  • Page 1 LED Flood Panel7x3W LED floodlight user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 17.08.2015, ID: 253406...

  • Page 3: Table Of Contents

    1.3 Symbols and signal words....................... 8 Safety instructions..........................10 Features............................... 15 Installation..............................16 Starting up..............................20 Connections and operating elements................... 23 Operating..............................26 7.1 Starting the device........................... 26 7.2 Main menu............................26 7.3 Menu overview..........................33 Technical specifications........................41 LED Flood Panel7x3W...
  • Page 4 Table of contents Plug and connection assignments....................42 Troubleshooting............................43 Cleaning............................... 45 Protecting the environment......................46 LED floodlight...

  • Page 5: General Notes

    If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. LED Flood Panel7x3W...

  • Page 6: Further Information

    General notes 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    References to other locations in this manual are identified by an arrow and the specified page number. In the electronic version of the manual, you can click the cross-reference to jump to the specified location. Example: See Ä ‘Cross-references’ on page 7. LED Flood Panel7x3W...

  • Page 8: Symbols And Signal Words

    General notes 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
  • Page 9 General notes Warning signs Type of danger Warning – high-voltage. Warning – suspended load. Warning – danger zone. LED Flood Panel7x3W...

  • Page 10: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 11 Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. LED Flood Panel7x3W...
  • Page 12 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
  • Page 13 Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. LED Flood Panel7x3W...
  • Page 14 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 15: Features

    Special features of the device: 7 × tri-colour LEDs, 3 W each Control via DMX (3, 4 or 8 channels) and via buttons and display on the unit Automatic mode and sound control Master / Slave mode Robust metal housing LED Flood Panel7x3W...

  • Page 16: Installation

    Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 17 Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. LED Flood Panel7x3W...
  • Page 18 Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. Mounting options You can install the unit in hanging or standing position.
  • Page 19 Installation Please note that this device must not be connected to a dimmer. LED Flood Panel7x3W...

  • Page 20: Starting Up

    Starting up Starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. LED floodlight...
  • Page 21 Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). LED Flood Panel7x3W...
  • Page 22 Starting up Connections in master/slave When you configure a group of devices in master/slave mode, the first unit will control the mode other units for an automatic, sound-activated, synchronized show. This function is ideal when you want to start a show immediately. Connect the DMX output of the master device to the DMX input of the first slave device.

  • Page 23: Connections And Operating Elements

    Connections and operating elements Connections and operating elements Top side 1 Display. 2 [Mode] Calls the main menu or a submenu. 3 [Setup] Confirms a selected value. 4, 5 [Up], [Down] To increase / decrease the displayed value by one. LED Flood Panel7x3W...
  • Page 24 Connections and operating elements Rear panel LED floodlight...
  • Page 25 IEC chassis socket for the power supply cable to the next unit. 8 Locking screws for the mounting brackets. 9 [DMX Out] DMX output. 10 [DMX In] DMX input. 11 Bracket for floor placement or hanging. 12 Safety eyelet. LED Flood Panel7x3W...

  • Page 26: Operating

    Operating Operating 7.1 Starting the device Connect the device to the power supply to start operation. After a few seconds, the display indicates that a reset is in progress. The device is then ready for use. 7.2 Main menu Press [MODE] to activate the main menu and select an operating mode. Use the buttons [Up] and [Down] to change the respectively indicated value.
  • Page 27 Highest possible DMX address 3-channel 4-channel 8-channel Confirm with [Setup]. With the buttons [Up] and [Down] you can now select one of the fol‐ lowing DMX operating modes: ‘3-ch’ (three channels) ‘4-ch’ (four channels) ‘8-ch’ (eight channels) LED Flood Panel7x3W...
  • Page 28 Operating This setting is only relevant if the device is controlled via DMX. When the display shows the desired value, press [Setup] to confirm the selection and then [Mode] to return to the parent menu. To return to the parent menu without making changes, press [Mode]. LED floodlight...
  • Page 29 Fast transition, all colours Pr.05 Fast transition, three colours Pr.06 Random programme 1 Pr.07 Random programme 2 Pr.08 Slow transition bright / dark, red Pr.09 Slow transition bright / dark, green Pr.10 Slow transition bright / dark, blue LED Flood Panel7x3W...
  • Page 30 Operating The auto show can only be activated on the device that works as master. This setting is only relevant if the device is not controlled via DMX. The device can operate in stand-alone mode or control connected devices of the same type, that must be configured as slaves.
  • Page 31 Confirm again with [Setup]. In the following menu, you can use the [Up] and [Down] buttons to set the strobe speed for the various hues in a range from ‘FS00’ to ‘FS99’ . LED Flood Panel7x3W...
  • Page 32 Operating Settings programme Pr.02 … Pr. For programmes ‘Pr.02’ to ‘Pr.01’ , you can additionally set the speed for the transition from one hue to the next. Use the buttons [Up] and [Down] to select a value between ‘slow’ and ‘fast’...

  • Page 33: Menu Overview

    Operating 7.3 Menu overview LED Flood Panel7x3W...
  • Page 34 Operating 7.3.1 Functions in 3-channel DMX mode Channel Value Function 0…255 Intensity Red (0 % to 100 %) 0…255 Intensity Green (0 % to 100 %) 0…255 Intensity Blue (0 % to 100 %) 7.3.2 Functions in 4-channel DMX mode Channel Value Function...
  • Page 35 Intensity Red (0 % to 100 %), if channel 6 = 0 Constant hue, if channel 6 = 1…24 0…8 Red: 255 9…17 Red: 255, Green: 50 18…26 Red: 255, Green: 150 27…35 Red: 255, Green: 255 36…44 Red: 200, Green: 255 LED Flood Panel7x3W...
  • Page 36 Operating Channel Value Function 45…53 Red: 100, Green: 255 54…62 Red: 40, Green: 255 63…71 Green: 255 72…80 Green: 255, Blue: 50 81…89 Green: 255, Blue: 150 90…98 Green: 255, Blue: 255 99…107 Green: 150, Blue: 255 108…116 Green: 50, Blue: 255 117…125 Blue: 255 126…134...
  • Page 37 225…233 Red: 220, Green: 100, Blue: 50 234…242 Red: 220, Green: 200, Blue: 100 243…251 Red: 255, Green: 200, Blue: 150 252…255 Red: 255, Green: 255, Blue: 255 Process speed, if channel 6 = 25…249 0…255 Slow…fast LED Flood Panel7x3W...
  • Page 38 Operating Channel Value Function Response characteristic in music operation, if channel 6 = 250…255 0…255 Low (0) to high (255) Channel 6 = 0 Intensity Green 0…255 (0 % to 100 %) Channel 6 = 1… Without function Channel 6 = 0 Intensity Blue 0…255 (0 % to 100 %) Channel 6 = 1…...
  • Page 39 Pr.08 (slow transition bright / dark, red) 200…224 Pr.09 (slow transition bright / dark, green) 225…249 Pr.10 (slow transition bright / dark, blue) 250…255 Sound control Control of all devices that use the same DMX address 0…9 All IDs 10…19 20…29 … LED Flood Panel7x3W...
  • Page 40 Operating Channel Value Function 200…209 ID20 ID21 ID22 … ID66 0…250 Fast response faders 1, 2, 3 and 4 251…255 Delayed response faders 1, 2, 3 and 4 LED floodlight...

  • Page 41: Technical Specifications

    100 V … 240 V (AC), 50/60 Hz Power consumption 30 W Fuse 5 mm × 20 mm, 1 A, slow-blow Dimensions (W × H × D) 300 mm × 200 mm × 60 mm Weight 2.6 kg LED Flood Panel7x3W...

  • Page 42: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 43: Troubleshooting

    Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: LED Flood Panel7x3W...
  • Page 44 Troubleshooting Symptom Remedy The unit does not work, no Check the mains connection and the fuse. light. No response to the DMX con‐ 1. Check the DMX ports and cables for proper connection. troller. 2. Check the address settings and the DMX polarity. 3.

  • Page 45: Cleaning

    The fan grids of the device must be cleaned on a regular basis to remove dust and dirt. Before cleaning, switch off the device and disconnect AC-powered devices from the mains. Use a lint- free damp cloth for cleaning. Never use solvents or alcohol for cleaning. LED Flood Panel7x3W...

  • Page 46: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 48 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
