BD7CW Trim Saw
Owner's Manual and Operating Instructions
Revision 100
Manual Part No. 170833-OM
Caution: Read all safety and operating
instructions before using this equipment.
This manual MUST accompany the
equipment at all times.
01.2014
Barranca Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
Toll-Free: (800) 630-7682
Phone: (310) 523-5867
Fax: (310) 257-3063
www.barrancadiamond.com
Advertisement
Table of Contents
Related Manuals for Barranca Diamond BD7CW
Summary of Contents for Barranca Diamond BD7CW
- Page 1 BD7CW Trim Saw Owner’s Manual and Operating Instructions Revision 100 01.2014 Barranca Diamond Products, Inc. Manual Part No. 170833-OM 1315 Storm Parkway Torrance, CA 90501 Caution: Read all safety and operating Toll-Free: (800) 630-7682 instructions before using this equipment. Phone: (310) 523-5867...
-
Page 2: Table Of Contents
This owner’s manual contains information neces- sary to operate and maintain your BD7CW Trim Slab Saw safely and correctly. Please take the time to familiarize yourself with the BD7CW Saw by reading and understanding this manual. -
Page 3: Safety Precautions
BD7CW SAFETY SAFETY PRECAUTIONS Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. In order to prevent injury, the... - Page 4 BD7CW SAFETY REDUCE THE RISK OF UNINTENTIONAL STARTS Make sure the ON/OFF switch is in the OFF position before plugging in a power tool. ROTATING OR MOVING PARTS Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never operate the motor with covers, shrouds or guards removed.
- Page 5 BD7CW SAFETY DIRECTION OF FEED All blades, grinding wheels or polishing belts should always be installed such that rotation is in the direction of the arrow imprinted on the blade, wheel or belt. ONLY OPERATE AT THE PROPER SPEED Severe personal injury and damage to the motor or equipment can result if operated at speeds above maximum.
- Page 6 BD7CW SAFETY SILICA DUST WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis.
-
Page 7: Electrical Requirements & Grounding Instructions
BD7CW SAFETY ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! WARNING In case of a malfunction or breakdown, grounding provides a path of least resistance for electrical current to reduce the risk of electric shock. - Page 8 BD7CW SAFETY ELECTRIC MOTOR SAFETY For maintenance care and operation of the electric motor, refer to your electric motor instruction book- let furnished with the electric motor. Protect the electric motor from dust as much as possible and keep ventilating openings clean. Before plugging in the machine, make sure that the outlet voltage is within the voltage marked on the machines's data plate.
- Page 9 BD7CW SAFETY WARNING To avoid the possibility of the appliance or plug receptacle getting wet, position the machine to one side of a wall mounted receptacle. This will prevent water from dripping into the receptacle or plug. A "drip loop," shown in the picture below, should be arranged by the user to properly position the power cord relative to the power source.
- Page 10 BD7CW SAFETY WARNING Use of undersized extension cords result in low voltage to the motor that can result in motor burnout and premature failure. MK Diamond warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords,will be repaired or replaced totally at the customer’s expense.
-
Page 11: Product Specifications
(w/o Hood & Vise) *220Volt w/Hood & Vise Part # 169780 BD7CW The BD7CW will manually cut specimens up to 1-3/16" (30mm) in height and has a 14" (356 mm) x 14" (356 mm) self-aligning tabletop. Blade Lubricate Approximately 1/3 gallon (1.3 liters) of lubricant is required to adequately cover the bottom of a 7-inch (178 mm) blade. -
Page 12: Oil/Coolant
A good coolant but has no lubricating properties and causes rust and degradation of exposed iron and steel parts. Causes rapid blade dulling and premature wear. Use of water voids the warranty on all Barranca Diamond saws. CNC Machining Fluids Water soluable synthetic coolants (i.e. -
Page 13: Assembly
Adding Lubricant Before operating the BD7CW, fill the reservoir so the lubricant fluid covers the bottom 1/4" (6.35 mm) of the blade. Be sure the sludge plug is pressed in. Equipment Damage: Do not overfill the reservoir. Excess fluid will result in unnecessary WARNING spraying of fluid while sawing. -
Page 14: Power Switch
BD7CW OPERATION Power Switch 1. Check that the power switch is in the OFF position. 2. Plug-in the power cord. Power Test Move the power switch to the ON position to rotate the blade. (Figure 6) Check that the blade is rotating. This indicates the saw is functioning properly. -
Page 15: Cutting
BD7CW CUTTING Cutting with the Trim Saw Ensure the power switch is in the OFF position. Slide the vise to the front of the saw. (Figure 8) Loosen the wing nuts to open the rock vise jaws clamp to fit the material to be cut. (Figure 9) The blade guard height can be adjusted by turning the knob located on the back of the blade guard. -
Page 16: Maintenance
BD7CW MAINTENANCE Maintenance The 7-inch Trim Saw will continue to perform at optimum levels with proper care, daily cleaning and general maintenance. CAUTION Place the ON / OFF switch in the OFF position and unplug cord before servicing and when changing accessories, such as blades. -
Page 17: Motor
WARNING If the saw motor should stop during operation, the power to the main motor must be shut off by moving the power switch in the OFF position. The motor will restart automatically once cooled down. If the motor does not restart after a cool down period, contact Barranca Diamond Service at 800.474.5594. Diamond Blade Periodically, the diamond blade will need to be resharpened, should slow or poor sawing performance occur. -
Page 18: Installation & Removal
BD7CW DIAMOND BLADE Diamond Blade Installation and Removal It will be necessary to access the blade for inspection or replacement. 1. Remove wing nut and lift table up. (Figure 17) 2. Use a 18mm adjustable wrench and allen wrench to tighten or loosen the jam nut, right hand thread. - Page 19 NOTES...
-
Page 20: Exploded View
BD7CW EXPLODED VIEW... -
Page 21: Part List
BD7CW PART LIST ITEM DESCRIPTION PART # QTY. SCREW, SOC HD CAP, 1/4 - 20 X 1 151049 NUT, HEX, 1/4 - 20 151893 WASHER, 1/4 SAE FLAT 151915 PLUG, RUBBER DRAIN W/O HOLE 153439-NL WASHER, #10 SPLIT LOCK 153684... - Page 22 NOTES...
- Page 23 NOTES...
- Page 24 PURCHASE PLACE: PURCHASE DATE: Barranca Diamond warrants to the original retail purchaser for a period of 1 year except as noted, from the date of purchase all products covered by this Warranty to be free of defects in materials and workmanship.
-
Page 25: Warranty
If the bond between the rim and the core fails during normal use, the blade will be replaced free of charge. Blades and bits damaged due to careless or improper use are not covered under this warranty. Exclusions Barranca Diamond does not warrant the following components, which carry their own manufacturer’s warranty for the indicated periods: Electric Motors Manufacturer’s Warranty... - Page 26 BD7CW SERVICE & WARRANTY REPLACEMENT PARTS Replacement parts for this tool may be ordered from your Barranca Diamond distributor or directly from Bar- ranca Diamond. Please have the following information ready before calling: • Model and serial number of the machine • Date of purchase • Description of parts being ordered (see parts list) RETURN MATERIALS PROCEDURE...
- Page 27 NOTES...
- Page 28 Barranca Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 421-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.barrancadiamond.com...
