Advansus I865G-IM Series User Manual

Intel pentium d / pentium 4 / celeron micro atx main board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Micro ATX
I865G-IM Series
®
®
®
®
Intel
Pentium
D / Pentium
4 / Celeron
Micro ATX Main Board
User's Manual
Ver. 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I865G-IM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advansus I865G-IM Series

Summary of Contents for Advansus I865G-IM Series

  • Page 1 Micro ATX I865G-IM Series ® ® ® ® Intel Pentium D / Pentium 4 / Celeron Micro ATX Main Board User’s Manual Ver. 1.00...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by Advansus; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Welcome! ..................1-2 Package contents ................1-2 Special features ................1-2 1.3.1 Product highlights ............1-2 1.3.2 Innovative Advansus features ......... 1-4 Before you proceed ................ 1-6 Motherboard overview ..............1-7 1.5.1 Placement direction ............1-7 1.5.2 Screw holes ..............1-7 1.5.3...
  • Page 4 Creating a bootable floppy disk ........2-2 2.1.2 Advansus EZ Flash utility ..........2-3 2.1.3 AFUDOS utility ..............2-4 2.1.4 Advansus CrashFree BIOS 2 utility ........ 2-6 2.1.5 Advansus Update utility ..........2-8 BIOS setup program ..............2-11 2.2.1 BIOS menu screen ............2-12 2.2.2...
  • Page 5 Contents Power menu ................. 2-26 2.5.1 Suspend Mode ............. 2-26 2.5.2 Repost Video on S3 Resume ........2-26 2.5.3 ACPI 2.0 Support ............2-26 2.5.4 ACPI APIC Support ............2-26 2.5.5 APM Configuration ............2-27 2.5.6 Hardware Monitor ............2-28 Boot menu ..................

  • Page 6: Notices

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.

  • Page 7: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 8: About This Guide

    Refer to the following sources for additional information and for product and software updates. Advansus websites The Advansus website provides updated information on Advansus hardware and software products. Refer to the Advansus contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 9: Conventions Used In This Guide

    Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 10: I865G-Im Specifications Summary

    Realtek 10/100 LAN controller ® Supports up to 8 USB 2.0 ports Special features Advansus EZ Flash Advansus CrashFree BIOS 2 Advansus MyLogo™ Rear panel 1 x Parallel port 1 x LAN (RJ-45) port 4 x USB 2.0 ports 1 x Serial port (COM)
  • Page 11 BIOS features 4 Mb Flash ROM, AMI BIOS, PnP, WfM2.0, DMI2.0, BIOS 2.3, Advansus EZ Flash, CrashFree BIOS2, C.P.R. (CPU Parameter Recall), Advansus MyLogo Industry standard PCI 2.2, USB 2.0 Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, Chassis...

  • Page 13: Chapter 1: Product Introduction

    This chapter describes the motherboard features and the new technologies it supports. Product introduction i865G-IM...

  • Page 14: Welcome

    ® The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of Advansus quality motherboards! Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.
  • Page 15 Intel 65nanometer process technology support ® The motherboard supports Intel processors built on the 65-nanometer (nm) ® process technology with copper interconnect. Intel s 65 nm process is the most advanced chip manufacturing technology, delivering breakthrough performance, enhanced media experience, and low power consumption. The Intel 65 nm ®...

  • Page 16: Innovative Advansus Features

    ROM chip. See details on page 2-6. Advansus EZ Flash BIOS With the Advansus EZ Flash, you can easily update the system BIOS even before loading the operating system. No need to use a DOS-based utility or boot from a floppy disk.
  • Page 17 C.P.R. (CPU Parameter Recall) The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the BIOS default settings in case the system hangs due to overclocking. When the system hangs due to overclocking, C.P.R. eliminates the need to open the system chassis and clear the RTC data.

  • Page 18: Before You Proceed

    Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Use a grounded wrist strap or touch a safely grounded object or to a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity •...

  • Page 19: Motherboard Overview

    Motherboard overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

  • Page 20: Motherboard Layout

    1.5.3 Motherboard layout Chapter 1: Product introduction...

  • Page 21: Central Processing Unit (Cpu)

    Advansus will shoulder the cost of repair only if the damage is shipment/transit-related. • Keep the cap after installing the motherboard. Advansus will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA775 socket.
  • Page 22 Press the load lever with your thumb (A) and move it to the left (B) until it is released from the retention tab. PnP Cap Retention tab Load lever This side of the cam box should face you. To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU.
  • Page 23 Close the load plate (A), then push the load lever (B) until it snaps into the retention tab. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! Notes on Intel Hyper-Threading Technology ®...

  • Page 24: Installing The Cpu Heatsink And Fan

    1.6.2 Installing the CPU heatsink and fan The Intel Pentium 4 LGA775 processor requires a specially designed heatsink ® ® and fan assembly to ensure optimum thermal condition and performance. • When you buy a boxed Intel Pentium 4 processor, the package ®...
  • Page 25 Push down two fasteners at a time in a diagonal sequence to secure the heatsink and fan assembly in place. Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN. CPU_FAN CPU FAN PWM CPU FAN IN CPU FAN PWR CPU fan connector Do not forget to connect the CPU fan connector! Hardware monitoring errors...

  • Page 26: Uninstalling The Cpu Heatsink And Fan

    1.6.3 Uninstalling the CPU heatsink and fan To uninstall the CPU heatsink and fan: Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard.
  • Page 27 Carefully remove the heatsink and fan assembly from the motherboard. Rotate each fastener clockwise to ensure correct orientation when reinstalling. Narrow end of the groove The narrow end of the groove should point outward after resetting. (The photo shows the groove shaded for emphasis.) i865G-IM 1-15...

  • Page 28: System Memory

    System memory 1.7.1 Overview The motherboard comes with four 184-pin Double Data Rate (DDR) Dual Inline Memory Modules (DIMM) sockets. The following figure illustrates the location of the sockets: 184-pin DDR DIMM sockets 1.7.2 Memory configurations You may install 64MB,128 MB, 256 MB, 512 MB, and 1 GB DDR DIMMs into the DIMM sockets using the memory configuration in this section.

  • Page 29: Ddr Qualified Vendors List

    DDR Qualified Vendors List The following table lists the memory modules that have been tested and qualified for use with this motherboard. Visit the Advansus website (www.Advansus.com) for the latest DDR DIMM modules for this motherboard. Table 1 DDR Qualified Vendors List...

  • Page 30: Channel Memory Configuration

    Table 1 DDR Qualified Vendors List DIMM support Size Vendor Model Brand Side(s) Component 512MB Corsair VS512MB400 Value select VS32M8-5 2B0402 256MB Corsair VS256MB333 Samsung K4H560838D-TCB3 512MB Corsair XMS2702v3.1 Mosel V58C2256804SAT6 512MB Micron MT16VDDT6464AG-335GB Micron MT46V32M8TG-6TG 256MB Micron MT8VDDT3264AG-335GB Micron MT46V32M8TG-6TG 256MB Micron...

  • Page 31: Installing A Dimm

    1.7.4 Installing a DIMM Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the motherboard and the components. Unlock a DIMM socket by pressing DDR DIMM notch the retaining clips outward.

  • Page 32: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 33: Interrupt Assignments

    1.8.3 Interrupt assignments Standard interrupt assignments Priority Standard Function System Timer Keyboard Controller Re-direct to IRQ#9 Communications Port (COM2)* Communications Port (COM1)* IRQ holder for PCI steering* Floppy Disk Controller Printer Port (LPT1)* System CMOS/Real Time Clock IRQ holder for PCI steering* IRQ holder for PCI steering* IRQ holder for PCI steering* PS/2 Compatible Mouse Port*...

  • Page 34: Pci Slots

    1.8.4 PCI slots The PCI slots support cards such as a LAN card, SCSI card, USB card, and other cards that comply with PCI specifications. The figure shows a LAN card installed on a PCI slot. 1.8.5 AGP slot The Accelerated Graphics Port(AGP) slot that supports AGP8X/4X cards. when you buy an AGP card, make sure that you ask for one with +1.5V specification.

  • Page 35: Jumpers

    Jumpers Clear RTC RAM (3-pin CLRTC) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords.
  • Page 36 USB device wake-up (3-pin USBPW12, USBPW34, USBPW56, USBPW78) Set these jumpers to +5V to wake up the computer from S1 sleep mode (CPU stopped, DRAM refreshed, system running in low power mode) using the connected USB devices. Set to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU, DRAM in slow refresh, power supply in reduced power mode).
  • Page 37 Keyboard power (3-pin KBPWR) This jumper allows you to enable or disable the keyboard wake-up feature. Set this jumper to pins 2-3 (+5VSB) to wake up the computer when you press a key on the keyboard (the default is the Space Bar). This feature requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS.

  • Page 38: 1.10 Connectors

    1.10 Connectors 1.10.1 Rear panel connectors PS/2 mouse port (green). This port is for a PS/2 mouse. Parallel port. This 25-pin port connects a parallel printer, a scanner, or other devices. LAN (RJ-45) port. This port allows 10/100Mb connection to a Local Area Network (LAN) through a network hub.

  • Page 39: 1.10.2 Internal Connectors

    Refer to the audio configuration table for the function of the audio ports in 2, 4, or 6-channel configuration. Audio 2, 4, or 6-channel configuration Port Headset 4-channel 6-channel 2-channel Light Blue Line In Front Speaker Out Front Speaker Out Lime Line Out Rear Speaker Out...

  • Page 40: Ide Connectors

    IDE connectors (40-1 pin PRI_IDE, SEC_IDE) These connectors are for Ultra DMA 100/66 signal cables. There are three interfaces on each Ultra DMA 100/66 signal cables: blue, black, and gray. Connect the blue interface into the motherboad’s IDE connector, then select the following modes to configure your hard disk drive(s).

  • Page 41: Cpu And Chassis Fan Connectors

    Serial ATA connectors (7-pin SATA1, SATA2) These connectors are for the Serial ATA signal cables for Serial ATA hard disk drives. SATA 2 SATA 1 SATA connectors Install the Windows 2000 Service Pack 4 or the Windows XP Service Pack1 ®...
  • Page 42 Chassis intrusion connector (4-1 pin CHASSIS) This connector is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a high- level signal to this connector when a chassis component is removed or replaced.
  • Page 43 ATX power connectors (20-pin ATXPWR,4-pin ATX12V) These connectors are for an ATX power supply. The plugs from the power supply are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. •...
  • Page 44 USB connectors (10-1 pin USB56, USB78) These connectors are for USB 2.0 ports. Connect the optional USB/GAME module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed.
  • Page 45 11. System panel connector (20-1 pin PANEL) This connector supports several chassis-mounted functions. PLED SPEAKER PANEL IDE_LED RESET PWRSW Requires an ATX power supply. System Panel connector The sytem panel connector is color-coded for easy connection. Refer to the connector description below for details. •...
  • Page 46 1-34 Chapter 1: Product introduction...

  • Page 47: Chapter 2: Bios Setup

    This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. BIOS setup i865G-IM...

  • Page 48: Managing And Updating Your Bios

    The following utilities allow you to manage and update the motherboard Basic Input/Output System (BIOS) setup. Advansus AFUDOS (Updates the BIOS in DOS mode using a bootable floppy disk.) Advansus EZ Flash (Updates the BIOS using a floppy disk during POST.) Advansus CrashFree BIOS 2 (Updates the BIOS using a bootable floppy disk or the motherboard support CD when the BIOS file fails or gets corrupted.)

  • Page 49: Advansus Ez Flash Utility

    2.1.2 Advansus EZ Flash utility The Advansus EZ Flash feature allows you to update the BIOS without having to go through the long process of booting from a floppy disk and using a DOS-based utility. The EZ Flash utility is built-in the BIOS chip so it is accessible by pressing <Alt>...

  • Page 50: Afudos Utility

    2.1.3 AFUDOS utility The AFUDOS utility allows you to update the BIOS file in DOS environment using a bootable floppy disk with the updated BIOS file. This utility also allows you to copy the current BIOS file that you can use as backup when the BIOS fails or gets corrupted during the updating process.
  • Page 51 Updating the BIOS file To update the BIOS file using the AFUDOS utility: Visit the Advansus website (www.Advansus.com) and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable floppy disk. Write the BIOS filename on a piece of paper. You need to type the exact BIOS filename at the DOS prompt.

  • Page 52: Advansus Crashfree Bios 2 Utility

    2.1.4 Advansus CrashFree BIOS 2 utility The Advansus CrashFree BIOS 2 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using the motherboard support CD or the floppy disk that contains the updated BIOS file.
  • Page 53 DO NOT shut down or reset the system while updating the BIOS! Doing so can cause system boot failure! Restart the system after the utility completes the updating process. The recovered BIOS may not be the latest BIOS version for this motherboard. Visit the Advansus website (www.Advansus.com) to download the latest BIOS file. i865G-IM...

  • Page 54: Advansus Update Utility

    2.1.5 Advansus Update utility The Advansus Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows environment. The Advansus Update utility allows ® you to: • Save the current BIOS file • Download the latest BIOS file from the Internet •...
  • Page 55 To update the BIOS through the Internet: Launch the Advansus Update utility from the Windows desktop by clicking ® Start > Programs > Advansus > AdvansusUpdate > AdvansusUpdate. The Advansus Update main window appears. Select Update BIOS from the Select the Advansus FTP site...
  • Page 56 To update the BIOS through a BIOS file: Launch the Advansus Update utility from the Windows desktop by clicking ® Start > Programs > Advansus > AdvansusUpdate > AdvansusUpdate. The Advansus Update main window appears. Select Update BIOS from a file option from the drop-down menu, then click Next.

  • Page 57: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the Advansus website (www.Advansus.com) to download the latest BIOS file for this motherboard and . i865G-IM 2-11...

  • Page 58: Bios Menu Screen

    2.2.1 BIOS menu screen Menu items Menu bar Configuration fields General help System Time [11:51:19] Use [ENTER], [TAB] System Date [Thu 05/07/2004] or [SHIFT-TAB] to Legacy Diskette A [1.44M, 3.5 in] Legacy Diskette B [Disabled] select a field. Use [+] or [-] to Primary IDE Master :[Not Detected] configure system time.

  • Page 59: Menu Items

    2.2.4 Menu items The highlighted item on the menu bar displays the specific items for that menu. System Time [11:10:19] Use [ENTER], [TAB] System Date [Thu 03/27/2003] or [SHIFT-TAB] to Legacy Diskette A [1.44M, 3.5 in] select a field. Legacy Diskette B [Disabled] For example, selecting Main shows the Main Use [+] or [-] to...

  • Page 60: Main Menu

    Main menu When you enter the BIOS Setup program, the Main menu screen appears, giving you an overview of the basic system information. Refer to section “2.2.1 BIOS menu screen” for information on the menu screen items and how to navigate through them. System Time [11:51:19] Use [ENTER], [TAB]...

  • Page 61: Primary, Third And Fourth Ide Master/Slave

    2.3.4 Primary, Secondary, Third and Fourth IDE Master/Slave While entering Setup, the BIOS automatically detects the presence of IDE devices. There is a separate sub-menu for each IDE device. Select a device item then press <Enter> to display the IDE device information. Primary IDE Master Device : Not Detected...

  • Page 62: Ide Configuration

    PIO Mode [Auto] Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4] DMA Mode [Auto] Selects the DMA mode. Configuration options: [Auto] [SWDMA0] [SWDMA1] [SWDMA2] [MWDMA0] [MWDMA1] [MWDMA2] [UDMA0] [UDMA1] [UDMA2] [UDMA3] [UDMA4] [UDMA5] SMART Monitoring [Auto] Sets the Smart Monitoring, Analysis, and Reporting Technology.

  • Page 63: System Information

    The P-ATA+S-ATA and P-ATA options are for advanced users only. If you set to any of these options and encounter problems, revert to the default setting S-ATA. Configuration options: [P-ATA+S-ATA] [S-ATA] [P-ATA] The IDE Port Settings item appears only when the Onboard IDE Operate Mode item is set to Compatible Mode.

  • Page 64: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Jumperfree Configuration CPU Configuration Chipset Onboard Devices Configuration...

  • Page 65: Cpu Configuration

    The following item appears only when the AI Overclocking item is set to [Manual]. CPU External Frequency(MHz) [xxx] (value is auto-detected) Indicates the frequency sent by the clock generator to the system bus and PCI bus. The bus frequency(external frequency)multiplied by the bus multiple equals the CPU speed.

  • Page 66: Chipset

    Ajacent Cache Line Prefetch [Enabled] Allows you to enable/disable the Ajacent Cache Line Prefetch function. Configuration options: [Disabled] [Enabled] CPU Internal Thermal Control [Auto] Disables or sets the CPU internal thermal control. Configuration options: [Disabled] [Auto] Hyper-Threading Technology [Enabled] Allows you to enable or disable the processor Hyper-Threading Technology. Configuration options: [Disabled] [Enabled] 2.4.3 Chipset...
  • Page 67 DRAM RAS# Precharge [4 Clocks] Controls the idle clocks after issuing a precharge command to the DDR SDRAM. Configuration options: [4 Clocks] [3 Clocks] [2 Clocks] DRAM RAS# to CAS# Delay [4 Clocks] Controls the latency between the DDR SDRAM active command and the read/write command.

  • Page 68: Onboard Devices Configuration

    2.4.4 Onboard Devices Configuration Onboard AC’97 Audio [Auto] Onboard LAN [Enabled] Onboard LAN Boot ROM [Disabled] Serial Port1 Address [3F8/IRQ4] Parallel Port Address [378] Parallel Port Mode [ECP] ECP Mode DMA Channel [DMA3] Parallel Port IRQ [IRQ7] Onboard AC’97 Audio [Auto] When set to Auto, the BIOS detects whether you are using any audio device. If an audio device is detected, the onboard audio controller is enable;...

  • Page 69: Pci Pnp

    2.4.5 PCI PnP The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices.

  • Page 70: Usb Configuration

    IRQ-xx assigned to [PCI Device] When set to [PCI Device], the specific IRQ is free for use of PCI/PnP devices. When set to [Reserved], the IRQ is reserved for legacy ISA devices. Configuration options: [PCI Device] [Reserved] 2.4.6 USB Configuration The items in this menu allows you to change the USB-related features.

  • Page 71: Usb Mass Storage Device Configuration

    USB Mass Storage Device Configuration USB Mass Storage Device Configuration USB Mass Storage Reset Delay [20 Sec] No USB Mass Storage device detected USB Mass Storage Reset Delay [20 Sec] Allows you to select the number of seconds POST waits for the USB mass storage device after the start unit command. The message “No USB mass storage device detected”...

  • Page 72: Power Menu

    Power menu The Power menu items allow you to change the settings for the Advanced Power Management (APM). Select an item then press <Enter> to display the configuration options. Suspend Mode [Auto] Repost Video on S3 Resume [No] ACPI 2.0 Support [No] ACPI APIC Support [Enabled] APM Configuration Hardware Monitor 2.5.1 Suspend Mode [Auto] Allows you to select the Advanced Configuration and Power Interface (ACPI) state to be used for system suspend.

  • Page 73: Apm Configuration

    2.5.5 APM Configuration APM Configuration Power Button Mode [On/Off] Restore on AC Power Loss [Power Off] Power On By RTC Alarm [Disabled] Resume On LAN [Disabled] Power On By External Modems [Disabled] Power On By PCI Devices [Disabled] Power On By PS/2 Keyboard [Disabled] Power On By PS/2 Mouse [Disabled] Power Button Mode [On/Off] When the power button is pressed, the system goes into On/Off or Suspend. Restore on AC Power Loss [Power Off] When set to Power Off, the system goes into off state after an AC power loss.

  • Page 74: Hardware Monitor

    Power On By PCI Devices [Disabled] When set to [Enabled], this parameter allows you to turn on the system through a PCI LAN or modem card. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled] Power On By PS/2 Keyboard [Disabled] Allows you to use specific keys on the keyboard to turn on the system.
  • Page 75 CPU Fan Speed [xxxxRPM] or [N/A] The onboard hardware monitor automatically detects and displays the CPU fan speed in rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows N/A. Chassis Fan Speed [xxxxRPM] or [N/A] The onboard hardware monitor automatically detects and displays the chassis fan speed in rotations per minute (RPM).

  • Page 76: Boot Menu

    Boot Device Priority Boot Device Priority 1st Boot Device [1st FLOPPY DRIVE] 2nd Boot Device [PM-ST330620A] 3rd Boot Device [PS-Advansus CD- 1st ~ xxth Boot Device [1st Floppy Drive] Select Screen Select Item These items specify the boot device priority sequence from the available devices. Enter Go to Sub-screen General Help...

  • Page 77: Boot Settings Configuration

    This allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Set this item to [Enabled] to use the Advansus MyLogo™ feature. Add On ROM Display Mode [Force BIOS] Sets the display mode for option ROM.

  • Page 78: Security

    Interrupt 19 Capture [Disabled] When set to [Enabled], this function allows the option ROMs to trap Interrupt 19. Configuration options: [Disabled] [Enabled] 2.6.3 Security The Security menu items allow you to change the system security settings. Select an item then press <Enter> to display the configuration options. Security Settings <Enter> to change password.

  • Page 79: Change User Password

    After you have set a supervisor password, the other items appear to allow you to change other security settings. Security Settings Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password User Access Level [Full Access] Change User Password Clear User Password Password Check [Setup] Select Screen Select Item Change Option General Help Save and Exit Exit User Access Level (Full Access] This item allows you to select the access restriction to the Setup items.

  • Page 80: Clear User Password

    Clear User Password Select this item to clear the user password. Password Check [Setup] When set to [Setup], BIOS checks for user password when accessing the Setup utility. When set to [Always], BIOS checks for user password both when accessing Setup and booting the system.

  • Page 81: Exit Menu

    Exit menu The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Exit Options Exit system setup after saving the Exit & Save Changes changes. Exit & Discard Changes Discard Changes F10 key can be used for this operation.
  • Page 82 2-36 Chapter 2: BIOS setup...
