Majestic fireplaces UVLC18RN Installation And Operating Instructions Manual
Majestic fireplaces UVLC18RN Installation And Operating Instructions Manual

Majestic fireplaces UVLC18RN Installation And Operating Instructions Manual

Vent-free gas log sets
Hide thumbs Also See for UVLC18RN:

Advertisement

If the information in this manual is not followed exactly, a fire or explosion may result, causing property
damage, injury or loss of life.
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call
the fire department.
INSTALLER PLEASE NOTE:
DO NOT begin installation of this gas logset
until all instructions have been read and under-
stood.
CARBON MONOXIDE POISONING MAY LEAD TO DEATH.
When used without fresh air, vent-free log sets may give off carbon monoxide, an odorless, poisonous gas.
Some people - pregnant women, people with heart or lung disease, anemia, or persons under the influence of alcohol, and
persons at high altitudes are more affected by carbon monoxide than others.
Early signs of carbon monoxide poisoning resemble the flu - headache, dizziness, and/or nausea. If you have these signs, the
heater may not be installed or working properly. GET FRESH AIR AT ONCE! Have the heater serviced before using it again.
*These logsets are not for exterior use.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Vent-Free Gas Log Sets*
Models: UVLC18RN, UVLC24RN, UVLC30RN (Natural Gas)
UVLC18RP, UVLC24RP, UVLC30RP (Propane)
Installation and Operating
Instructions
W A R N I N G
Tested and listed to ANSI Z21.11.2b.2004, Unvented Heaters,
and Z21.60b-2004; CSA 2.26b-2004 Decorative Gas Appliances
for Installation in Solid-Fuel Burning Fireplaces.
Installation and service must be performed by
a qualified agency, individual, firm, corporation,
or company, experienced in the installation, re-
pair, and servicing of this type of gas appliance.
Do not modify, alter or tamper with any part of
this heater, control, or logs.
This appliance may be installed in an aftermar-
ket, permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases.
W A R N I N G
C E RT I F I E D
ATTENTION
20000333 7/06 Rev. 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UVLC18RN and is the answer not in the manual?

Questions and answers

Summary of Contents for Majestic fireplaces UVLC18RN

  • Page 1 Vent-Free Gas Log Sets* Models: UVLC18RN, UVLC24RN, UVLC30RN (Natural Gas) UVLC18RP, UVLC24RP, UVLC30RP (Propane) Installation and Operating Instructions C E RT I F I E D W A R N I N G If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, injury or loss of life.
  • Page 2: General Information

    General Information • In order to avoid any possible gas leaks, apply pipe joint com- IN ORDER TO ASSURE A SAFE AND EFFECTIVE pound to all non-flared, threaded connections involved in this INSTALLATION, ONLY A QUALIFIED SERVICE installation. For propane, the joint compound must be resistant PERSON WHO IS FAMILIAR WITH THE BUILDING to the corrosive action of propane.
  • Page 3: Installation Requirements

    Rear Overall Overall Pressure (w.c.) Manifold Min. Input Max. Input Setting Width Width Depth Height Min. Max. Pressure BTU/hr BTU/hr Front Rear 18” UVLC18RN 30” 17” 15” 18” 5.5” 14.0” 3.5” 22,000 30,000 3/8” 3/8” Open Open 24” UVLC24RN Natural 33”...
  • Page 4: Installation Precautions

    When installed as a Decorative Gas Appliance for Planning installation in a solid-fuel burning fireplace, a mini- Planning the installation is an important first step. It will mum permanent free opening of 29 square inches save time and money later in the actual installation. In must be maintained with a fixed damper stop pro- planning the installation, consider: vided with the appliance.
  • Page 5: Provide For Adequate Ventilation

    Installation Requirements If your home meets all of the above criteria, you must Fresh Air Requirements provide additional fresh air for the appliance as detailed for Combustion and Ventilation on Page 6. WARNING If your home does not meet the above criteria, follow the procedure below.
  • Page 6 Example: B. Vent the room directly to the outdoors. (Provide one square inch of opening for each 4,000 BTU/hr.) Gas Range 55,000 BTU/hour Vent-Free LogSet +25,000 BTU/hour For further information on ventilation guidelines and siz- Total 80,000 BTU/hour ing specifications, follow the National Fuel Gas Code/ NFPA 54/ANSI Z223.1/NFPA 54, Section 5.3.
  • Page 7: Installation Instructions

    Installation Instructions WARNING: Do not install this appliance in bedrooms or bathrooms. Do not allow fans to blow directly into the fire- WARNING: Any change to this heater or its con- place. Avoid any drafts that alter burner flame trols can be dangerous. patterns.
  • Page 8 Manufactured Fireplace Damper Stop Installation Damper Stop #3030176 is designed for use with CFM Corporation BR, BC, SR, SC,TF and TL Series fire- places. 1. Open the fireplace damper. The damper must be in the open position in order to attach the damper stop. 2.
  • Page 9 Front View Ceiling Without Hood With Hood 8” 42” Noncombustible Facing Material 3¹⁄₂” Noncombustible Min. Material Flat Mantel 38¹⁄₂” Shelf Standoff Standoff 8” 20” 4” 12’ 4” 7¹⁄₂” MC656-2 Seal with 3¹⁄₂” MC656-2 Noncombus- Min. clearances 3/26/99 djt tible Material 4”...
  • Page 10: Gas Line Connection

    Gas Line Connection WARNING Check the gas type. Use only the gas type indicated on Connection directly to an unregulated LP tank can the appliance rating plate. If the gas listed on the plate cause an explosion. is not the type of gas supplied, DO NOT INSTALL the During the initial purging and subsequent light- log set.
  • Page 11: Remote Wall Switch

    Remote Wall Switch (Optional Model GWSK) 1. Thread wire through the electrical knockout located on either side of the fireplace. Do not cut the wire or insulation on metal edges. Ensure that the wire is protected. Run the other end to a conveniently located wall receptacle box.
  • Page 12: Flame Appearance

    Operating Instructions The First Firing Yellow Flames On completing the gas line connection, a small amount of air will be trapped in the gas line. When you first light the unit with the pilot light, it will take a few minutes to purge the trapped air.
  • Page 13: For Your Safety Read Before Lighting

    Lighting And Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- instructions.
  • Page 14: Troubleshooting

    Troubleshooting Honeywell Valve START CHECK • Supply line hooked up Gas supply on • Shutoff valve open • Lockout has engaged. Wait 60 seconds and try again • Piezo screws are tight for good ground Pilot lights with Piezo • For spark at electrode while depressing piezo - 1/8”...
  • Page 15: Inspecting The Venting System

    Inspecting the Venting System Maintenance and Safeguards A vented fireplace venting system is designed and con- Keep the control compartment, logs and burner area structed to develop a positive flow adequate to remove around the logs clean by vacuuming or brushing at least flue gasses to the outside atmosphere.
  • Page 16 2a,b 15a/b Switch 19a,b (behind door) CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. UVLC Supreme Vent Free Gas Logs 0333 Ref. Description UVLC18 UVLC24 UVLC30 UVLC parts Complete Log Set...
  • Page 17 UVLC Supreme Vent Free Gas Logs (continued) Ref. Description UVLC18 UVLC24 UVLC30 Log #V43 Front Left 20004893 Log #V44 Front Right 20004894 Burner Supply w/Orifices - Natural 20003050 20000329 20000329 Burner Supply w/Orifices - LP 20003687 20000318 20000318 3/8” Flex Tubing 3304176 3304176 3304176...
  • Page 18 Accessories The following accessories are available from your Majestic Fireplaces Dealer. If you need additional information beyond what your dealer can supply, contact CFM Corporation, 2695 Meadowvale Blvd., Mississauga, Ontario, Canada L5N 8A3 Attention: Director of Technical Service. Accessory Description...
  • Page 19 La Société n’assume et n’autorise personne à assumer, en son nom, toutes The Company will not be responsible for . . . responsabilités en ce qui a trait à la vente de ce produit Majestic Fireplaces. a) Down drafts or spillage caused by environmental conditions such as near- Les garanties, telles que décrites dans ce document, ne s’appliquent pas aux...
  • Page 20 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com © CFM Corporation...
