Page 1: Instructions For Installation
INSTRUCTIONS FOR INSTALLATION, USE AND CARE OF WATER HEATERS STANDARD MB 30, 50, 80 lit. STANDARD MB 80 H, PRAKTIK MB 50, 80, 100, 120 lit. PRAKTIK MB 50, 80, 100, 120 lit. Inox PRAKTIK MB PK 80,120 lit. PRAKTIK MB PK 80, 120 lit. Inox... -
Page 2: Table Of Contents
CONTENTS Technical information..............3 Installation..................4 Connection to water supply............8 Connection to power supply............9 Use, control and maintenace of electrical water heaters.....10 Waste disposal ................11... -
Page 3: Technical Information
TECHNICAL INFORMATION Electrical accumulation water heaters are designed to work with pressure of the water supply pipeline. The appliance is not meant for persons (including children) of reduced psychophysical abilities, unless under supervision of persons responsable for their safety, i.e. for persons not skilled for use of the appliance. -
Page 4: Installation
2 or 4 screws of 8 mm minimum diameter. Thin and delicate walls should be reinforced prior to water heater installation Technical characteristics of accumulation water heater: Model Standard MB 30 Standard MB 50 Standard MB 80 Capacity (litres) Nominal pressure (Mpa) - Page 5 Model Slim MB 30 Slim MB 50 Slim MB 80 Capacity (litres) Nominal pressure (Mpa) 16/46 21/71 29/109 Weight when full of water (kg) Corrosion protection Enamelled Enamelled Enamelled type Mg anode Mg anode Mg anode Heater power (W) 2000 2000 2000 Voltage...
- Page 6 Connection and installation measures: NN U Picture 2 Model (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) STANDARD MB 30 130-360 STANDARD MB 50 130-360 MB STANDARD 80 1004 130-360 PRKTIK MB 50 130-360 PRKTIK MB 80 130-360 PRKTIK MB 100...
- Page 7 WALL SIDE VIEW A (mm) B (mm) C (mm) 0 (mm) E (mm) L (mm) MB 80 H 1004 STANDARD Left water heater MB 80 HL Right water heater MB 80 HD Horisontal water heaters could be mounted as left or right depend- ing on the position of the thermoregulator, and this models are designed to be mounted only on wall (not ceiling ) , so pipes are toward floor.
-
Page 8: Connection To Water Supply
CONNECTION TO WATER SUPPLY Input of cold water for electrical water heater is marked with blue ring, while hot water output is marked with red ring, which is to be respected when connecting water heater to water supply. Accumula- tion heater works under preassure (closed system) and it is possible to use water at more than one point in the house. -
Page 9: Connection To Power Supply
The water heaters with heat exchanger are connected to water supply in the same way like regular water heaters. Water heaters with heat exchanger are ment for connection to other energy sources (central- ized heating system, solar heating and heat punps). Entrance point of heated media to the heat exchanger is marked with red, while exit is marked with blue. -
Page 10: Use, Control And Maintenace Of Electrical Water Heaters
Connection scheme for water heaters of 30-120 litres. 1. Thermoregulator 2 Heater 3 Connection clamp 4 Signal lamp L – phase N neutral Ground Picture 4 WARNING: Before any intervention the water heater must be discon- nected from the power supply line. USE, CONTROL, MAINTENANCE OF ELECTRIC WATER HEATERS After connecting it to water and power supplies the water heater is... -
Page 11: Waste Disposal
Water heaters also have thermometers with metal cap and bimetal showing the temperature of the water. If water heater will not be used for longer period it is recomanded to disconnect it from power supply line. If water inside the water heater could freeze while not used it is recomanded to empty the tank. - Page 12 Metalac Bojler Ljubićska 1, 32300 Gornji Milanovac, Srbija T. +381 32 717 432, 712 818 F. + 381 32 770 498 E. bojler@metalac.com www.metalac.com Revision 24.11.2012.god.
