PF10 Power Feed Trim Saw
Owner's Manual and Operating Instructions
Revision 105
Manual Part No. 161090
Caution: Read all safety and operating
instructions before using this equipment.
This manual MUST accompany the
equipment at all times.
07.2013
Barranca Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
Toll-Free: (800) 630-7682
Phone: (310) 523-5867
Fax: (310) 257-3063
www.barrancadiamond.com
Advertisement
Table of Contents
Related Manuals for Barranca Diamond PF10
Summary of Contents for Barranca Diamond PF10
- Page 1 PF10 Power Feed Trim Saw Owner’s Manual and Operating Instructions Revision 105 07.2013 Barranca Diamond Products, Inc. Manual Part No. 161090 1315 Storm Parkway Torrance, CA 90501 Caution: Read all safety and operating Toll-Free: (800) 630-7682 instructions before using this equipment.
-
Page 2: Table Of Contents
PF10 Thank you for selecting the Barranca Diamond PF10 Trim Saw. We are certain that you will be pleased with your purchase. Barranca Diamond takes pride in producing top quality products for hobby and commercial lapidary users throughout the world. -
Page 3: Safety Precautions
PF10 SAFETY SAFETY PRECAUTIONS Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. In order to prevent injury, the following safety precautions... - Page 4 PF10 SAFETY ROTATING OR MOVING PARTS Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never operate the engine with covers, shrouds, or guards removed. MAINTAIN TOOLS WITH CARE Keep tools clean for the best and safest performance. Always follow maintenance instructions for lubricating, and when changing accessories.
- Page 5 MAINTAIN TOOLS WITH CARE Keep the diamond blade sharp, the sawing lubricant clean and reservoir filled to the correct level for the best and safest performance. Always follow the maintenance instructions for sharpening the blade, lubricating and servicing the PF10.
-
Page 6: California Proposition 65 Warning
PF10 SAFETY WARNING Sawing, grinding and drilling generates dust. Excessive airborne particles may cause irritation to eyes, skin and respiratory tract. To avoid breathing impairment, always employ dust controls and protection suitable to the material being sawed, ground or drilled; (See OSHA 29 CFR Part 1910.1200). Diamond Blades improperly used are dangerous. -
Page 7: Electrical Requirements & Grounding Instructions
PF10 SAFETY ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! In case of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. - Page 8 Use of under size extension cords result in low voltage to the motor that can result in motor burnout and premature failure. Barranca Diamond warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords will be repaired or replaced totally at the customers expense.
-
Page 9: Product Specifications
PF10 SPECIFICATIONS Shipping Weight 95 lbs. (115 lbs. crated) Main Motor Baldor Model 17K017W470 Horsepower 1/3 HP Motor Voltage 110 volt/60Hz Amperage 5.8 Amps Motor RPM 1725 RPM Fixed Motor Arbor Diameter 1/2" Duty Continuous Motor Arbor Bearings Ball Bearings, permanently sealed Blade Capacity 8", 9"... -
Page 10: Oil/Coolant
A good coolant but has no lubricating properties and causes rust and degradation of exposed iron and steel parts. Causes rapid blade dulling and premature wear. Use of water voids the warranty on all Barranca Diamond saws. CNC Machining Fluids Water soluable synthetic coolants (i.e. -
Page 11: Setup
SETUP CONTENTS In the shipping crate, you will find one Barranca Diamond PF10 Trim Saw assembly (saw, motor, baseboard, spray hood and 10" x 0.040 x 5/8 303 Pro diamond blade). One package of six rubber feet and mounting screws, and one 1" x 1" x 6" sharpening stick. -
Page 12: Inspection
Fig 3. Toggle power switch positions and functions Prior to operating the PF10 Trim Saw, you must fill the oil reservoir so that the lubricant fluid covers the bottom 1/4" of the blade (fig 4). 1/2 gallon of oil will adequately cover the bottom of a 10” blade and 3/4 gallon will be sufficient for an 8”... -
Page 13: Start Up
PF10 START UP START UP With the table removed from the reservoir, inspect the motor mounts and belt tension. Check the four motor mounting nuts (fig 6) to insure they are tight and the motor is secure. The V-belt is adjusted and tensioned at the factory. - Page 14 Fig 9. Motor cord attached to the power feed box receptacle If an extension cord is used to attach to the PF10 Trim Saw, use an extension cord that is at least 14 gauge wire and no longer than 25 feet.
-
Page 15: Start Up
PF10 START UP START UP (continued) Once the rock vise is placed in the far back position, lock the clutch handle in the 9 or 3 o’clock position (fig 11). Now engage the power feed and main motor to begin advancing the vise and rotating the blade by pushing the toggle to the rear or to the BACK/POWER FEED position (fig 3). -
Page 16: Slab Sawing Mode
PF10 SLAB SAWING MODE SLAB SAWING MODE To begin slabbing of rock material, turn the toggle switch to the MIDDLE/OFF position (fig 3) and secure the material in the rock vise by opening the vise jaws wide enough to fit the material to be cut. Retighten the jaws with the wing nut screws on the rock vise (fig 14). - Page 17 PF10 SLAB SAWING MODE SLAB SAWING MODE (continued) At this point, the clutch handle should be engaged by turning it to the 3 or 9 o’clock position (fig 11). Slab- bing of material can now be initiated by engaging the power feed and blade by moving the toggle switch to the BACK/POWER FEED position (fig 3).
-
Page 18: Trim Sawing Mode
TRIM SAWING MODE TRIM SAWING MODE Slabbing of rock material to uniform thicknesses using the PF10 Trim Saw is best performed using the auto- matic power feed mode. However, manual trimming of slabs to desired shapes (preforming) can be achieved using the saw in the FORWARD/MANUAL FEED position (fig 3). -
Page 19: Maintenance
CUTTING LUBRICANT REPLACEMENT The PF10 Trim Saw requires periodic routine maintenance to remove the build up of rock mud (sludge) and dirty lubricating fluid from the reservoir. It will be apparent to the user that the lubricating fluid is dirty and needs to be changed if the oil residue on the saw table after cutting is thick and dark with rock sludge build up. - Page 20 The power feed system utilizes a 4 RPM AC gear motor mounted inside of the rectangular box attached to the front of the PF10 Trim Saw (fig 27). There is no need to service or lubricate the power feed motor unless the motor fails and the screw feed rod fails to rotate when the feed is engaged.
- Page 21 BLADE ARBOR ASSEMBLY AND PULLEYS The PF10 Trim Saw is equipped with a 5/8"-18 left-hand fine threaded arbor shaft with sealed ball bearings mounted in an aluminum bearing arbor housing. A 2" OD x 5/8" bore die cast zinc coated pulley is mounted on the shaft outside the oil reservoir.
- Page 22 ON. If the motor does not restart after a cool down period, remove the motor and have an authorized repair service center for Baldor inspect the motor. Barranca Diamond can refer you to an authorized motor repair service center in your area.
-
Page 23: Diamond Blade
Fig 31. Motor reset button. DIAMOND BLADE Periodically, the diamond blade on the PF10 Trim Saw will need to be resharpened should slow or poor sawing performance occur. Dull or “glazed over” diamonds will either not cut thus stalling the saw and shutting off the motor, or the rock vise and rock material will ride up the blade and possibly damage the blade or “dish”... -
Page 24: Installation & Removal
PF10 INSTALL/REMOVAL DIAMOND BLADE INSTALLATION AND REMOVAL (continued) Reattach the saw table with the four mounting screws. Be sure the cork tank gasket is positioned correctly between the saw table and coolant reservoir and that the proper amount of lubricant is in the reservoir before attaching the saw table. - Page 25 NOTES...
-
Page 26: Exploded View
PF10 EXPLODED VIEW... - Page 27 PF10 EXPLODED VIEW...
-
Page 28: Part List
PF10 PARTS LIST Item Description Part # Assembly, Accessories Guard, Splash 161023 Screw, Round Head Machine 10-32 x 1" 161042 Spacers, Splash Guard 161076 Washer, Flat SAE # 10 154369 Nut, Hex 10-32 156269 Blade, MK-303 10 x 040 x 5/8"... - Page 29 Cord, Power 14/3 SJTWX5-15PX10 158205 Assembly, Shaft Shaft, Casting 161075 Pulley, Shaft 161020 Screw, Set 10-32 x 5/16" 161088 Shaft, Blade PF10 Bearing, Shaft PF10 162562 Collar, Shaft Pin 161017 Collar Shaft 161089 Gasket, Shaft 161043 Flange, Blade 2-1/4" OD X 5/8" Arbor 135830 Nut, 5/8"-18 UNF...
-
Page 30: Part List
PF10 PARTS LIST Washer, Flat SAE # 10 154369 Slide Plate, Vise 161035 Slider, Upper Brass 161029 Slider, Lower Brass 161030 Screw, Round Head Machine 10-32 x 1" 161042 Nut, Hex 10-32 156269 Assembly, Linear Feed Housing, Gear Motor 161046... - Page 31 NOTES...
-
Page 32: Service And Warranty
PURCHASE PLACE: PURCHASE DATE: Barranca Diamond warrants to the original retail purchaser for a period of 1 year except as noted, from the date of purchase all products covered by this Warranty to be free of defects in materials and workmanship. - Page 33 Blades and bits damaged due to careless or improper use are not covered under this war- ranty. Exclusions: Barranca Diamond does not warrant the following components, which carry their own manufacturer’s warranty for the indicated periods: Electric Motors Manufacturer’s Warranty...
-
Page 34: Replacement Parts
• Date of purchase • Distributor’s name Then please call Barranca Diamond at (310) 523-5867 or toll free at 800-630-7682 to obtain a Return Goods Authorization number (RGA) authorizing the return. Please Note: • Ensure your item(s) are prepaid to the destination •... - Page 35 NOTES...
- Page 36 Barranca Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 421-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.barrancadiamond.com...
