- Page 1 Model eC1500...
- Page 2 Model EC1500 User's Manual July 2015. Published by Premier Outdoor Equipment, LLC, Windom, Minnesota. © 2015 Premier Outdoor Equipment, LLC All rights reserved. PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.
-
Page 3: Table Of Contents
CaMera diagraM ............4 iteMs reqUired for startUp ........5 Battery installation ..........6 MeMory Card installation ........7 qUiCk setUp ..............8 advanCed settings & fUnCtions ......9 viewing sCreen inforMation & fUnCtions ..12 storM MoUnting & field setUp ......14 CaMera Care .............16 troUBle shooting ...........17 warranty inforMation ........20 prodUCt registration Card ........21 WARNING! Prolonged exposure from looking directly into any infrared... -
Page 4: Camera Diagram
Red Walk Ambient Test Light Sensor Camera Options SD Card Column Slot Case Door Case Door Latch (Open) Power On/Off Button Plus Arrow C-Cell Battery C-Cell Battery Set Button Minus Arrow Comparment Comparment PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY. -
Page 5: Items Required For Startup
(Sold separately) • SDHC Storage Card (up to 32GB; 4GB or higher recommended) (Sold separately) NOTE: Eyecon™ Trail Cameras can accept SD cards up to 32GB, but testing shows that maximum performance is obtained at 16GB. • 1 External SD memory card reader for viewing photos/videos. -
Page 6: Battery Installation
2. Insert (3) C-cell batteries, negative (–) side inserted first into one side. 3. Close the battery door and position lock to locked position. 4. Repeat on opposite side. if Using eyeCon extenda-life Battery paCk ™ 1. Remove plastic plug on the back side of the camera. note: Save this plug for future use. -
Page 7: Memory Card Installation
MeMory Card installation: to install the sd Card (Sold separately) 1. Open case door. 2. Insert the SD card face up into the SD Card Slot until you hear it click into place. Press it once to remove. note: It is recommended not to use a card that has been previously used in different trail cameras or one that has previously been used in a Point &... -
Page 8: Quick Setup
qUiCk setUp: Your Storm Trail Camera will come with the following standard options already preset so that quality photos may be taken right out of the box without changing any settings. Mode: Photo BUrst: 3 photo-burst resolUtion: 5 mp delay: 10 sec If you wish to customize your own settings proceed to Advanced Settings &... -
Page 9: Advanced Settings & Functions
advanCed settings & fUnCtions: Press and quickly release the power button to activate the camera and view the full color user setup screen. You will see two options on the screen: “Camera Setup” and “View Photos, ” with one of these flashing. Press either the + or – arrows until “Camera Setup” is flashing. - Page 10 Mode: Mode selects whether you would like the camera to take still photos or take video clips. Options are: Photo (still) or Video. Mode: Scroll down by pressing either the + or – arrows until a To set the black box appears around “Mode.” Press the set button until either Photo or Video appears in a white box with black letters.
- Page 11 res: This setting selects the resolution at which you would like the camera to take the pictures. A higher resolution photo requires more storage. Options are: 5MP, 7MP, or 9MP. resolUtion: Use the + or – arrows to scroll down until a black To set the box appears around the photo “Resolution”...
-
Page 12: Viewing Screen Information & Functions
viewing sCreen inforMation & fUnCtions view iMages and video: In the bottom right hand corner of the viewing screen there will be a black box which will display the total number of still images or videos on the SD card. note: In the upper right hand corner of the screen there is an icon that represents either Photo or Video. - Page 13 Delete All Files: Press the set button and scroll down using either of the + or – arrows until “Delete All Files” turns blue. Press the set button again for another screen to appear. You will be asked, “Confirm Deleting All Files. ” At this point you decide either to delete or cancel.
-
Page 14: Storm Mounting & Field Setup
storM MoUnting & field setUp The Storm comes with a 6 ft nylon mounting strap which allows for quick and easy mounting. The camera back is unique in that it has 12 vertical large bark biters and 5 different adjustment slots. This allows for several strap placement options or another strap can be added depending on your application. - Page 15 red walk test Mode: The red walk test light on your Storm is used to help determine that your camera is set at the proper height and is pointed in the right direction. The red walk test light can only be activated by a combination of heat and motion. After 90 seconds the walk test becomes inactive and will not be seen until the user wakes the camera up again.
-
Page 16: Camera Care
MoistUre: Although all Eyecon™ Trail Cameras have a very durable plastic composite case which also makes them water resistant even under the most extreme weather conditions, care must be taken to prevent water damage. -
Page 17: Trouble Shooting
Over time a sdhC or any storage device could become corrupt. If your camera fails to acknowledge the SD card we recommend that you replace the card with a new SD card or one from a different EYECON™ Trail Camera that you know works. This will help determine whether the problem is the SD card or the camera. - Page 18 pictures in a Point & Shoot Camera as read errors may occur. Always format brand new SDHC cards; a Full Format is recommended over a quick format. always forMat Brand new and prior Used sdhC Cards prior to Use in the trail CaMera. iMage qUality: Your Storm Trail Camera is designed to give you optimum trigger speed along with great night photo clarity.
- Page 19 PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.
-
Page 20: Warranty Information
Eyecon Trail Camera’s 1 Year Limited Warranty: For a period of 365 days after purchase, Eyecon Trail Cameras will, at its discretion, repair or replace this product for any reason of any defect or malfunction. This warranty is only valid if the product is used for the purpose intended and has not been tampered with and/or physically damaged in any way. -
Page 21: Product Registration Card
To activate your product’s warranty, please mail in your registration card or submit it online at www.EyeconTrailCameras.com prodUCt registration Product Purchased Model Number Serial Number Owner’s Name Street Address City State Zip Code E-mail Address Phone Owners Age (optional) Sex (optional) Date Purchased Purchased From (Dealer Name) How did you hear about us:... - Page 22 Remember to activate your product’s warranty? See warranty information and registration instructions on page 16 and then complete and mail in the registration card on page 17 or submit it online at: www.EyeconTrailCameras.com PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.
- Page 23 OWNER’S RECORD Product Name Model Number Serial Number Purchased From Purchased Date yoU MUst retUrn the CoMpleted registration Card aBove WITHIN (30) DAYS OF THE PURCHASE IN ORDER TO ACTIVATE THE LIMITED warranty Coverage. (Make sure to include date purchased on the card!) notes: PLEASE REGISTER TO ACTIVATE YOUR PRODUCT’S WARRANTY.
- Page 24 PO Box 454 • Windom, MN 56101 844-745-7723 • 507-832-8322...
