- Page 1 LM5560-Q45 ® ® Intel Q45 LGA775 socket for Intel Core™ 2 Quad Micro ATX Motherboard User’s Manual Ver. 1.00...
-
Page 2: Table Of Contents
LM5560-Q45 Contents Safety Information ......................5 Technical Support ......................6 Conventions Used in This Guide ..................6 Packing List ........................7 Revision History .......................8 Specifications Summary....................9 Specifications Summary....................10 Specifications Summary....................11 Block Diagram.........................12 Production Introduction ....................14 Before you Proceed ....................14 Motherboard Overview....................15 1.2.1 Placement Direction ........................15 1.2.2... - Page 3 Primary EIDE Connector (PRE_EIDE1) ..................42 1.8.11 Power Fan Connector (PWR_FAN1)..................42 1.8.12 Serial ATA Connector (SATA1~6) ..................... 43 1.8.13 Digital Audio Connector (SPDIF_O1) ..................44 1.8.14 SPI Pin Header (SPI1) ....................... 44 1.8.15 USB 2.0 Connector (USB56, USB78, USB910, USB1112)............45 LM5560-Q45...
- Page 4 LM5560-Q45 Contents BIOS Setup ........................47 BIOS Setup Program ....................47 2.1.1 Legend Box ............................ 48 2.1.2 List Box............................48 2.1.3 Sub-menu............................48 BIOS Menu Screen ....................49 2.2.1 Standard CMOS Features......................50 2.2.2 Advanced BIOS Features ......................52 2.2.3 Advanced Chipset Features......................59 2.2.4...
-
Page 5: Safety Information
If you encounter technical problems with the product, contact a qualified service technician or your retailer. The symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products. LM5560-Q45... -
Page 6: Technical Support
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the Advansus website : http://www.advansus.com.tw/... -
Page 7: Packing List
1 x COM 1 Cable (9P/260mm) 1 x ATA66 IDE Cable (40P) 3 x SATA Cable Kit (SATA/Power) 1 x I/O Shield 1 x Startup Manual If any of the above items is damaged or missing, please contact your retailer. LM5560-Q45... -
Page 8: Revision History
LM5560-Q45 Revision History Revision Revision History Date V 1.00 First release for PCB 1.00 February 6, 2009... -
Page 9: Specifications Summary
1 x PCI Express 2.0 X16, 1 X PCIe_X1 , 2 x PCI (PCI Rev. 2.3 compliant) Expansion Slots 16Bit (8 in 8out) S3 / S4 Intel Integrated TPM1.2 Wake up on LAN or LAN (PXE / RPL) Ring Smart Fan Control LM5560-Q45... -
Page 10: Specifications Summary
LM5560-Q45 Specifications Summary Display Chipset Intel® Graphics Media Accelerator 4500 integrated Display Memory Intel DVMT 4.0 supports up to 352 MB video memory Max. Resolution 2048 x 1536 bpp(@ 75Hz) Yes , on board GMA 4500 Yes , through ADD2 card... -
Page 11: Specifications Summary
Mechanical & Environmental Power Type Operating Temperature 0~60°C (32~140°F) Operating Humidity 0%~90% relative humidity, non-condensing 9.6" x 9.6" (243.84 mm x 243.84 mm) Size (L x W) 1.40 lbs (0.64 Kg) Weight * Specifications are subject to change without notice. LM5560-Q45... -
Page 12: Block Diagram
LM5560-Q45 Block Diagram... - Page 13 User’s Manual This chapter describes the main board features and the new technologies it supports. Product Product introduction introduction LM5560-Q45...
-
Page 14: Production Introduction
LM5560-Q45 Production Introduction 1.1 Before you Proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. Unplug the power cord from the wall socket before touching any component. Use a grounded wrist strap or touch a safely grounded object or a... -
Page 15: Motherboard Overview
Screw Holes Place eight (8) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis LM5560-Q45... -
Page 16: Motherboard Layout
LM5560-Q45 1.3 Motherboard Layout... -
Page 17: Layout Content List
D-sub 25-pin, female VGA1 VGA Connector D-sub 15-pin, female USB34 USB Connector x 2 LAN_USB12 RJ-45 Ethernet Connector x 1 34,35 USB Connector x 2 AUDIO1 Line-in Port, Line-out Port, 5.1 Channel Audio I/O (3 jacks) 34,35 Microphone Port, LM5560-Q45... - Page 18 LM5560-Q45 Internal Connector Label Function Note Page AAFP1 Front Panel Audio Connector 5 x 2 header, pitch 2.54mm ATX12V1 ATX Power Connector 2 x 2 header CHA_FAN1 Chassis Fan Connector 3 x 1 wafer, pitch 2.54mm CPU_FAN1 CPU Fan Connector 4 x 1 wafer, pitch 2.54mm...
-
Page 19: Central Processing Unit (Cpu)
Authorization (RMA) requests only if the motherboard comes with the cap on the LGA775 socket. The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap.. LM5560-Q45... -
Page 20: Installing The Cpu
LM5560-Q45 1.4.1 Installing the CPU Locate the CPU socket on the motherboard. Before installing the CPU, make sure that the socket box is facing towards you and the load lever is on your left. Press the load lever with your thumb (A), then move it to the left (B) until it is released from the retention tab. - Page 21 CPU! The motherboard supports Intel® LGA775 processors with the Intel® Enhanced Memory 64 Technology (EM64T), Enhanced Intel SpeedStep® Technology (EIST), and Hyper-Threading Technology. After installation, make sure to plug-in the ATX power cable to the motherboard. LM5560-Q45...
-
Page 22: Installing The Cpu Heatsink And Fan
LM5560-Q45 1.4.2 Installing the CPU Heatsink and Fan The Intel® Q45 LGA775 socket for Intel® Core™2 Quad / Core™2 Duo CPU processors require a specially designed heatsink and fan assembly to ensure optimum thermal condition and performance. Install the motherboard to the chassis before you install the CPU fan and heatsink assembly. - Page 23 Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. LM5560-Q45...
-
Page 24: Uninstalling The Cpu Heatsink And Fan
LM5560-Q45 1.4.3 Uninstalling the CPU Heatsink and Fan Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counter-clockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard Carefully remove the heatsink and fan assembly from the motherboard. - Page 25 The narrow end of the groove should point outward after resetting. (The photo shows the groove shaded for emphasis.) Refer to the documentation in the boxed or stand-alone CPU fan package for detailed information on CPU fan installation. LM5560-Q45...
-
Page 26: System Memory
LM5560-Q45 1.5 System Memory 1.5.1 DIMM Sockets Location The motherboard comes with four 240-pin Double Data Rate 2 (DDR2) Dual Inline Memory Modules (DIMM) sockets. A DDR2 module has the same physical dimensions as a DDR DIMM but has a 240-pin footprint compared to the 184-pin DDR DIMM. -
Page 27: Memory Configurations
Recommended memory configuration Channel Socket Channel A DIMM_A1 and DIMM_A2 Channel B DIMM_B1 and DIMM_B2 Memory frequency/CPU FSB synchronization DDR2 Single Ch. Dual Ch. CPU FSB DIMM Type Peak Bandwidth Peak Bandwidth 800/1066/ 5.32GB/s 10.6GB/s 1333MHz 6.4GB/s 12.8GB/s LM5560-Q45... -
Page 28: Installing A Ddr2 Dimm
LM5560-Q45 1.5.3 Installing a DDR2 DIMM Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the motherboard and the components. Unlock a DIMM socket by pressing the... -
Page 29: Expansion Slots
After installing the expansion card, configure it by adjusting the software settings. Turn on the system and change the necessary BIOS settings if any. Assign an IRQ to the card if needed. Refer to the tables on the next page. Install the software drivers for the expansion card. LM5560-Q45... -
Page 30: Standard Interrupt Assignments
LM5560-Q45 1.6.3 Standard Interrupt Assignments Priority Standard Function System Timer Keyboard Controller Redirect to IRQ#9 IRQ holder for PCI streering* Communications Port (COM1)* IRQ holder for PCI streering* Floppy Disk Controller Printer Port (LPT)* System CMOS/Rear Time IRQ holder for PCI streeing*... -
Page 31: Pci Slot
PCI slot. 1.6.5 PCI Express X16 Slot This motherboard supports one PCI Express x16 graphic cards that comply with the PCI Express specifications. The following figure shows a graphics card installed on the PCI Express x16 slot. LM5560-Q45... -
Page 32: Jumpers
LM5560-Q45 1.7 Jumpers 1.7.1 Clear CMOS (CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. -
Page 33: Chassis Intrusion Connector (Chssis1)
User’s Manual 1.7.2 Chassis Intrusion Connector (CHSSIS1) 1.7.3 COM1, COM2 RI/+5V/+12V Select (JCOMPWR1, JCOMPRW2) RI (Default) +12V JCOMPWR1 JCOMPWR2 LM5560-Q45... -
Page 34: Connectors
LM5560-Q45 1.8 Connectors 1.8.1 Rear Panel Connectors Label Function Description KBMS1 PS/2 mouse connector The standard PS/2 mouse DIN connector is for a PS/2 mouse. LPT1 Parallel port connector This 25-pin parallel port is a standard printer port that supports Enhanced Parallel... - Page 35 USB 2.0 devices. VGA1 VGA port This 15-pin port is for a VGA monitor or other VGA-compatible devices. COM1 Serial port connector D-Sub 9-pin, male KBMS1 PS/2 KB connector This port is for a PS/2 keyboard LM5560-Q45...
-
Page 36: Front Panel Audio Connector (Aafp1)
LM5560-Q45 1.8.2 Front Panel Audio Connector (AAFP1) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC ‘97 (optional) audio standard. Connect one end of the front panel audio I/O module cable to this connector. -
Page 37: Atx Power Connector (Atx12V1, Eatxpwr1)
300W for a fully configured system. The system can become unstable and might experience difficulty powering up if the power supply is inadequate. You must install a PSU with a higher power rating if you intend to install additional devices. LM5560-Q45... -
Page 38: Chassis Fan Connector (Cha_Fan1)
LM5560-Q45 1.8.4 Chassis Fan Connector (CHA_FAN1) 1.8.5 CPU Fan Connector (CPU_FAN1) Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. -
Page 39: Serial Port Connector 2 (Com2)
User’s Manual 1.8.6 Serial Port Connector 2 (COM2) LM5560-Q45... -
Page 40: System Panel Connector (F_Panel1)
LM5560-Q45 1.8.7 System Panel Connector (F_PANEL1) This connector supports several chassis-mounted functions. System Power LED (2-pin PWRLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. -
Page 41: Amplifier Connector (Jamp1)
User’s Manual 1.8.8 Amplifier Connector (JAMP1) 1.8.9 Digital I/O Connector (JDIO1) LM5560-Q45... -
Page 42: Primary Eide Connector (Pre_Eide1)
LM5560-Q45 1.8.10 Primary EIDE Connector (PRE_EIDE1) Orient the red markings (usually zigzag) on the IDE cable to Pin 1.8.11 Power Fan Connector (PWR_FAN1) -
Page 43: Serial Ata Connector (Sata1~6)
SATA6 SATA5 SATA2, 4, 6 Connect the right-angle side of SATA signal cable to SATA device. Or you may connect the right-angle side of SATA cable to the onboard SATA port to avoid mechanical conflict with huge graphics cards. LM5560-Q45... -
Page 44: Digital Audio Connector (Spdif_O1)
LM5560-Q45 1.8.13 Digital Audio Connector (SPDIF_O1) This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port(s). Connect the S/PDIF module cable to this connector, then install the module to a slot opening at the back of the system chassis. -
Page 45: Usb 2.0 Connector (Usb56, Usb78, Usb910, Usb1112)
These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed. Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. LM5560-Q45... - Page 46 LM5560-Q45 This chapter tells how to change the system setting through the BIOS setup menus. Detailed descriptions of the BIOS parameters are also provided. BIOS setup BIOS setup...
-
Page 47: Bios Setup
Select the Load Setup Defaults from the BIOS menu screen. The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. Visit the system builder’s website to download the latest BIOS file for this motherboard LM5560-Q45... -
Page 48: Legend Box
LM5560-Q45 2.1.1 Legend Box The keys in the legend bar allow you to navigate through the various setup menus Key(s) Function Description ↑↓→← Move Enter Select + / - / PU / PD Value Exit General Help Item Help Previous Value... -
Page 49: Bios Menu Screen
To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu. LM5560-Q45... -
Page 50: Standard Cmos Features
LM5560-Q45 2.2.1 Standard CMOS Features The Standard CMOS Features screen gives you an overview of the basic system 2.2.1.1 Date [Day, xx/xx/xxxx] The date format is <week>, <month>, <day>, <year>. 2.2.1.2 Time [xx:xx:xx] The time format is <hour> <minute> <second>, based on the 24-hour clock. - Page 51 Set the system to halt on errors according to the system functions specified in each option. Configuration options: [All Errors] [No Errors] [All, But Keyboard] [All, But Diskette] [All, But Disk/Key] 2.2.1.7 Memory This category displays base memory, extended memory, and total memory detected during POST (Power On Self Test). LM5560-Q45...
-
Page 52: Advanced Bios Features
LM5560-Q45 2.2.2 Advanced BIOS Features The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure according to particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen. - Page 53 CPU C1E function select. The options: Auto, Disabled Execute Disable Bit When disabled, forces the XD feature flag to always return 0 Virtualization Technology The options: Enabled, Disabled SWMRR The options: Enabled, Disabled Core Multi-Processing The options: Enabled, Disabled LM5560-Q45...
- Page 54 LM5560-Q45 2.2.2.2 Hard Disk Boot Priority Set hard disk boot device priority. 2.2.2.3 Virus Warning Enables or disables the virus warning. Item Description Activates automatically when the system boots up causing a warning Enabled message to appear when anything attempts to access the boot sector or hard disk partition table.
- Page 55 Selection of the command “Disabled” will speed the boot up. Item Description Enabled Enable Floppy Seek Disabled Disable Floppy Seek 2.2.2.9 Boot Up NumLock Status Set the boot up Num Lock status. The options are “On” and “Off”. Item Description Enable NumLock Disable NumLock LM5560-Q45...
- Page 56 LM5560-Q45 2.2.2.10 Gate A20 Option Item Description Normal A pin in the keyboard controller controls GateA20 Fast Lets chipset control GateA20 (Default) 2.2.2.11 Typematic Rate Setting The typematic rate is the rate key strokes repeat as determined by the keyboard controller.
- Page 57 2.2.2.21 Small Logo (EPA) Show This item allows you enabled/disabled the small EPA logo show on screen at the POST step. Item Description Enabled EPA Logo shows is enabled Disabled EPA Logo show is disabled 2.2.2.22 ASF Support The default is [Enabled]. LM5560-Q45...
- Page 58 LM5560-Q45 2.2.2.23 DMI Event Log The options: Enabled, Disabled. 2.2.2.24 Clear All DMT Event Log The options: Yes, No. 2.2.2.25 View DMI Event Log Show the Event Log history. The options: Yes, No. 2.2.2.26 Mark DMI Events as Read The options: Yes, No.
-
Page 59: Advanced Chipset Features
Enabling this feature reserves 15 MB to 16 MB memory address space for ISA expansion cards that specifically require this setting. This makes memory from 15 MB and up unavailable to the system. Expansion cards can only access memory up to 16 MB. The default setting is “Disabled”. LM5560-Q45... - Page 60 LM5560-Q45 2.2.3.4 PCI Express Root Port Function PCI Express Port The choices: Auto, Enabled, Disabled. PCI-E Compliancy Mode The choices: V1.0a, V1.0. 2.2.3.5 VT-d The options: Disabled, Enabled 2.2.3.6 Intel AMT Configuration 2.2.3.7 PEG/Onchip VGA Control The selections are “Auto”, “Onchip VGA” or “PEG Port”.
- Page 61 2.2.3.9 DVMT Mode Use this field to select the memory to allocate for video memory. The choices are “Enabled”, “Disabled”. 2.2.3.10 Total GFX Memory Precharge Delay (tRAS) The options: 256MB, MAX 2.2.3.11 PAVP Mode The options: Disabled, Lite, Paranoid LM5560-Q45...
-
Page 62: Integrated Peripherals
LM5560-Q45 2.2.4 Integrated Peripherals 2.2.4.1 OnChip IDE Device... - Page 63 SATA devices, such as hot-plugging and Native Command Queuing (NCQ). LEGACY Mode Support The choices: Disabled, Enabled. 2.2.4.2 Onboard Device Azalia Controller The choices: Auto, Disabled. Audio Amplifier The choices: Enabled, Disabled. Amplifier Gain (dB) The choices: 31.8dB, 27.2dB, 21.2dB, 15.3dB LM5560-Q45...
- Page 64 LM5560-Q45 2.2.4.3 Super I/O Device Power ON Function This feature allows you to wake up the system using any of the listed options. The selections are “Hot KEY”, “Mouse Left”, “Mouse Right”, “Any KEY” and “BUTTON ONLY”. KB Power ON Password Select this item to set or change the KB power on password.
- Page 65 “On” setting boots up the system after failure, and the “Former-Sts” returns the system to the status before power failure. 2.2.4.4 JMicron 36X ATA Controller The options: Enabled, Disabled. 2.2.4.5 Onboard LAN Boot ROM The options: Enabled, Disabled. 2.2.4.6 Watch Dog Timer Selection The options: 0 ~ 255 LM5560-Q45...
- Page 66 LM5560-Q45 2.2.4.7 USB Device Setting USB 1.0 / 2.0 Controller The choices: Disabled, Enabled. USB Operation Mode Allows you to configure the USB 2.0 controller in HiSpeed (480 Mbps) or Full Speed (12 Mbps). Configuration options: [Full/Low Speed] [HiSpeed] USB Keyboard Function The choices: Disabled, Enabled.
-
Page 67: Security Chip Configuration
User’s Manual 2.2.5 Security Chip Configuration 2.2.5.1 LT/TXT Initialization The options: Disabled, Enabled. 2.2.5.2 Reset TPM Flag The options: Disabled, Enabled. 2.2.5.3 TPM Support The options: Disabled, Enabled. LM5560-Q45... -
Page 68: Power Management Setup
LM5560-Q45 2.2.6 Power Management Setup The power management setup controls the single board computer's “green” features to save power. The following screen shows the manufacturer’s defaults. - Page 69 User Defined Power Down which ranges from 1 min. to 15 min. and disable. 2.2.6.6 Video Off Method Use this to select the method to turn off the video. The choices are “Blank Screen”, “V/H SYNC+ Blank”, and “DPMS”. LM5560-Q45...
- Page 70 LM5560-Q45 2.2.6.7 Video Off In Suspend When the system is in suspend mode, the video will turn off. The choices are “No” and “Yes”. 2.2.6.8 Suspend Type Select the suspend type. The choice: Stop Grant, Pwron suspend. 2.2.6.9 MODEM Use IRQ This determines the IRQ in which the MODEM can use.
- Page 71 2.2.6.17 Primary / Secondary IDE The options: Disabled, Enabled. 2.2.6.18 FDD, COM, LPT Port The options: Disabled, Enabled. 2.2.6.19 PCI PIRQ [A-D] # The options: Disabled, Enabled. 2.2.6.20 HPET Support The options: Disabled, Enabled. 2.2.6.21 HPET Mode The default is 32-bit mode. LM5560-Q45...
-
Page 72: Pnp/Pci Configurations
LM5560-Q45 2.2.7 PnP/PCI Configurations 2.2.7.1 Init Display First This item allows you to choose the first display interface to initiate while booting. The choice is “PCI Slot” or “Onboard”. 2.2.7.2 Rest Configuration Data The default is “Disabled”. Select Enabled to reset Extended System Configuration Data (ESCD) if you have installed a new add-on card, and system configuration is in such a state that the OS cannot boot. - Page 73 This is set to “Disabled” by default. 2.2.7.5 Maximum Payload Size This allows you to set the maximum TLP payload size for PCI Express devices. The options: [128 bytes], [256 bytes], [512 bytes], [1024 bytes], [2048 bytes], and [4096 bytes]. LM5560-Q45...
-
Page 74: Pc Health Status
LM5560-Q45 2.2.8 PC Health Status 2.2.8.1 CPU Warning temperature The options: Disabled, 50℃/122℉, 53℃/127℉, 56℃/133℉, 60℃/140℉, 63℃/145℉, 66℃/151℉, 70℃/158℉. 2.2.8.2 System Temperature This shows you the current temperature of system. 2.2.8.3 CPU Temperature This shows the current CPU temperature. 2.2.8.4 CPU FAN Speed This shows the current CPU FAN operating speed. -
Page 75: Frequency/Voltage Control
This is achieved by varying the frequency slightly so that the signal does not use any particular frequency for more than a moment. The options: Disabled, N+0.3333, N+0.6666. 2.2.9.3 CPU/SRC/PCI The options: Default, 100/100/33MHz, 133/100/33MHz, 200/100/33MHz, 266/100/33MHz, 333/100/33MHz. LM5560-Q45... -
Page 76: Load Setup Defaults
LM5560-Q45 2.2.10 Load Setup Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. Press <Y> to load the BIOS default values for the most stable, minimal-performance system operations. -
Page 77: Set Password
CMOS. The password must be no longer than eight (8) characters. Remember, to enable the password setting feature, you must first select either “Setup” or “System” from the “Advanced BIOS Features” menu. LM5560-Q45... -
Page 78: Save And Exit Setup
LM5560-Q45 2.2.12 Save and Exit Setup If you select this and press <Enter>, the values entered in the setup utilities will be recorded in the CMOS memory of the chipset. The processor will check this every time you turn your system on and compare this to what it finds as it checks the system. -
Page 79: Exit Without Saving
User’s Manual 2.2.13 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. LM5560-Q45...
