- Page 1 Intel® GME965 socket 479P Core Duo / Core Solo/Core 2 Duo Mini ITX Main Board User’s Manual Ver. 1.00...
-
Page 2: Table Of Contents
Contents Safety Information ......................4 Technical Support ......................5 Conventions Used in This Guide ..................5 Packing List ........................6 Revision History .......................7 Specifications Summary....................8 Block Diagram.........................10 Production Introduction ....................12 Before you Proceed ....................12 Motherboard Overview....................13 1.2.1 Placement Direction ........................13 1.2.2 Screw Holes ........................... 13 Motherboard Layout ....................14... - Page 3 LCD Inverter Connector (JBKL1)....................40 1.8.12 Digital I/O Connector (JDIO1) ....................40 1.8.13 SPI Connector (JSPI1)....................... 41 1.8.14 Digital Audio Connector (SPDIF_OUT2) ................... 41 1.8.15 Serial SATA Connector [Black] (SATA1, SATA2, SATA3) ............42 1.8.16 USB 2.0 Connector (USB3, USB4, USB5) ................43 i965GM-DCQI...
-
Page 4: Safety Information
Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. -
Page 5: Technical Support
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the Advansus website for FAQ, technical guide, BIOS updates, driver updates, and other information: http://www.advansus.com.tw/Support/Support.asp... -
Page 6: Packing List
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x Intel GME965 Mini ITX Main board 1 x CD-ROM contains the followings: － User’s manual (this manual in PDF file) －... -
Page 7: Revision History
User’s Manual Revision History Revision Revision History Date V 1.0 First release for PCB 1.00 October 02, 2007 i965GM-DCQI... -
Page 8: Specifications Summary
Specifications Summary Supports Intel socket P Core 2 Duo / Core Duo / Core 2 Solo / Core Solo mobil CPU with 65nm process technology Intel GME965 Chipset Two 200-pin SODIMMs sockets up to 4GB Dual Channel DDR2 533/667... - Page 9 Mechanical & Environmental Power Type 0~60°C (32~140°F) Operating Temperature 0%~90% relative humidity, non-condensing Operating Humidity 6.69" x 6.69" (170 mm x 170 mm) Size (L x W) 0.88 lbs (0.4 Kg) Weight * Specifications are subject to change without notice. i965GM-DCQI...
-
Page 10: Block Diagram
Block Diagram... - Page 11 User’s Manual This chapter describes the main board features and the new technologies it supports. Product Product introduction introduction i965GM-DCQI...
-
Page 12: Production Introduction
Production Introduction 1.1 Before you Proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. Unplug the power cord from the wall socket before touching any component. Use a grounded wrist strap or touch a safely grounded object or a... -
Page 13: Motherboard Overview
Screw Holes Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis i965GM-DCQI... -
Page 14: Motherboard Layout
1.3 Motherboard Layout... -
Page 15: Layout Content List
USB1 RJ-45 Ethernet connector x 1 33,34 USB connector x 2 USB2 RJ-45 Ethernet connector x 1 (Optional for Intel 82566MM) 33,34 USB connector x 2 AUDIO1 Line-in port, Line-out port, 5.1 Channel Audio I/O (3 jacks) Microphone port, i965GM-DCQI... - Page 16 Internal Connector Label Function Note Page AMPJ1 Amplifier connector 4 x 1 header, pitch 2.54mm ATXPWR1 ATX power connector 10 x 2 header COM3 Serial port 3 connector 5 x 2 header, pitch 2.54mm COM4 Serial port 4 connector 5 x 2 header, pitch 2.54mm...
-
Page 17: Central Processing Unit (Cpu)
Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the socket. The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap. i965GM-DCQI... -
Page 18: Installing The Cpu
1.4.1 Installing the CPU Locate the CPU socket on the motherboard. Before installing the CPU, make sure that the socket box is facing towards you. The processor socket comes with a screw to secure the processor, please unlock the screw first. - Page 19 The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU. After installation, make sure to plug-in the ATX power cable to the motherboard. i965GM-DCQI...
-
Page 20: Installing The Cpu Heatsink And Fan
1.4.2 Installing the CPU Heatsink and Fan The Intel® socket 479P Core Duo / Core Solo / Core 2 Duo CPU processor requires a specially designed heatsink and fan assembly to ensure optimum thermal condition and performance. Install the motherboard to the chassis before you install the CPU fan and heatsink assembly. - Page 21 Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. i965GM-DCQI...
-
Page 22: Uninstalling The Cpu Heatsink And Fan
1.4.3 Uninstalling the CPU Heatsink and Fan Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard Carefully remove the heatsink and fan assembly from the motherboard. -
Page 23: System Memory
A DDR2 module has the same physical dimensions as a DDR DIMM but has a 200-pin footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched differently to prevent installation on a DDR DIMM socket. The following figure illustrates the location of the sockets: i965GM-DCQI... -
Page 24: Memory Configurations
1.5.2 Memory Configurations You can install 128 MB, 256 MB, 512 MB, 1GB and 2GB DDR2 SDRAM DIMMs into the SODIMM sockets using the memory configurations in this section. Installing DDR2 DIMM other than the recommended configurations may cause memory sizing error or system boot failure. -
Page 25: Installing A Ddr2 Dimm
A DDR2 DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket to avoid damaging the DIMM. The DDR2 DIMM sockets do not support DDR DIMMs. DO NOT install DDR DIMMs to the DDR2 DIMM socket. i965GM-DCQI... -
Page 26: Removing A Ddr2 Dimm
1.5.4 Removing a DDR2 DIMM Press the two ejector tabs on the slot outward simultaneously, and then pull out the DIMM module. Support the DIMM lightly with your fingers when pressing the ejector tabs. The DIMM might get damaged when it flips out with extra force. -
Page 27: Expansion Slots
After installing the expansion card, configure it by adjusting the software settings. Turn on the system and change the necessary BIOS settings if any. Assign an IRQ to the card if needed. Refer to the tables on the next page. Install the software drivers for the expansion card. i965GM-DCQI... -
Page 28: Standard Interrupt Assignments
* There IRQs are usually available for ISA or PCI device. 1.6.4 PCI Slots i965GM-DCQI has one PCI slots. The PCI slots support cards such as a LAN card, SCSI card, USB card, and other cards that comply with PCI specifications. -
Page 29: Jumpers
Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. Except when clearing the CMOS, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! Normal (Default) Clear RTC i965GM-DCQI... -
Page 30: Com1 Ri/+5V/+12V Selection (Jcompwr1, Jcompwr2)
1.7.2 COM1 RI/+5V/+12V Selection (JCOMPWR1, JCOMPWR2) JCOMPWR1 JCOMPWR2 (Default) +12V Ring 1.7.3 COM2 RI/+5V/+12V Selection (JCOMPWR1, JCOMPWR2) JCOMPWR1 JCOMPWR2 (Default) +12V Ring... -
Page 31: Com3 Ri/+5V/+12V Selection (Jcompwr3, Jcompwr4)
User’s Manual 1.7.4 COM3 RI/+5V/+12V Selection (JCOMPWR3, JCOMPWR4) JCOMPWR3 JCOMPWR4 (Default) +12V Ring 1.7.5 COM4 RI/+5V/+12V Selection (JCOMPWR3, JCOMPWR4) JCOMPWR3 JCOMPWR4 (Default) +12V Ring i965GM-DCQI... -
Page 32: Sm Power Connector (Sm_Pwrbtn1)
1.7.6 SM Power Connector (SM_PWRBTN1) ATX Mode (Default) AT Mode... -
Page 33: Connectors
10/100 Mbps LAN controller allows 10/100 Mbps connection to a Local Area Network (LAN) through a network hub. ACT / LINK LED SPEED LED Status Description Status Description No link 10Mbps connection Orange Linked ORANGE 100Mbps connection Blinking Data activity GREEN 1Gbps connection i965GM-DCQI... - Page 34 Label Function Description AUDIO1 Line-In port (Light Blue). This port connects a tape, CD, DVD player, or other audio sources. AUDIO1 Line-Out port (Lime) This port connects a headphone or a speaker. In 4-channel, 6-channel, and 8-channel configuration, the function of this port becomes Front Speaker Out.
-
Page 35: Amplifier Connector (Ampj1)
300W for a fully configured system. The system can become unstable and might experience difficulty powering up if the power supply is inadequate. You must install a PSU with a higher power rating if you intend to install additional devices. i965GM-DCQI... -
Page 36: Serial Port 3 Connector (Com3)
1.8.4 Serial Port 3 Connector (COM3) 1.8.5 Serial Port 4 Connector (COM4) -
Page 37: Cpu Fan Connector (Cpu_Fan1)
Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. i965GM-DCQI... -
Page 38: System Panel Connector (Fpio1)
1.8.8 System Panel Connector (FPIO1) This connector supports several chassis-mounted functions. System Power LED (2-pin PWRLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. -
Page 39: Primary Ide Connector (Ide1)
User’s Manual 1.8.9 Primary IDE Connector (IDE1) Orient the red markings (usually zigzag) on the IDE cable to Pin Please DO NOT use IDE1 and SATA2 at the same time. This is an incompatible conflict. 1.8.10 LVDS Connector (JLVDS1) i965GM-DCQI... -
Page 40: Lcd Inverter Connector (Jbkl1)
1.8.11 LCD Inverter Connector (JBKL1) Signal Description Signal Signal Description Bright adjust. Vadj=0.75V ~ 4.25V (Recommended: 4.7KΩ, > 1/16W) ENBKL LCD backlight ON/OFF control signal 1.8.12 Digital I/O Connector (JDIO1) -
Page 41: Spi Connector (Jspi1)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port(s). Connect the S/PDIF module cable to this connector, then install the module to a slot opening at the back of the system chassis. The S/PDIF module is purchased separately. i965GM-DCQI... -
Page 42: Serial Sata Connector [Black] (Sata1, Sata2, Sata3)
1.8.15 Serial SATA Connector [Black] (SATA1, SATA2, SATA3) SATA1 SATA2 SATA3 SATA1 SATA2 SATA3 Install the Windows® 2000 Service Pack 4 or the Windows® XP Service Pack1 before using Serial ATA. When using the connectors in Standard IDE mode, connect the primary (boot) hard disk drive to the SATA1 connector. -
Page 43: Usb 2.0 Connector (Usb3, Usb4, Usb5)
These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed. USB3 USB4 USB4 USB5 USB3 USB5 Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. i965GM-DCQI...
