VIESMANN
Service instructions
for contractors
Vitocell 300-B
Type EVB
DHW cylinders, 300 and 500 litres
Vitocell 300-V
Type EVI
DHW cylinders, 200 to 500 litres
VITOCELL 300-B
VITOCELL 300-V
Please keep safe.
5692 709 GB
7/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VITOCELL 300-B and is the answer not in the manual?

Questions and answers

Related Manuals for Viessmann VITOCELL 300-B

Summary of Contents for Viessmann VITOCELL 300-B

  • Page 1 VIESMANN Service instructions for contractors Vitocell 300-B Type EVB DHW cylinders, 300 and 500 litres Vitocell 300-V Type EVI DHW cylinders, 200 to 500 litres VITOCELL 300-B VITOCELL 300-V Please keep safe. 5692 709 GB 7/2009...

  • Page 2: Safety Instructions

    Safety instructions Safety instructions Please follow these safety instructions closely to prevent accidents and mate- rial losses. Safety instructions explained ■ all current safety regulations as defined by DIN, EN, DVGW, TRGI, Danger TRF, VDE and all locally applicable This symbol warns against the standards, risk of injury.
  • Page 3 ■ When using gas as fuel, also close the For replacements, use only orig- main gas shut-off valve and safeguard inal spare parts from Viessmann against unauthorised reopening. or those which are approved by ■ Isolate the system from the power sup- Viessmann.

  • Page 4: Table Of Contents

    Steps - commissioning, inspection and maintenance.......... Further details regarding the individual steps............Parts lists Parts list Vitocell 300-B (300 litres)..............10 Parts list Vitocell 300-B (500 litres)..............12 Parts list Vitocell 300-V (200 and 300 litres)............14 Parts list Vitocell 300-V (500 litres)..............16 Commissioning/service reports................

  • Page 5: Commissioning, Inspection, Maintenance

    Commissioning, inspection, maintenance Steps - commissioning, inspection and maintenance For further information regarding the individual steps, see the page indicated Commissioning steps Inspection steps Maintenance steps Page • 1. Filling the DHW cylinder..........• • 2. Inspection and maintenance........... • •...

  • Page 6: Further Details Regarding The Individual Steps

    Commissioning, inspection, maintenance Further details regarding the individual steps Filling the DHW cylinder 1. Fill the DHW cylinder from the DHW 3. Check sensor wells for leaks and side. retighten, if required. Note 4. Check the function of the safety If the DHW cylinder is pressurised, valves according to manufacturer's re-torque the flange cover with a tor-...

  • Page 7: Cleaning The Inside Of The Dhw Cylinder

    Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Cleaning the inside of the DHW cylinder 1. Drain the DHW cylinder from the DHW side. 2. Remove top panel A or hood B, thermal insulation mats C and ther- mometer sensor D.
  • Page 8 Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) 6. Use a chemical cleaning agent to remove hard deposits that cannot be removed by a high pressure cleaner. Please note Cleaning agents containing hydrochloric acid attack the material of the DHW cylinder. Never use such cleaning agents.

  • Page 9: Returning The Dhw Cylinder Into Use

    Commissioning, inspection, maintenance Further details regarding the individual steps (cont.) Returning the DHW cylinder into use 1. Reconnect the DHW cylinder to the pipework. 2. Insert new gaskets H underneath flange lid E or cylinder cap F. 3. Refit flange lid E or cylinder cap F with stainless steel circular blank G and tighten with the required tor- que.

  • Page 10: Parts Lists

    Parts lists Parts list Vitocell 300-B (300 litres) When ordering spare parts: 010 Sensor well (with pos. 009) Quote the type and serial no. (see type 011 Sensor well thermal insulation plate) and the pos. no. of the required 012 Reducer part (as per this parts list).
  • Page 11 Parts lists Parts list Vitocell 300-B (300 litres) (cont.)

  • Page 12: Parts List Vitocell 300-B (500 Litres)

    Parts lists Parts list Vitocell 300-B (500 litres) When ordering spare parts: 011 Sensor retainer Quote the type and serial no. (see type 012 Sensor well (with pos. 011) plate) and the pos. no. of the required 013 Reducer part (as per this parts list).
  • Page 13 Parts lists Parts list Vitocell 300-B (500 litres) (cont.)

  • Page 14: Parts List Vitocell 300-V (200 And 300 Litres)

    Parts lists Parts list Vitocell 300-V (200 and 300 litres) When ordering spare parts: 009 Sensor retainer Quote the type and serial no. (see type 010 Sensor well (with pos. 009) plate) and the pos. no. of the required 011 Sensor well thermal insulation part (as per this parts list).
  • Page 15 Parts lists Parts list Vitocell 300-V (200 and 300 litres) (cont.)

  • Page 16: Parts List Vitocell 300-V (500 Litres)

    015 Gasket 016 Dummy flange (with pos. 015) 001 Lid 017 Thermometer 002 Upper thermal insulation mat II 018 Viessmann logo 003 Lower thermal insulation mat 030 Thermometer cover 004 Cover with thermal insulation 031 Sensor well thermal insulation 005 Thermal insulation jacket...
  • Page 17 Parts lists Parts list Vitocell 300-V (500 litres) (cont.)

  • Page 18: Commissioning/Service Reports

    Commissioning/service reports Commissioning/service reports Commissioning Service Service date: Service Service Service date: Service Service Service date: Service Service Service date: Service Service Service date:...

  • Page 19: Product Parameters

    Product parameters Product parameters Vitocell 300-B Cylinder capacity Standby heat loss kWh/24 h 1.17 1.37 with 45 K temperature differential (volume standby sec- tion) (volume solar section) Vitocell 300-V Cylinder capacity Standby heat loss kWh/24 h with 45 K temperature...

  • Page 20: Accessories

    Vitocell 300-V, type EVI 200 l type EVI 300 l type EVI 500 l Vitocell 300-B, type EVB 300 l type EVB 500 l Cylinder capacity Total width incl. electric immersion heater b (Vitocell 300-B) — 1114 b (Vitocell 300-V) 1137...
  • Page 21 Accessories Accessory specification (cont.) Diagram: Vitocell 300-V...

  • Page 22: Certificates

    Certificates Declaration of conformity We, Viessmann Werke GmbH & Co KG, D-35107 Allendorf, confirm as sole respon- sible body that the products Vitocell 300-B and Vitocell 300-V comply with the following standards: DIN 4753 AD Codes of Practice This product is designated _-0036 in accordance with the following Directives:...
