Striking energy G2 1500 R Instruction Manual

ShortWave Space Heaters
Models
G2 1500 R, G2 2000 R, G2 3000 R, G2 4000 R
G2 1500 ULG, G2 2000 ULG, G2 3000 ULG, G2 4000 ULG
Features
• 5 Year warranty on the body
• Integrated uni-body reflector
• Manufactured in South Africa. Parts available locally.
• Unique reflector design resulting in cost effective heat reflection.
• High grade Aluminium and Stainless steel construction. No powder coated mild steel that chip rust and
flake.
Applications
• Restaurants & Hotels,
• Homes, Bathrooms, Patios
• Schools, Halls
• Factories, warehouses
• Greenhouses and other Agricultural
Safety / Cautions: :
• The appliances must be installed by a qualified electrician according to the legal regulations as
published.
• The heater must always be earthed.
• If the heater is installed without a plug, or with other means for disconnection from the supply, a
double pole isolator should be used.
• The heater must not be installed in a recessed area. It must always be surface mounted and allow for
proper ventilation. Do not allow any heat build-up.
• The minimum ventilation openings around the heater, after installation, must be 150mm from the top
and sides and at least 1500mm away from any combustible materials (curtains, paper etc)
• Remove the foam that protects the lamp during transit before operating the heater.
• The heater MUST be installed above 1800mm from the floor surface.
• Ensure that the heater is properly fixed using the supplied swivel bracket.
• Permanent wall plugs and or screws should be used.
• Do not use any form of adhesive tape or temporary fixing.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• When installed in a bathroom / Jacuzzi area, installed in such a way that the heater, switches and
other controls cannot be touched by a person in the bath
Page ! of ! 1 6
Instruction Manual
www.striking.co.za info@striking.co.za Tel: 012 940 8222
instructions
