Barranca Diamond HP18 Owner's Manual Operating Instruction & Parts List

Slab saw series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Slab Saw SERIES
Owner's Manual, Operating
instructiOns & parts list
revision 117
Manual part no. 164269
Caution: read all safety and operating
instructions before using this equipment.
this manual MUST accompany the
equipment at all times.
MADE IN USA
06.2017
MOdels:
Hp18
Hp20
Hp24
MADE IN USA
Barranca diamond products, inc.
1315 storm parkway
torrance, ca 90501
toll-Free: (800) 630-7682
phone: (310) 523-5867
Fax: (310) 257-3063
www.barrancadiamond.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP18 and is the answer not in the manual?

Questions and answers

Related Manuals for Barranca Diamond HP18

Summary of Contents for Barranca Diamond HP18

  • Page 1 Hp18 Hp20 Hp24 MADE IN USA MADE IN USA revision 117 06.2017 Barranca diamond products, inc. Manual part no. 164269 1315 storm parkway torrance, ca 90501 Caution: read all safety and operating toll-Free: (800) 630-7682 instructions before using this equipment.
  • Page 2 INTRODUCTION thank you for selecting the Barranca diamond slab saw. we are certain that you will be pleased with your purchase. Barranca diamond takes pride in producing top quality products for hobbyists and commercial lapidary users throughout the world. this product is manufac- tured in the united states.

  • Page 3: Table Of Contents

    Maintenance Following use general Maintenance Monthly Maintenance 19-20 troubleshooting eXplOded View & parts list Hp18 explored View & parts list 24-27 Hp18 Vise assembly & parts list Hp18 Hood assembly & parts list Hp24 explored View & parts list 30-33 Hp24 Vise assembly &...

  • Page 4: Safety

    Slab Saw SERIES SaFETY SaFETY PRECaUTIONS read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. in order to prevent injury, the following safety precautions should be followed at all times! REaD OwNER'S MaNUal bEFORE USE Before using this equipment, ensure that the person operating this machine has read and...
  • Page 5 Slab Saw SERIES SaFETY REDUCE THE RISK OF UNINTENTIONal STaRTS Make sure the ON/OFF switch is in the OFF position before plugging in a power tool. ROTaTING OR MOvING PaRTS Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. never operate the engine with covers, shrouds or guards removed.
  • Page 6 Slab Saw SERIES SaFETY DIRECTION OF FEED always feed work into a blade or cutter in the direction shown in this manual. all blades, grinding wheels or polishing belts should always be installed such that rotation is in the direction of the arrow imprinted on the blade, wheel or belt.
  • Page 7 Slab Saw SERIES SaFETY SIlICa DUST waRNING grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis.

  • Page 8: Electrical Requirements

    Slab Saw SERIES SaFETY ElECTRICal REQUIREMENTS aND GROUNDING INSTRUCTIONS in order to prevent electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! waRNING in case of a malfunction or breakdown, grounding provides a path of least resistance for electrical current to reduce the risk of electric shock.
  • Page 9 Barranca diamond warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords, will be repaired or replaced totally at the customer's expense.
  • Page 10 8302024 MOTOR single phase, continuous duty commercial grade motor with automatic thermal overload protection. Manual reset button on Hp18, Hp20 & Hp24 Baldor motors. export motor 230 volts 50Hz can be or- dered with either saw. FEED MECHaNISM stainless steel screw rod with silicon bronze threaded clutch block engagement system. silicon bronze spur to hardened steel worm gear to belt pulley drive.

  • Page 11: Unpacking & Assembly

    11 gauge steel construction with locking casters on slab saws. OIl SlUDGE DRaIN 2” drain cap on Hp18 and Hp24 saws. drain placement is on bottom of saw tank. ON/OFF aUTOMaTIC POwER CONTROl Hp18 and Hp24 saws have adjustable chain for automatic shut-off control of power on/off switch.

  • Page 12: Contents

    Slab Saw SERIES SPECIFICaTION CONTENTS in the wood crate, you will find one (1) Barranca diamond slab saw, one (1) 303 segmented diamond blade, one (1) owner’s manual, one (1) warranty card, and 4 leg casters (SLAB SAW SERIES). TRaNSPORT slab saws weigh between 550 (Hp18 &...
  • Page 13 Barranca diamond saws. CNC Machining Fluids water soluble synthetic coolants (i.e.

  • Page 14: Pre-Start Inspection

    Slab Saw SERIES STaRTUP & aDJUSTMENT PRE-STaRT INSPECTION the pre-start inspection should be performed before beginning any job. 1. Check Oil level Oil should always cover at least 1/4" to 3/8" of the bottom of the blade (Kerf should be completely cov- ered).

  • Page 15: Startup

    Slab Saw SERIES STaRTUP & aDJUSTMENT automatic Shutoff (Slab Saw SERIES) Once a rock specimen has been securely vised inside of the saw, the operator can adjust the automatic shut-off control switch by moving the link chain to the desired position where the rock and vise are anticipated to complete the desired cut.

  • Page 16: Adjustment & Operation

    1/2" plywood to give firm and tight grip to the rock specimen. should replacement be needed due to wear or breakage, the parts can be ordered from Barranca diamond products. wedges of wood can be used in the voids between the rock specimen and vise plates to enhance the surface contact and pressure hold prior to tightening the vise screw bolt.
  • Page 17 Slab Saw SERIES STaRTUP & aDJUSTMENT Handle Crank Cross Feed adjustable Rock Cut Index Control to use the crank cross feed index wheel, simply clamp and secure the cutting material into the vise by using the clamp screw to tighten the vise and turn the wheel crank until the desired slab thickness is achieved You can measure the slab thickness with a ruler prior to cutting, but remember, depending on blade thickness, the amount of waste material...
  • Page 18 Barranca diamond at (800) 630-7682 for factory assistance in clutch adjustment. Feed screw & clutch block shoe brass pressure block, feed screw &...

  • Page 19: Maintenance Following Use

    Slab Saw SERIES MaINTENaNCE MaINTENaNCE FOllOwING USE the following maintenance should be performed following each use. place the ON/OFF switch in the OFF position and unplug cord prior to servicing waRNING and when changing accessories, such as blades, belts, and the like. blade-Shaft bearings remove sheet metal cover over blade shaft and grease zerk fittings on base mount bear-...

  • Page 20: General Maintenance

    Slab Saw SERIES MaINTENaNCE GENERal MaINTENaNCE Oil Sludge Removal from Reservoir use plumber's pipe wrench to remove drain cap. allow free liquid to drain to a pan. use a spatula to remove sludge from tank bottom toward drain hole. use of plumbers tape on the drain pipe threads will adequately seal the cap to thread contact to prevent leaks.

  • Page 21: Lubrication Points

    Slab Saw SERIES MaINTENaNCE worm Shaft and Pinion Gear lubrication the worm drive shaft and pinion gear lubrication box on the rear of the saw should be checked for adequate grease lubrication periodically. remove cover to check lubricant, remove the box by remov- ing the four mounting screws that attach the box to the rear of the saw reservoir.

  • Page 22: Troubleshooting

    Slab Saw SERIES TROUblESHOOTING TROUblESHOOTING Saw will Not Start check power cord and receptacle. Motor Overheating if motor overheats allow to cool for 2 to 3 hours, push reset button with power disconnected, hookup power cord and resume cutting by pulling the power switch to the On position. all motors have automatic thermal protection and will shut off if overheated.
  • Page 23 NOTES...

  • Page 24: Exploded View

    HP18 EXPlODED vIEw HP18 Slab Saw Part# 8302018 bOM SUbSTITUTION TablE PaRT # DESCRIPTION 156729 8302020 Hp-20 slaB saw 1.5Hp 166073 ITEM DESCRIPTION PaRT # QTY. nut, HeX, 3/8 - 16 101188 screw, HeX Head, 1/4 - 20 X 5/8...
  • Page 25 HP18 EXPlODED vIEw HP18 Slab Saw Part# 8302018 ITEM DESCRIPTION PaRT # QTY. cOllar, sHaFt, 3/4" i.d. 153814 wasHer, Flat, sae, #10 154369 screw, pan Hd, cap, 1/4 - 20 X 1/2 155452 screw, Flat Head, 1/4-20X 1/2 pHil 155812...

  • Page 26: Parts List

    HP18 PaRTS lIST HP18 Slab Saw Part# 8302018...
  • Page 27 HP18 PaRTS lIST HP18 Slab Saw Part# 8302018 ITEM DESCRIPTION PaRT # QTY. nut, HeX, 3/8-16 101188 pulleY, 2-3/4 X 5/8 134668 wasHer, Flat, sae, 3/8 150923 wasHer, Fender, 5/16 X 1.0 151053 screw, HeX Hd, cap, 5/16-18 X 3/4...
  • Page 28 HP18 EXPlODED vIEw HP18/20 assembly, vise Part # 166372 ITEM DESCRIPTION PaRT # QTY. wasHer, Flat, sae, 1/4 151915 screw, HeX Hd, cap, 1/4-20X 2-1/4 156607 screw, 5/16-18 X 3/8 sOcKet Head set 157083 nut, HeX, nYlK, 1/4-20 159857 BusHing, BrOnZe Flanged 5/8 X 1/2 X 3/4...
  • Page 29 HP18 PaRTS lIST HP18/20 assembly, Hood Part # 166373 ITEM DESCRIPTION PaRT # QTY. nut, HeX, 1/4-20 151893 wasHer, Flat, sae, 1/4 151915 screw, Flat Hd, 1/4-20 X 3/4 154657 screw, pan Head pHillips 10-32 X 3/8" 161875 pull Handle...
  • Page 30 HP24 EXPlODED vIEw HP24 Slab Saw Part# 8302024 ITEM DESCRIPTION PaRT # QTY. nut, HeX, 3/8 - 16 101188 nut, HeX, 5/16 -18 101196 screw, HeX Head, 1/4 - 20 X 5/8 150404 wasHer, Flat, sae, 3/8 150923 wasHer, 3/8 split lOcK 150925 wasHer, lOcK, split, 5/16 151747...
  • Page 31 HP24 EXPlODED vIEw HP24 Slab Saw Part# 8302024 ITEM DESCRIPTION PaRT # QTY. cOllar, sHaFt, 3/4" i.d. 153814 screw, HeX Hd, 5/16-18X1-1/4 153950 screw, Flat Hd, 1/4-20 X 3/4 154657 screw, pan Hd, cap, 1/4-20 X 1/2 155452 Blade, 24 X 1.0, 303s 165731 screw, Flat Hd, 1/4-20X1 157527...
  • Page 32 HP24 PaRTS lIST HP24 Slab Saw Part# 8302024...
  • Page 33 HP24 PaRTS lIST HP24 Slab Saw Part# 8302024 ITEM DESCRIPTION PaRT # QTY. nut, HeX, 3/8-16 101188 pulleY, 2-3/4 X 5/8 134668 wasHer, Flat, sae, 3/8 150923 wasHer, Fender, 5/16 X 1.0 151053 screw, HeX Hd, cap, 5/16-18 X 3/4 151369 wasHer, Flat, sae, 5/16 151754...
  • Page 34 HP24 EXPlODED vIEw HP24 vise assembly Part# 167368 SCALE 0.375 ITEM DESCRIPTION PaRT # QTY. wasHer, Flat, sae, 1/4 151915 screw, HeX Hd, cap, 1/4-20X 2-1/4 156607 screw, 5/16-18 X 3/8 sOcKet Head set 157083 nut, HeX, nYlK, 1/4-20 159857 BusHing, BrOnZe Flanged 5/8 X 1/2 X 3/4 162304 sHOe, clutcH cOMplete...
  • Page 35 HP24 PaRTS lIST HP24 assembly, Hood Part # 172308 ITEM DESCRIPTION PaRT # QTY. wasHer, Flat, sae, 1/4 151915 screw, HeX Hd, 1/4-20 X 3/4 152370 nut, HeX, nYlK, 1/4-20 159857 guard, splasH, nO lOgO 160310-nl weldMent, HOOd 164949 windOw 166151 gasKet, windOw 166213...
  • Page 36 Barranca diamond customer service department at (800) 630-7682 M-F 8am - 5pm pst. Barranca diamond warrants to the original retail purchaser for a period of 90 days except as noted, from the date of purchase all products covered by this warranty to be free of defects in materials and workmanship.

  • Page 37: Warranty

    Blades and bits damaged due to careless or improper use are not covered under this warranty. Exclusions Barranca Diamond does not warrant the following components, which carry their own manufacturer’s warranty for the indicated periods: Electric Motors Manufacturer’s Warranty...
  • Page 38 • Date of purchase • Distributor’s name then please call Barranca diamond at (310) 523-5867 or toll free at 800-630-7682 to obtain a return goods authorization number (rga) authorizing the return. please note: • Ensure your item(s) are prepaid to the destination •...
  • Page 39 NOTES...
  • Page 40 Barranca diamond products, inc. 1315 storm parkway torrance, ca 90501 toll-Free: (800) 421-5830 phone: (310) 539-5221 Fax: (310) 539-5158 www.barrancadiamond.com...
