- Page 1 Touch 2 WiFi...
- Page 2 Model: Touch 2 WiFi Touch 2 WiFi...
-
Page 3: Table Of Contents
Re-calibrating the Thermostat Mode Select Error Codes Pairing the Touch 2 Hub 28-31 Thermostat Mode Wiring Diagrams Pairing the Touch 2 WiFi Factory Reset What is a Mesh Network? Mode 2 - Time Clock Mode 1 - Thermostat LCD Display... -
Page 4: What Is A Programmable Room Thermostat
How quickly the room heats up depends on the design and size of the heating system. down. Setting a programmable room thermostat to a lower temperature will result in the room being controlled at a lower temperature, and saves energy. Touch 2 WiFi... - Page 5 You are able to temporarily adjust the heating program by overriding or using the temperature hold feature. These features are explained further on pages 17 and 18 of this manual. so they must not be covered by curtains or blocked by furniture. Nearby electric properly. Touch 2 WiFi...
-
Page 6: Installation Procedure
Do not push hard on the LCD screen as this may cause irreparable damage. This Touch 2 WiFi is designed to be ush mounted and requires a back box of 35mm (minimum depth) to be sunk into the wall prior to installation. - Page 7 Touch 2 WiFi...
-
Page 8: Mode Select
Mode Select This Touch 2 WiFi can either be used as a thermostat or a time clock. Thermostat mode is the default setting. To change between thermostat or time clock modes, follow these steps. • Use the Left / Right keys to scroll to SETUP ............... -
Page 9: Pairing The Touch 2 Hub
• When successfully connected, enter a title for the new location (e.g. Home) and Pairing the Touch 2 WiFi The next step is to join the Touch 2 WiFi to the Touch 2 Hub, we recommend joining the Touch 2 WiFi located nearest to the Touch 2 Hub first. -
Page 10: What Is A Mesh Network
• Press the Tick key to pair the Touch 2 WiFi to the Touch 2 Hub ...... • • When the Touch 2 WiFi successfully connects to the Touch 2 Hub the MESH symbol will be permanently displayed. • Press Next to add more zone or press Finish to complete the setup. -
Page 11: Mode 1 - Thermostat
Mode 1 - Thermostat Touch 2 WiFi... - Page 12 MORNING DAY EVENING NIGHT DONE Touch 2 WiFi...
-
Page 13: Lcd Display
Cool On - Displayed when cooling is active. Clock - Time displayed in 24 hour format. Holiday Left - Displayed when the thermostat is in holiday mode. Hold Left - Displayed when a temperature hold is active, the remaining time will be shown. Touch 2 WiFi... -
Page 14: Temperature Display
“Room Temp” or “Floor Temp” before the actual temperature value. Room Temperature Floor Temperature When the Touch 2 WiFi is set to use both the air & the floor sensor, the room temperature will be dispalyed by default. Touch 2 WiFi... -
Page 15: Setting The Clock
Use the Up / Down keys to set the hours (24 hour format) ......• • Use Up / Down keys to set the minutes ..............• • Use Left / Right keys to set the the day ..............• Hours Minutes Touch 2 WiFi... -
Page 16: Comfort Levels Explained
Comfort Levels Explained The Touch 2 Wifi o ers three program mode options; Weekday/Weekend programming, 7 Day programming and 24 Hour programming. There is also the option to use the thermostat as a Non-Programmable thermostat. When thermostats are connected to the mesh network, the program mode for the system is con gured by using the Myson Touch 2 App. - Page 17 Press Tick to alter DAY settings ..................• Repeat these steps to set all comfort levels. --:-- • For any unused periods set time to • Use the Left / Right keys to scroll to DONE and press Tick ....... Touch 2 WiFi...
-
Page 18: Temperature Control
Press Tick to and return to the main display ........Set Temperature Set Icon Note: This new temperature is maintained only until the next programmed comfort level. At this time, the thermostat will revert back to the programmed levels. Touch 2 WiFi... -
Page 19: Temperature Hold
You will see the HOLD LEFT indication is displayed on screen. The time will countdown the set duration and then revert to the normal program. HOLD LEFT Indicator Hold Time Remaining To cancel a temperature Hold, repeat these steps but reduce the Hold time to 00:00 hrs. Touch 2 WiFi... -
Page 20: Locking/Unlocking The Touch 2 Wifi
Note: The keypad lock indicator is only displayed when the lock is active. Unlocking the Touch 2 Wifi To unlock the Touch 2 Wifi press Tick once. The display will show 00:00 and you will need to enter the four digit pin number you set previously. - Page 21 The frost icon will toggle ON/OFF each time Tick is pressed ..........In this mode, the Touch 2 Wifi will display the frost icon and will only turn the heating ON should the room temperature drop below the set frost temperature (see page 23).
- Page 22 Touch 2 Wifi remains active. To turn the Touch 2 Wifi off completely, scroll to the Power Icon and hold the Tick key for approximately 4 seconds until the display goes blank ....The display and heating output will be turned OFF.
- Page 23 Note: A holiday period does not start until 00:00 the next day. For example, if you set thermostat will revert back to the programmed schedule at 00:00 on Monday. To cancel, repeat these steps but reduce the Holiday duration to 00 days. Touch 2 WiFi...
- Page 24 This limit is also applicable when the thermostat is locked and so allows you to give others limited control over the heating system. Feature 06 – Sensor Selection: On this Touch 2 Wifi, you can select which sensor should be used. Touch 2 WiFi...
- Page 25 7 Day Program Mode - Each day has 4 comfort levels that can be programmed independently. 24 Hour Mode - All days are programmed the same and repeat continuously. Feature 13 - Temperature Format: This function allows you to select between °C and °F. Touch 2 WiFi...
-
Page 26: Adjusting The Optional Settings
Use the Left / Right keys to select SETUP .............. • .................. Feature Number Setting Value • Use the Up / Down keys to scroll through features .......... • Use the Left / Right keys to adjust the setting within each feature ... • Touch 2 WiFi... -
Page 27: Frost Protection
Cool Set Temperature Not Used Program Mode 00 = Non - Programmable 01 = Weekday/Weekend (Default) 02 = 7 Day Programming 03 = 24 Hour Mode Temperature Format 00 = C, 01 = F (00 = Default) Touch 2 WiFi... -
Page 28: Re-Calibrating The Thermostat
The remote FLOOR probe has not been wired correctly. The remote FLOOR probe is faulty. E2 = The remote AIR probe has not been connected. The remote AIR probe has not been wired correctly. The remote AIR probe is faulty. Touch 2 WiFi... - Page 29 Wiring Diagram - Touch 2 WiFi to Boiler S/L Touch 2 WiFi 230VAC TO CONNECT BOILER CONSULT BOILER MAKERS DIAGRAM LIVE 230V SUPPLY IN SWITCHED LIVE TO BOILER NEUTRAL and comply with local installation regulations. Touch 2 WiFi...
- Page 30 Wiring Diagram - Touch 2 WiFi to Boiler Voltfree Touch 2 WiFi 230VAC TO CONNECT BOILER CONSULT BOILER MAKERS DIAGRAM VOLT FREE TO BOILER LIVE 230V SUPPLY IN LS & LR ARE NORMALLY THE NEUTRAL ROOM THERMOSTAT CONNECTIONS and comply with local installation regulations.
-
Page 31: Wiring Diagram
Wiring Diagram - Touch 2 WiFi to Valve Touch 2 WiFi 230VAC TO CONNECT BOILER CONSULT BOILER MAKERS DIAGRAM LIVE 230V SUPPLY IN NEUTRAL TO BOILER NEUTRAL LS & LR ARE NORMALLY THE HEATING VALVE ROOM THERMOSTAT CONNECTIONS and comply with local installation regulations. - Page 32 TC-M Wiring Diagram Touch 2 WiFi to UFH Wiring Centre 230V & optional probe connections 230VAC Touch 2 WiFi 230VAC TC-M R PROBE nal) 230VAC FLOOR PROBE REMOTE AIR PROBE (Optional) (Optional) FLOOR PROBE REMOTE AIR PROBE (Optional) (Optional) This product must only be installed by a qualified electrician Zone 1 and comply with local installation regulations.
-
Page 33: Factory Reset
The thermostat will revert to the main display screen for the selected mode. Note: Factory reset will cancel all parameters that were entered during the set-up and pairing operations. These processes must be repeated after factory reset is completed. Touch 2 WiFi... -
Page 34: Mode 2 - Time Clock
Mode 2 - Time Clock Touch 2 WiFi... -
Page 35: Lcd Display
Timer Status – Displays the current state of the timed output. Clock - Time displayed in 24 hour format. Holiday Left – Displayed when the thermostat is in holiday mode. Hold Left – Displayed when a temperature hold is active, the remaining time will be shown. Touch 2 WiFi... -
Page 36: Setting The Switching Times
Press the Right arrow key .................... • • Repeat the steps above to set all periods. For any unused periods enter -- : -- • When complete, use the Left / Right keys to scroll to DONE and press Touch 2 WiFi... -
Page 37: Timer Override
To override the timed output on, follow these steps. • Use the Up / Down keys to set the override duration e.g. 02:00 hours ..• Hold Left and the remaining time will now be displayed. HOLD LEFT Indicator Hold Time Remaining Touch 2 WiFi... -
Page 38: Optional Features
Optional Features Explained Feature 01 – Pairing To Touch 2 Wifi: This function is used to connect the time clock to the Touch 2 Hub. Feature 02 - Weekday/Weekend (5/2), 7 Day Programming or 24 Hour Mode: Weekday/ Weekend (5/2) 7 Day Program Mode programmed independently. - Page 39 Wiring Diagram - Time Clock Mode Touch 2 WiFi 230VAC VOLT FREE OUTPUT LIVE 230V SUPPLY IN NEUTRAL FOR 230V OUTPUT ON A2 LINK LIVE TO A1 and comply with local installation regulations. Touch 2 WiFi...
- Page 40 Want More Information? Call our support team on: +44 (0)845 402 3434 www.myson.co.uk MYSON Eastern Avenue, Team Valley, Gateshead, Tyne & Wear NE11 0PG, UK T: +44 (0)845 402 3434 F: +44 (0)191 491 7568 sales@myson.co.uk www.myson.co.uk Series...
