StarTech.com 35FCREADBK3 Instruction Manual

Instruction Manual
3.5in Front Bay USB 2.0 22-in-1 Memory Card Reader
35FCREADBK3
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1x Card Reader
• 1x 9-pin IDC USB cable
• 1x Bag of Mounting Screws
• 1x Instruction Manual
System Requirements
• Computer chassis with available 3.5in front bay
• Computer system with available internal 9-pin USB header
• Windows 2000/ XP(32/64-bit)/ Server 2003 (32/64-bit)/ Vista (32/64-
bit)/ 7 / 8 (32/64-bit)/ Server 2008 R2, Linux kernel 2.4 or later
1 2
5
1
2
3
4
5
6
MemoryStickTM (MS/MS Pro/MS Pro Duo)
7
For the most up-to-date information, please visit: www.startech.com
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
35FCREADBK3 o cerca il tuo prodotto tra le
3 4
6 7
Memory Stick Micro (M2™)
x-Picture
SD/MMC/RS MMC
Micro SD/SDHC/SDXC
CFI/CFII
USB Type A Female
migliori offerte di Schede di Memoria e Lettori
Installation
WARNING! Computer parts can be severely damaged by static
electricity. Be sure that you are properly grounded before opening
your computer case. StarTech.com recommends that you wear an
anti-static strap when installing any computer component. If an anti-
static strap is unavailable, discharge yourself of any static electricity
build-up by touching a large grounded metal surface (such as the
computer case) for several seconds.
1. Turn your computer off and any peripherals connected to the
computer (i.e. Printers, external hard drives, etc.). Unplug the
power cable from the rear of the power supply on the back of the
computer and disconnect all peripheral devices.
2. Remove the cover from the computer case. Refer to
documentation for your computer system for details.
3. Remove the cover for a front panel 3.5in bay. Refer to
documentation for your computer system for details.
4. Slide the internal card reader into the 3.5in bay from the outside.
Once the mounting holes along the sides of the card reader line
up with the mounting holes for the 3.5in bay, fasten the card
reader in place. Refer to documentation for your computer system
for details.
5. Connect the USB cable from the rear of the card reader to an
available 9-pin USB header on the motherboard. The connector
is keyed to help prevent incorrect installation. See system or
motherboard documentation for specific details.
6. Place the cover back onto the computer case.
7. Insert the power cable into the socket on the power supply and
reconnect all other connectors removed in Step 1.
8. No driver installation is required, as the operating system should
detect and install it automatically. Once installed, memory cards
may be inserted into the reader and used (only one card at a
time supported).
NOTE: The 35FCREAKBK3 memory card reader supports access to
multiple media card types simultaneously (excluding same type
media), allowing you to copy files from or between different media
cards at the same time. If multiple of the same card type is added,
the card reader will recognize the first card that was connected only.
StarTech.com
*actual product may vary from photos
Manual Revision: 04/19/2013
