INSTALLER/CONSUMER
SAFETY INFORMATION
Read and save
these instructions.
This book contains your installation
instructions and should be kept in a
safe place. For you to realize all the
advantages and use of the reliable
service that has been engineered into
your Temco fireplace, you must care-
fully follow all of the instructions con-
tained in this book regarding installation
and operation of the fireplace.
These instructions should be read
carefully in their entirety before begin-
ning installation of the fireplace.
It is suggested that you wear work
gloves and safety glasses to protect
your hands and eyes when installing
your fireplace. NOTE: Authorities
having jurisdiction (i.e. building inspec-
tors, fire marshals, etc.) should be
consulted before installation to deter-
mine the need to obtain a permit.
When installing the Blower Kit, it is
necessary to bring the power source to
the fireplace before walls are enclosed.
Refer to Blower Kit instructions.
These fireboxes are approved as
universal fireboxes and can be
paired with any ANSI Z21.11.2 ap-
proved vent-free log set. The vent-
free log manufacturer's instructions -
including their required dimensional
clearances for firebox size, - must be
followed.
Refer to the manual that is packed with
the log set for operating instructions.
INSTALLER DO NOT DISCARD THIS MANUAL - Leave in Fireplace for Homeowner
Vent-Free Firebox
Models: UVSRC36A
Homeowner's Installation and
Operating Manual
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
UVSRC42A
"
20007435 6/04 Rev. 1
