- Page 1 INSTRUCTIONS FOR INSTALLATION, USE AND CARE OF WATER HEATERS EZV 5 and 10 litres...
- Page 2 CONTENTS TECHNICAL INFORMATION.............3 INSTALLATION .................3 CONNECTION TO WATER SUPPLY............5 STEPS FOR CONNECTION TO WATER SUPPLY.........6 CONNECTION TO POWER SUPPLY...........7 USE AND MAINTENACE..............7 WASTE DISPOSAL................8...
- Page 3 TECHNICAL INFORMATION Low capacity electrical water heaters are designed as open system without pressure. Water heaters are made according to valid standards and tested and certified by authorized laboratory. The appliance is not meant for persons (including children) of reduced psychophysical abilities, unless under supervision of per- sons responsable for their safety, i.e.
- Page 4 Since they work as open system, hot water can be used only in one place. Technical characteristics of low capacity water heater: Type EZV 10 EZV 5 Model EZV 10N EZV 10P EZV 5N EZV 5P Capacity (litres) Nominal pressure (Mpa) Weight when full of water (kg)
- Page 5 Pict. 3 Connection and installation measures: TYPE EZV 10 EZV 5 Model EZV 10N EZV 10P EZV 5N EZV 5P A(mm) B(mm) C(mm) D(mm) E(mm) F(mm) CONNECTION TO WATER SUPPLY Input for cold water on the water heater is marked with blue ring while hot water output is marked with a red ring, which is to be respected when connecting water heater to water supply.
- Page 6 If regular water pressure in the pipeline is higher than 0,6 Mpa (6 bar) a reduction valve has to be mounted on the cold water inlet connection. No device functioning with water should be installed to the water heater output (dispenser, mash...) neither pipe longer than 1,2 m, as it would increase pressure inside the tank and damage it.
- Page 7 Low installation scheme C.W. 1 interlocking valve 2 reduction valve H.W. 3 Non-return valve 4 Mixing unit /pipe CW cold water HW hot water Pict. 4 CONNECTION TO ELECTRIC POWER SUPPLY Low capacity water heater is connected to power supply only if tank is previously filled with water.
- Page 8 fied and left for recycling or final disposal according to loacal regulations. Only by waste separation and management you will protect the environment. Metalac Bojler Ljubicska 1, 32300 Gornji Milanovac, Serbia T. +381 32 717 432, 712 818 F. + 381 32 712 818 E.
