INSTALLER/CONSUMER
SAFETY INFORMATION
DO NOT INSTALL AN APPLI-
ANCE IN THIS FIREBOX, UN-
LESS THIS FIREBOX MEETS
THE MINIMUM DIMENSIONS
REQUIRED FOR THE INSTALLA-
TION.
WARNING: If the information in
this manual is not followed
exactly, a fire or explosion may
result causing property dam-
age, personal injury or loss of
life.
FOR USE ONLY WITH A LISTED,
GAS-FIRED, UNVENTED, DECO-
RATIVE ROOM HEATER NOT TO
EXCEED 40,000 BTU/H.
DO NOT BUILD A WOOD FIRE.
DUE TO HIGH TEMPERATURES,
THE APPLIANCE SHOULD BE
LOCATED OUT OF TRAFFIC
AND AWAY FROM FURNITURE
AND DRAPERIES.
Do not attempt to modify or alter
the construction of the appliance
or its components. Any modifica-
tion or alteration of construction
may void the warranty of these
units.
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or any
other appliance. Improper service
or maintenance can cause injury
or property damage. Refer to this
manual. For assistance or addi-
tional information, consult a
qualified installer, service agency
or the gas supplier.
Carefully review the instructions
supplied with the decorative type
unvented room heater for the
minimum fireplace size require-
ment.
INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner.
Ventless Fireboxes
Models: UVSRC36
UVSRC42
Homeowner's Installation
and Operating Manual
These Ventless Fireboxes are design certified
to ANSI 21.91.2001, and are for use with any
ANSI Z21.11.2a Unvented Room Heaters.
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
™
2068
20002068 2/04 Rev. 10
Advertisement
Related Manuals for Majestic fireplaces UVSRC36
Summary of Contents for Majestic fireplaces UVSRC36
- Page 1 INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner. Ventless Fireboxes Models: UVSRC36 UVSRC42 Homeowner's Installation and Operating Manual These Ventless Fireboxes are design certified to ANSI 21.91.2001, and are for use with any ANSI Z21.11.2a Unvented Room Heaters.
-
Page 2: Table Of Contents
(See the Accessories on Page 12 for details.) Available Models: UVSRC36 - Radiant Circulating Model UVSRC42 - Radiant Circulating Model Do not place clothing or other flammable material on or near the appliance. -
Page 3: Specifications And Framing
" 33 " 47" 66 " " 38" Outside Air Gas Line Access Electrical Access Fig. 1 UVSRC36 Series Firebox specifications and framing dimensions. UVSRC42 Series Firebox Specifications 50" " " 36" 50" 70 " " 38" Outside Gas Line... -
Page 4: General Information
UVSRC Series Fireboxes DO NOT BURN WOOD OR OTHER MATERIALS IN THESE FIREBOXES. General Information The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 (latest edition) and with the Na- tional Electrical Code, ANSI/NFPA70 (latest edition). -
Page 5: Clearances
250°F or greater. Grate Clearance: The minimum clearance between the front legs of the grate and front edge of the fireplace is 3”. (Fig. 4) UVSRC Series Firebox Dim. UVSRC36 36" 17" 12" 14" 42"... -
Page 6: Installation
UVSRC Series Fireboxes Planning In planning the installation for the firebox it is necessary to determine where the unit is to be installed and whether optional accessories are desired. Gas supply piping should also be planned. These models MAY NOT be installed in OEM mobile homes. - Page 7 See gas specifications for pressure details and ratings. 20002068 The UVSRC36/42 with optional fan requires 120VAC electrical hook-up. 3/8" Union CAUTION: All wiring should be done by a qualified electrician and shall be in compliance with all local, 3/8"...
- Page 8 UVSRC Series Fireboxes Black White Ground Fig. 8 Wiring diagram. Install Fan Kit Assembly Refer to the Fan Kit (Model FK12) installation instruc- tions for field installation. (Fig. 8) WHEN INSTALLED, THE FIREBOX MUST BE ELCTRICALLY CONNECTED AND GROUNDED (See Figure 14) IN ACCORDANCE WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES: U.S.
- Page 9 Finishing Refer to Page 5, Figure 3 for allowable finishing materi- als and clearances to combustibles. All joints, top, bottom and sides, where the wall or decorative facing material meets the firebox surround must be completely sealed with a noncombustible material.
-
Page 10: Maintenance
UVSRC Series Fireboxes Install Hood A hood is furnished with the firebox. Optional hoods listed on Page 12 may be installed as shown in Figures 16 and 17. Failure to do so may create a fire hazard. WARNING: When the black surround is covered by a brick surface, (Figure 16), use an extended hood. - Page 11 CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. UVSRC36/42 Ref. Description 1a. Right Screen Assembly (Screens and Rod) 1b. Left Screen Assembly (Screens and Rod) 2.
-
Page 12: Replacement Parts
UVSRC Series Fireboxes The following accessories for these appliances are available from your local Majestic Fireplaces distributor. Each accessory comes with a separate installation instruction for mounting to the particular firebox. Be sure to read each instruction thoroughly before installing. See your Majestic Fireplaces distributor or dealer for other finishing options such as marble and mantels —... - Page 13 LIMITED WARRANTY & 30 YEAR PROTECTION PLAN For MAJESTIC FIREPLACES CFM Specialty Home Products warrants its MAJESTIC FIREPLACES® Pre-Engineered Fireplace (“Fireplace”) and the CFM Specialty Home Products supplied firegrate, glass doors, outside air system, fan motor, and liners to be free from defects in material or workmanship, as follows: A.
- Page 14 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com © CFM Specialty Home Products...
