StarTech.com 35FCREADBU3 Quick Start Manual

Quick start guide
USB 3.0 multi-card memory card reader
35FCREADBU3
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging contents
• 1 x USB 3.0 multi-card memory card reader with integrated USB 3.0
IDC cable
• 1 x package of mounting screws
• 1 x instruction manual

System requirements

• Computer case with an available 3.5 in. front bay
• Computer system with available internal 20-pin USB header port
• Any of the following operating systems:
• Windows® 7 (32-bit or 64-bit)
• Windows 8 (32-bit or 64-bit)
• Windows 8.1 (32-bit or 64-bit)
• Windows Server® 2003
• Windows Server 2008 R2
• Windows Vista®
• Linux® kernel 2.4 or later
Operating system requirements are subject to change. For the latest
requirements, please visit www.startech.com/35FCREADBU3.

Product overview

For the latest information, technical specifications, and support for
this product, please visit www.startech.com/35FCREADBU3.
Front
Installation
Warning! Computer parts can be severely damaged by static
electricity. Before you open your computer case, make sure that
you're properly grounded by wearing an anti-static strap. If an anti-
static strap isn't available, touch a large grounded metal surface for
several seconds to discharge any built-up static electricity.
Install the memory card reader
You can use the 35FCREADBU3 memory card reader to access
multiple types of media cards simulatenously, allowing you to copy
files from or between different types of memory cards at the same
time. If you add multiple memory cards that are the same type,
the memory card reader will only recognize the first card that was
connected.
You can use up to four different slot types at the same time,
including:
*actual product may vary from photos
The SD/MS PRO HG and the Micro SD slots on the card reader share
resources, so only one card can be accessed at a time.
1
5
1 SD UHS-II (standard card, HC card, XC card, MMC,
Mini SD with adapter, Micro SD with adapter)
2 SD/MS PRO HG (Standard card, HC card, XC card, MMC,
Mini SD with adapter, Micro SD with adapter)
3 Micro SD (standard card, HC card, XC card)
4 Power and activity LEDs
5 Compact flash (CF I or II, CF 6.0)
6 Memory stick (Standard, Pro, Duo, Pro Duo, Pro-HG, XC,
Micro MS with adapter)
7 USB 3.0 pass through
• Compact flash slot
• Memory stick slot
• SD UHS-II slot
• SD/MS PRO HG slot
2
3
4
6
7
Manual Revision: 05/07/2015
