Summary of Contents for Klipsch KI-102
- Page 1 KLIPSCH PERMANENT INSTALLATIONS KI-102 | KI-115 | KI-172 | KI-215 | KI-262 | KI-272 | KI-362 | KI-396 OWNER’S MANUAL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. READ these instructions. The lightning flash with arrowhead symbol within an equilateral 2. KEEP these instructions. triangle, is intended to alert the user to the presence of 3. HEED all warnings. uninsulated “dangerous voltage” within the product’s enclosure that 4. - Page 3 Klipsch recommends that only qualified personnel install its loudspeaker systems. In addition to the load ratings of speaker enclosure pickup points, rigging hardware and array configurations, the safety and integrity of any installation depends on the strength and suitability of the attachment location.
-
Page 4: Installation
INSTALLATION KI-102 | KI-172 The optional SB-102 accessory bracket is specifically designed for the KI-102 and KI-172 loudspeaker systems. The bracket provides up to four attachment points to the securing surface and two attachment points to the speaker. When installing the bracket, the attachement point (2”... - Page 5 The horizontal array size is limited only by the mounting location’s structural integrity. Klipsch recommends that only professional-grade rigging components, appropriately rated straight bolts and welded eye bolts are used. Additionally, safety backup straps or wirerope should be installed for added measure of rigging safety.
-
Page 6: Array Configurations
Note that their all bolts for cracks, corrosion, or any other side effects. coverage patterns are the same as the KI-102 damage which may be present. To install the and KI-262, respectively. eyebolts, remove all three retaining screws... -
Page 7: Input Connections
INPUT CONNECTIONS All KI Series speakers utilize five-way binding posts for full-range signal input connection to the built-in passive crossover. - Page 8 KI-262 | KI-272 | KI-362 External, active crossover frequency selection will be required (refer to specifications on KLIPSCH.COM/PRO for recommended frequencies). Modifying the full-range internal passive crossovers for bi-amp To convert the speaker to passive bi-amp mode, place the speaker face operation is relatively simple.
- Page 9 KI-362 VARIPOINT ADJUSTMENT The KI-362 three-way loudspeaker system provides for pattern adjustment by rotating the position of the high- and mid-frequency VariPoint module. To accomplish this, first determine the desired orientation of the Varipoint module. This should be established before the speaker is suspended.
-
Page 10: Power Requirements
3dB above the maximum speaker power ratings, or twice the published numerical power rating of the speaker. For example, the KI-102 is rated at 100 watts continuous. A 3dB continuous headroom factor would suggest a 200-watt amplifier. - Page 12 3502 WOODVIEW TRACE, INDIANAPOLIS, IN, USA KLIPSCH.COM/PRO ©2015, Klipsch Group, Inc. Klipsch Group, Inc. is a wholly-owned subsidiary of Voxx International Corporation. Klipsch and Keepers of the Sound are trademarks of Klipsch Group, Inc., registered in the United States and other countries. V01 - 0511...
