- Page 1 USER GUIDE TONEDEQ | AFX...
-
Page 2: Important Safety Information
NOTE: Fishman Transducers, Inc. is not responsible for unauthorized equipment modifi- cations that could violate FCC rules, and/ or void product safety certifications. EU Declaration of Conformity CE: Hereby, Fishman declares that this ToneDEQ is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. -
Page 3: Quick Start
Welcome Thank you for making Fishman a part of your acoustic experience. We are proud to offer you the finest acoustic amplification products available; high-quality professional-grade tools to empower you to sound your very best. We are confident TONEDEQ | AFX will both enhance and inspire your music making. -
Page 4: Left Side Panel
Left Side Panel 9VDC Power may be supplied by either a 9V battery ( battery compartment underneath the pedal ) or the Fishman 910-R power adapter. XLR D.I. Output Connect a standard microphone cable here to feed recording equipment or a sound reinforcement mixing console. -
Page 5: Right Side Panel
(no battery onboard), always plug into this preamp pedal first, even if you use a pedal tuner. Insert a plug into the input jack, and the TONEDEQ | AFX powers up. To conserve the battery, remove the plug from the input when not in use. -
Page 6: Front Panel
Front Panel Volume The volume control affects the 1/4 inch output level only. For the cleanest signal, set the volume as high as possible without clipping the next device in the signal chain. If you hear distortion and the level light is not flashing red, reduce the volume. -
Page 7: Tone Controls
Front Panel (cont.) Tone Controls Low • Boost here to add depth and weight to the sound of the instrument. Mid • Turn all the way left for a smooth “scooped out” tone at high volumes. Raise the control to the right of center to add midrange “bite” to the sound. High •... -
Page 8: Block Diagram
Front Panel (cont.) TONEDEQ | AFX offers two independent effects processors that run in parallel with the analog preamp, compressor and EQ circuits to reduce the effect of coloration on your instrument’s sound. Reverb & Delay Effects Time • Sets the overal “length” of the reverb or delay effect. -
Page 9: Chorus Effects
Front Panel (cont.) Chorus Effects Rate • Sets the speed (rate) or intensity of the selected effect. Level • The level control mixes the effect in parallel, adding as much or as little effect into your direct sound. Effects: • Chorus 1 •... -
Page 10: Technical Specifications
Typical in-use current consumption: 37mA (62mA max.) Typical 9V battery life: 12 hours using alkaline battery 18 hours using lithium battery) 9V adapter: Fishman 910-R or suitable filtered and regulated, 200mA type, tip = negative Tone Controls: Low cut: 40Hz, 80Hz, 160Hz Low control: ±14dB @ 100Hz... - Page 12 Fishman and Fishman Transducers are trademarks or tradenames of FISHMAN TRANSDUCERS, Inc. 513-300-199 Rev 2 9-15...
