Summary of Contents for Eyecon EC2150 Crossfire

  • Page 1 Model eC2150...

  • Page 2: Table Of Contents

    IteMs RequIRed foR staRtup ..............3 CaMeRa dIagRaMs ..................4-5 BatteRy InstallatIon .................6 MeMoRy CaRd InstallatIon ..............7 quICk setup ....................8 advanCed settIngs & funCtIons ............8 MountIng & fIeld setup................11 Red laseR ......................13 CaMeRa CaRe ....................13 tRouBleshootIng ..................15 WaRRanty InfoRMatIon ................16 pRoduCt RegIstRatIon CaRd ..............18 WARNING! Prolonged exposure from looking directly into any infrared light could cause cataracts or permanent retinal damage.

  • Page 3: Items Required For Startup

    • 10- AA Cell Alkaline Batteries (Sold separately) • 1- SDHC Storage Card (up to 32GB) (Sold separately) NOTE: Eyecon™ Trail Cameras can accept SD cards up to 32GB, but testing shows that maximum performance is obtained at 16GB. • 1- External SD memory card reader for viewing photos/videos. (Sold separately) • optIonal: 1 Model ECA100 Extenda-Life rechargeable lithium battery pack.

  • Page 4: Camera Diagrams

    Dual Locking CAUTION LASER RADIATION DO NOT STARE INTO BEAM Bark Biter Bark Biter Ambient Red Laser Camera Head Light Sensor* Light Locking Screw *This opening must be keep free from dust or dirt and should never be covered. PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.
  • Page 5 Dual Locking Tab SD Card Slot Unlocked Dual Locked Plus Minus Power On/Off Arrow Arrow Button Button AA Battery Compartment Lock Case Door Only Bottom of camera PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.

  • Page 6: Battery Installation

    Check your battery indicator after brand new batteries are installed, it should register full bars. If not you may have a battery in backwards. If usIng eyeCon extenda-lIfe BatteRy paCk ™...

  • Page 7: Memory Card Installation

    MeMoRy CaRd InstallatIon: to Install the sd CaRd (Sold separately) 1. To access the user interface and insert a SD card, lift up on the front of the locking latch located on top of the camera head. After the latch is disengaged, the camera head should pivot down freely.

  • Page 8: Quick Setup

    quICk setup: Your CRossfIRe will come with the following standard options already preset so that quality photos may be taken right out of the box without changing any settings. Mode: Photo BuRst: 3 photo-burst ResolutIon: 3mp delay: 10 sec If you wish to customize your own settings Battery Camera...
  • Page 9 tIMe: Use either the + or – arrows and scroll up until the “Clock” starts to To set the flash. Press the SET button and Clock will stop flashing, and either “AM” or “PM” will start to flash. Use the arrows to select the correct setting and press the SET button to move on to the “Hour”...
  • Page 10 Mode: Scroll down by pressing either the + or – arrows until the “Mode” To set the starts to flash. Press the set button until an arrow starts to flash by either Photo or Video, this determines what Mode the camera is in. Press the + or – arrows to select either the Photo or Video setting.

  • Page 11: Mounting & Field Setup

    or – arrows to select the desired Res setting. Press the set button again to lock in that setting and exit Res. You will see “Res” flashing again in the camera options column. delay: This setting selects the trigger delay at which you want to run your camera. This is the amount of time between each burst.
  • Page 12 turning it out or counter clockwise until the camera head moves freely. • Using the Laser Light, pivot the camera head until the desired location or target area is reached. Next, turn the locking screw clockwise to tighten the camera head in place.

  • Page 13: Red Laser

    MoIstuRe: Although all Eyecon™ Trail Cameras have a very durable plastic composite case which also makes them water resistant even under the most extreme weather conditions, care must be taken to prevent water damage.
  • Page 14 Like any electronic device, your Eyecon™ Trail Camera is designed with many small electronic components that are very sensitive to vibration. Failure to follow careful handling & transport may cause extreme and irreparable damage to your camera.

  • Page 15: Troubleshooting

    SDHC card we recommend that you replace the card with a new SDHC card or one from a different EYECON™ Trail Camera that you know works. This will help determine whether the problem is the SDHC card or the camera. We do recommend using cards that have been used in cameras from different manufactures and/ or different styles of cameras unless a Full Format on a PC is done to those cards.

  • Page 16: Warranty Information

    WaRRanty and RegIstRatIon Eyecon Trail Camera’s 1 Year Limited Warranty: For a period of 365 days after purchase, Eyecon Trail Cameras will, at its discretion, repair or replace this product for any reason of any defect or malfunction. This warranty is only valid if the product is used for the purpose intended and has not been tampered with and/or physically damaged in any way.
  • Page 17 4. Include a copy of your original receipt, your RA#, and a check or credit card number for $20.00 shipping/handling in the box. 5. Ship the box prepaid to: Eyecon Trail Cameras, Camera Returns, 1905 1st Ave. N., Windom, MN 56101. Make sure to put the RA# in bold letters on the outside of the box. PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.

  • Page 18: Product Registration Card

    To activate your product’s warranty, please mail in your registration card or submit it online at www.EyeconTrailCameras.com pRoduCt RegIstRatIon Product Purchased Model Number Serial Number Owner’s Name Street Address City State Zip Code E-mail Address Phone Owners Age (optional) Sex (optional) Date Purchased Purchased From (Dealer Name) How did you hear about us:...
  • Page 19 OWNER’S RECORD Product Name Model Number Serial Number Purchased From Purchased Date you Must RetuRn the CoMpleted RegIstRatIon CaRd aBove WITHIN (30) DAYS OF THE PURCHASE IN ORDER TO ACTIVATE THE LIMITED WaRRanty CoveRage. (Make sure to include date purchased on the card!) notes: Remember to activate your product’s warranty? See warranty information and registration instructions on page 16 and then complete and mail in the registration card on page 18 or submit it online at: www.EyeconTrailCameras.com...
  • Page 20 PO Box 454 • Windom, MN 56101 844-745-7723 • 507-832-8322...
