OWNER´S MANUAL
EPTL
REMOTE CONTROLLER
SPLIT AIR CONDITIONER
Thanks you very much for purchasing our air conditioner.
Please read this owner´s manual carefully before using
your air conditioner.
EPLT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPTL and is the answer not in the manual?

Questions and answers

Related Manuals for Ecox EPTL

Summary of Contents for Ecox EPTL

  • Page 1 OWNER´S MANUAL Thanks you very much for purchasing our air conditioner. Please read this owner´s manual carefully before using your air conditioner. EPTL REMOTE CONTROLLER EPLT SPLIT AIR CONDITIONER...

  • Page 2: Table Of Contents

    If the area where the air conditioner is going to remain idle, shut down your computer for saving energy. In unconditioned spaces should reduce the heat load introduced by excessive lighting or equipment remain on unnecessarily. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 3: Handling The Remote Control

    Use curtains to prevent the sunlight from failing on the receiver. If other electrical appliances react to the remote control, either move these appliances or consult your local dealer. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 4: Remote Control Specification

    Operating Mode: AUTO, COOL, DRY, HEAT (Cooling only model without) and FAN. Timer Setting Function in 24 hours. Indoor Setting Temperature Range 17º C ~ 30º C. Full function of LCD (liquid Crystal Display). REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 5: Features Of Remote Control Buttons

    TEMP Button : Push this button to decrease the indoor temperature setting. TEMP Button : Push this button to increase the indoor temperature setting. MODE Selection Button: Each time the button is pressed, the operation mode is shifted in the direction of the arrow. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...
  • Page 6 Press it again to cancel. This function is only can be used on COOL, HEAT and AUTO mode and maintain the most comfortable temperature for you. NOTE While the unit is running under SLEEP mode, it would be cancelled if ON/OFF, FAN SPEED, SLEEP or MODE button is pressed REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 7: Indicators On Display Panel

    TEMP. / TIMER DISPLAY Indicator: The temperature setting (from 17ºC to 30ºC) or timer setting (0-24h) will be displayed. If FAN mode is selected, there will be no display. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 8: Auto Operation

    Once you select the operating mode, the operating conditions are saved in the unit's microcomputer memory. Thereafter, the air conditioner will start operating under the same conditions when you simply push the ON/OFF button of the remote control. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 9: Cool / Heat / Fan Operation

    The OPERATION Indicator on the display panel of the Indoor unit illuminates. The operating mode is selected on accordance with the room temperature and operation starts after approximately 3 minutes (If you select FAN mode. The unit will start immediately). REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 10: Dry Operation

    COOL or FAN mode. To press the TIMER ON button can set the auto-on time of the unit. To press the TIMER OFF button can set the auto-off time of the unit. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...
  • Page 11 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13,14, 15, 16, 17, 18, 19, 20, 21, 22, 23 and 24. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 12: Example Of Timer Setting

    Start operation) This feature is useful when you want to stop the air conditioner after you go to bed, and start it again in the morning when you wake up or when return home. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...
  • Page 13 If the same time is set for both TIMER ON and TIMER OFF settings no timer operation is performed. The air conditioner may stop operating, either immediately or after approximately 10 minutes. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 14: Sleep Button Function

    When press this button once and quickly, the air flow direction setting feature of the louver is activated. The moving angle or the louver is 6" for each press. Keep pressing the DIRECTION/SWING button to move the louver to the desired position. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...

  • Page 15: Cautions

    Protect the Remote Control from high temperatures and exposure to radiation. Keep the indoor receiver out of direct sunlight or the air conditioner may malfunction. Keep control away from EMI (Electro-Magnetic Interference) supplied by other household appliances. REMOTE CONTROLLER EPTL SPLIT AIR CONDITIONER...
