  • Page 1 ZhongLi ZL2200 Bar Code Scanner User’s Guide...
  • Page 2 The information in this publication does not represent a commitment on the part of Youjie. Youjie shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

  • Page 3: Table Of Contents

    Table of Contents Introduction ..................... 1 Components ..................... 1 Maintenance ..................... 1 Caution and Serial Number Labels ..............2 Scanner Operation Audible Indicators ..................... 4 Visual Indicators ....................5 Failure Modes ....................6 Typical Depth of Field ..................6 Troubleshooting Guide ................7 Design Specifications ................
  • Page 4 UPC/EAN Formatting ..................18 Code Bytes Usage Code Bytes 0-9 ....................20 Code Type Table .................... 21 ASCII Reference Table................... 22 Technical Assistance ................27 Limited Warranty ................... 28...

  • Page 5: Introduction

    Introduction Components Item No. Description Red Output Window (Laser Aperture) Trigger Cable (undetachable) Beeper Hole LED Indicator (see page 5) Figure 1. Scanner Components Maintenance Smudges and dirt on the unit’s window can interfere with the unit’s performance. If the window requires cleaning, use only a mild glass cleaner containing no ammonia.

  • Page 6: Caution And Serial Number Labels

    Caution and Serial Number Labels Item Number, Serial Number and Compliance Information location Figure 2. Label Location on the Bottom of the Scanner...

  • Page 8: Scanner Operation

    Scanner Operation Audible Indicators When the scanner is operational, the scanner provides audible feedback to indicate the status of the scanner and the last scan. Eight settings are available for the tone of the beep (normal, six alternate tones and no tone). One Beep –...

  • Page 9: Visual Indicators

    Visual Indicators The scanner is equipped with a red LED and green LED, which indicate the scanner’s state and the status of the current scan respectively when the unit is in operation. Figure 3. LED Location Green and Red LEDs Are Off The LEDs will not be illuminated if the scanner is not receiving power from the host or transformer.

  • Page 10: Failure Modes

    Failure Modes One Razzberry Tone – On Power Up This indicates the scanner has experienced a laser or flipper subsystem failure. Return the unit for repair to an Authorized Service Center. Continuous Razzberry Tone with no LEDs If, upon power up, the scanner emits a continuous razzberry tone, then the scanner has an experienced an electronic failure.

  • Page 11: Troubleshooting Guide

    Troubleshooting Guide The following guide is for reference purposes only. Contact a customer service representative to preserve the limited warranty terms. Symptoms Possible Causes Solution All Interfaces No power is being Check the transformer, the outlet supplied to the and power strip. Make sure the unit.
  • Page 12 Symptoms Possible Causes Solution UPC/EAN, Code 39, interleaved 2 The unit powers The unit is trying to of 5, Code 93, Code 128 and up, but does not scan a particular Codabar are enabled by default. scan and/or symbology that is not Verify the type of bar code being beep.

  • Page 13: Design Specifications

    Design Specifications Operational Light Source: Visible Laser Diode (VLD) @ 650 nm Laser Power: Less than 1.0 mW average 17 mm – 232 mm 0.33 mm (13 mil) UPC-A Depth of Scan Field: (0.7" – 9.1") Bar Code Scan Speed: 72 ±...
  • Page 14 Electrical Input Voltage: 5VDC +/- 0.2V (USB port) Operating Power: Standby: 700 mW Decoding USB: 1000 mW Operating Current: Standby: 140 mA average @ 5VDC Decoding USB: 200 mA average @ 5VDC Environmental Operating: 0°C to 40°C (32°F to 104°F) Temperature: Storage: -40°C to 60°C (-40°F to 140°F)

  • Page 15: Configuration Introduction

    Configuration Introduction Your new scanner has been factory configured with a set of default parameters. Since many host systems have unique formats and protocol requirements, a wide range of configurable features that may be selected using this bar code based configuration tool are provided. Once the configuration is completed, the scanner stores the settings in nonvolatile memory (NOVRAM).

  • Page 16: Returning To Factory Defaults

    Returning to Factory Defaults Scan the Recall Defaults bar code to erase all previous settings and return the scanner to its factory default communication protocol. Recall Defaults ³...

  • Page 17: Code Types And Decode Rules

    Code Types and Decode Rules Bar code descriptions marked with an asterisk ( * ) define a feature that is a factory default. Bar codes marked with a tilde ( ~ ) require the Multi-Code configuration method. 2 of 5 Codes Additional Decode Features ~ Minimum Symbol Length –...

  • Page 18: Supplements

    Supplements Enable Bookland (979) Supplement Required ³ * Disable Bookland (979) Supplement Required ³ Enable Bookland (978) Supplement Required ³ * Disable Bookland (978) Supplement Required ³ Enable 977 (2 Digit) Supplement Required – The scanner will require a 2 digit supplement to be ³...

  • Page 19: Redundant Scans

    Scanner Operation Redundant Scans * 0 Redundant Scans – Requires 1 good decode for a good scan. ³ 1 Redundant Scan – Requires 2 consecutive decodes of the same bar code data for a good ³ scan. Data Transmission Delays Use these codes to select the amount of delay between sending data characters from the scanner to the host.

  • Page 20: Prefixes/Suffixes

    Prefixes/Suffixes Scan the Enter Configuration Mode bar code before trying to set these features (see the Multi-Code Method on page 11.) User Configurable Prefixes, All Data ~ Configurable Prefix Character #1 – A prefix ID can be added and assigned for data transmission. ³...

  • Page 21: User Configurable Suffixes, All Data

    User Configurable Suffixes, All Data Note: Scan the Enter/Exit Configuration mode code before trying to set this feature. Refer to Multi-Code Method on page 11. ~ Configurable Suffix Character #1 – A suffix ID can be added and assigned for data ³...

  • Page 22: Code Formatting

    Code Formatting UPC/EAN Formatting * Transmit UPC-A Check Digit ³ Do Not Transmit UPC-A Check Digit ³ Transmit UPC-E Check Digit ³ * Do Not Transmit UPC-E Check Digit ³ Expand UPC-E to 12 Digits – Expand UPC-E bar codes to the 12 digit equivalent, UPC-A bar codes. ³...
  • Page 23 Transmit Lead Zero on UPC-E – This option will transmit a zero before each UPC-E bar code. ³ Do Not Transmit Lead Zero on UPC-E ³ Convert EAN-8 to EAN-13 – The scanner will transmit five zeros before the bar code to convert ³...

  • Page 24: Code Bytes 0-9

    Code Bytes Usage The scanner must be in Configuration Mode for the features requiring code bytes for configuration. The Enter/Exit Configuration Mode bar code must be scanned before starting the configuration cycle. User configurable prefix/suffix characters can then be saved by scanning the 3 digit decimal equivalent of the ASCII character into the appropriate character location with the code byte bar codes.

  • Page 25: Code Type Table

    Code Byte 8 ³ Code Byte 9 ³ Code Type Table Code Byte Code Types UPC-A UPC-E EAN-8 EAN-13 Code 39 Codabar Interleaved 2 of 5 Code 128 Code 93 MSI Plessey Code 11 Airline 2 of 5 (15 digits) Matrix 2 of 5 Telepen UK Plessey...

  • Page 26: Ascii Reference Table

    ASCII Reference Table Decimal Value/ Control HEX Value Character Code Byte Value Keyboard Eqv...
  • Page 27 Decimal Value/ Control HEX Value Character Code Byte Value Keyboard Eqv space,blank “ & ‘ apostrophe comma minus period number zero number one...
  • Page 28 Decimal Value/ Control Keyboard HEX Value Character Code Byte Value < less than > greater than shift P letter l letter O...
  • Page 29 Decimal Value/ Control Keyboard HEX Value Character Code Byte Value shift K shift L shift M à,shift N , shift 0, underscore ‘ accent grave...
  • Page 30 Decimal Value/ Control HEX Value Character Code Byte Value Keyboard Eqv vertical slash alt mode (alt mode) delete, rubout...

  • Page 31: Technical Assistance

    Technical Assistance Contact information for technical support, product service, and repair can be found at www.youjieaidc.com.

  • Page 32: Limited Warranty

    Period to Youjie factory or authorized service center for inspection. No product will be accepted by Youjie without a Return Materials Authorization, which may be obtained by contacting Youjie. In the event that the product is returned to Youjie or its authorized service center within the Warranty Period and Youjie...
  • Page 33 This includes but is not limited to: cables, power supplies, cradles, and docking stations. Youjie extends these warranties only to the first end-users of the products. These warranties are non-transferable.
  • Page 34 ZL2200-UG Rev A 1/14...
