Quick Start

Using the Override Button
Unoccupied Operation - During programmed, unoccupied periods, pressing the
OVERRIDE button will force the thermostat into Occupied 1 settings for 30 minutes.
Each press of the OVERRIDE button will add another 30 minutes of time for up to 4
hours. If the maximum time has been set, the next press of the OVERRIDE button
will reset the timer and return the thermostat to the correct time period program for the
day.
Occupied Operation - During programmed, occupied periods, pressing the OVER-
RIDE button will force the thermostat into an unoccupied period for the rest of the day.
During this forced unoccupied period the OVERRIDE button will operate as described
above.
Viewing the Outdoor and Remote Temperature Sensors
OUTDOOR TEMP - Press the OUTDOOR
button to view the current outdoor temperature.
The high and low temperatures for the day will
also be displayed. The high and low temperatures reset at 12:00 am.
REMOTE TEMP - Pressing the OUTDOOR button once will display the current
outdoor temperature. Press the OUTDOOR button again to display POOL or SPA
temperature sensors. Each press of the OUTDOOR button will display a different
installed sensor. Keep pressing the OUTDOOR button to return to normal operation.
Note: If no outdoor sensor is connected, 2 dashes [- -] will appear with
the first button press.
Viewing the Indoor Humidity Sensor*
IMPORTANT: Allow at least 2 minutes after the thermostat
is powered on for the humidity to read correctly.
Press the HUMIDITY button t o display the current humidity measured at
the thermostat. The room relative humidity is displayed in the top left corner. The
humidification setpoint appears in the larger center display and can be adjusted using
the WARMER or COOLER buttons. Press the HUMIDITY button again to view and
adjust the dehumidification setpoints.
settings and return to normal operation.
Note: Due to variations in environmental conditions, it is not always
possible to achieve the desired humidification or dehumidification
setpoint.
NOTE: Override may only be
OVERRIDE
used when the thermostat is
set to PROGRAM ON.
(This feature not available on all models)
Press the HUMIDITY button again to confirm
