- Page 1 MAGNEPLANAR® CC3 Instruction Manual White Bear Lake, Minnesota www.magnepan.com...
- Page 2 Magneplanar CC3 Owner's Manual 1. INTRODUCTION / GENERAL DESCRIPTION... 3 2. CARTON CONTENTS... 3 3. PACKAGING... 3 4. HOOKUP... 3 5. INSTALLATION AND PLACEMENT ... 4 A) GENERAL... 4 B) INSTALLATION IN A CABINET... 4 C) INSTALLATION USING BUILT-IN “T” NUTS... 5 D) DAMPING...
- Page 3 Loudspeaker. The Magneplanar CC3 was conceived and designed for perfectionists. The CC3 consists of a curved, two-way planar magnetic driver. Due to the elegant simplicity and ruggedness of the design, the Magneplanar CC3 Center Channel will give many years of trouble-free service.
- Page 4 CC3. Leave an empty space of about 6 inches between the rear of the CC3 and the insulation. If the speaker is placed below the TV or screen, the speaker can be tilted upward by removing the 2 existing adjustable feet. Locate the front T nut shown in the following diagrams.
- Page 5 AMPLIFICATION WARNING: The CC3 is a 4 ohm speaker. Be certain the amplifier or receiver you are using is capable of driving a 4 ohm load. If you are uncertain, call the manufacturer of the amplifier.
- Page 6 He is experienced in providing service and can assist you if the speaker must be returned to the factory. If you determine you need to return it directly to Magnepan, ship the speaker freight prepaid to: Magnepan, Incorporated...
- Page 7 1 ADJUSTABLE FOOT 1 SPEAKER EMBLEM Curved, two-way planar magnetic dipole loudspeaker 155 Sq. In. 80Hz to 20kHz +/- 3dB See FAQ on web site at http://www.magnepan.com/faq.php#power 86dB/500Hz/2.83V 4 Ohms 900Hz 36"W X 10-1/2"H X 5-1/2"D 20lbs./pair Limited 3-Year to Original Owner...
