Striking energy G2 1500 R Instruction Manual

www.striking.co.za
Fixed Installation
The appliances must be installed by a qualified electrician according to the
•
legal regulations as published.
The heater must always be earthed.
•
If the heater is installed without a plug, or with other means for disconnection
•
from the supply, a double pole isolator should be used.
The heater must not be installed in a recessed area. It must always be surface
•
mounted and allow for proper ventilation. Do not allow any heat build-up.
The minimum ventilation openings around the heater, after installation, must be
•
150mm from the top and sides and at least 1500mm away from any
combustible materials (curtains, paper etc)
Remove the foam that protects the lamp during transit before operating the
•
heater.
The heater MUST be installed above 1800mm from the floor surface.
•
Ensure that the heater is properly fixed using the supplied swivel bracket.
•
Permanent wall plugs and or screws should be used.
Do not use any form of adhesive tape or temporary fixing.
•
If the supply cord is damaged, it must be replaced by the manufacturer, its
•
service agent or similarly qualified persons in order to avoid a hazard.
When installed in a bathroom / Jacuzzi area, installed in such a way that the
•
heater, switches and other controls cannot be touched by a person in the bath
Installation on a portable stand
Do not use this heater in the immediate surroundings of a bath, a shower or a
•
swimming pool.
DO not use the portable stand indoors or near any combustible materials,
•
couches, carpets etc.
Ensure that the electrical cable is secure and not crossing any walkways.
•

Safety Cautions: Operation

This appliance is not intended for use by persons (including children) with
•
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
INSTRUCTION MANUAL
Safety Cautions:
Infrared Space heaters
G2 1 500 R G2 1 500 L G
G2 2 000 R G2 3 000L L G
G2 3 000L R
G2 4 000 R
Models:
G2 2 000 G
G2 4 000L G
