Summary of Contents for DeDietrich DRP831JEC
- Page 1 COMBI 54 DED 198101/en (07-13)
-
Page 2: Noise Level
Noise level The refrigerator – freezer appliances are cooled by the refrigeration system with a compressor (assisted by fan in certain models) whose operation may produce certain noise. The level of such noise depends upon the location, correct use and age of the appliance. - Page 3 Fault: Cause/Remedy Bulb replacement: • Before replacing the light bulb, disconnect the appliance form the power supply (pull the power cord from the wall socket). A – Use the screwdriver to press the locking hook (in arrow direction), and remove the cover. B –...
-
Page 4: Troubleshooting Guide
Troubleshooting guide Fault: Cause/Remedy The appliance does not • Check if there is power in the socket and if the appliance is operate after connection to the switched on. mains: Cooling system operates • Ambient temperature too high. continuously without •... -
Page 5: Cleaning The Appliance
Cleaning the appliance Prior any cleaning attempt disconnect the appliance from the mains (see the control chapter for ON/OFF function), and pull the power cord from the mains wall outlet. Special antibacterial protection in top layer of inner walls prevents multiplication of bacteria and maintains the interior clean and germ free. -
Page 6: Defrosting The Appliance
Defrosting the appliance Automatic defrosting of Refrigerator needs no special defrosting procedure, because ice the refrigerator deposited at the inner back wall is defrosted automatically. Ice deposited on the inner back wall during the compressor operation is defrosted when the compressor stops operating, and condensed water drops are drained through the outlet in the inner back wall into the drain pan situated above the compressor where it evaporates. - Page 7 Storage of industrially The storage time and recommended temperature for storing frozen food commercially frozen foods is indicated on the packaging. Always follow manufacturer’s instructions for storage and use of frozen food. When shopping be careful to choose only food which is adequately packed and provided with complete data and stored in freezers where the temperature never rises above -18°C.
-
Page 8: Freezing And Storage Of Frozen Food
Freezing and storage of frozen food Storage procedure • Activate the fast freeze function by pressing the button (C) for continuous operation 24 hours prior intended freezing. - control unit I: with knob A, position SUPERFREEZE/ FRESHEXCEL; - control unit II: with key C; - mechanical regulation: knob position approximately between 4 and 6. -
Page 9: Food Safety
Food safety Temperature Indicator The temperature indicator, situated in the coolest part of refrigerator, helps to control correct temperatures of the appliance. Adequate temperature is indicated with O.K. mark. If this mark does not show, the temperature of this compartment is too high. -
Page 10: Storage Of Food In The Fresh Zone
Storage of food in the FRESH ZONE The FRESH ZONE drawer provides storage of wide selection of fresh food longer than in the traditional refrigerator. Food remains fresh for long time and it preserves its taste and nutritive ingredients. It reduces decay and loss of mass, so fruit and vegetables are more fresh and natural. -
Page 11: Storage Of Food In The Refrigerator
Storage of food in the refrigerator Important precautions • Proper use of the appliance, adequately packed food, correct and hints temperature and hygienic precautions produce substantial impact on the quality of stored food. • Always respect the best before date, printed on the packaging. •... - Page 12 Single drawer • Pulling out the drawer: - Pull the drawer towards yourself (in the direction of arrow 1) – as far as the door stopper. On the opposite side, continue to pull the drawer out of the refrigerator (in the direction of arrow 2 –...
-
Page 13: Refrigerator Accessories
• Recommended settings: - when fan is activated: position 1-4, - without the fan: position 4-7. Temperature setting for the refrigerator compartment also indirectly affects the temperature in the freezer compartment. Refrigerator accessories (Equipment depends on the model) Shelf • Shelves can be optionally placed on the guides inside the appliance. -
Page 14: Control Panel - Appliance With Mechanical Regulation
Control panel - appliance with mechanical regulation ON/OFF button The appliance is switched on/off by turning the temperature selector (see Fig.) to any position from 0 to 7. The appliance operation is controlled by turning the thermostat (temperature selecting button) located within the refrigerator cabinet from the position STOP (0) to the position 7 and back. - Page 15 Intermittent sound signal – power failure alarm If the refrigerator or freezer temperature increases excessively due to power failure, this is signaled by the sound alarm (intermittent beep), red light is on, and the display indicates fl ashing maximum temperature digit (max. 9°C for the refrigerator). Fast cooling of the refrigerator The function of fast cooling of the refrigerator interior is activated by pressing the button (K) –...
- Page 16 Refrigerator temperature setting Temperature setting +1°C do +9° span Freezer temperature setting span -16°C to -24°C + fast freeze • Freezer temperature is set by the button (A), and refrigerator temperature by the button (N). • When you press one of temperature setting buttons, the digital display starts fl...
- Page 17 CONTROL UNIT II Valve and no frost system appliance A Freezer temperature setting button H Red LED: indicates alarm state B Freezer temperature digital display: I Refrigerator ON/OFF button indicates temperature span between -16°C J Green LED: indicates refrigerator operation and -24°C.
- Page 18 Fast freezing function Fast freezing function is activated by turning the button (A) arrow (triangle) to the position SUPERFREEZE/FRESHEXCEL. If the function is not switched off manually it stops automatically (after approximately two days of operation). • After the automatic stop of the fast freeze function the appliance switches to regular operation mode at MAX.
-
Page 19: Control Panel - Appliance With Electronical Regulation
Control panel - appliance with electronical regulation CONTROL UNIT I No frost system appliance A ON/OFF and temperature setting button ON/OFF button The appliance is switched on by turning the button (A) towards MAX, and accordingly switched off when the arrow (small triangle) on the button points to the ON/OFF mark (the appliance, however, is still under mains power). -
Page 20: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door Freestanding appliance Necessary tools: ring spanner No.8, screwdriver, torque 25 Tilt the appliance so that the bottom hinge can be unscrewed and proceed with disassembling as shown in the Figure 3. Then fi x the assembly parts again in the opposite turn. Use the attached opposite hinge insert piece. - Page 21 • The appliance is fi tted with spacers to be mounted on the top edge of the condenser. They prevent the rear of the appliance to be pushed too close to the wall. Spacers are fabricated universally regarding the different distance of the condenser from the cabinet, so make sure to position them properly.
-
Page 22: Installation And Connections
Installation and connections Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. Relevant class of the appliance is indicated on the rating plate. Class Ambient temperature SN (subnormal) from + 10°C to + 32°C... -
Page 23: Description Of The Appliance
Description of the appliance Interior equipment of the appliance will typically vary according to the specifi c model. A Refrigerator 1 Fan 2 Interior light 3 Control panel 4 Horizontal bottle rack 5 Adjustable glass shelves 6 Pull-out glass shelf (adjustable height) 7 Removable snack tray 8 Foldable egg rack (closed - 6 eggs, open - 12 eggs) -
Page 24: Environmental Protection
Environmental protection This appliance’s packaging material is recyclable. Help recycle it and protect the environment by dropping it off in the municipal receptacles provided for this purpose. Your appliance also contains a great amount of recyclable material. It is marked with this label to indicate that in countries that are a members of the European Union the used appliances should not be mixed with other waste. -
Page 25: Before Fi Rst Operation
Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. The same recommendation applies to minors using the appliance. - Page 26 Fridge-Freezer Fridge-Freezer (hereinafter: the appliance) consists of two parts: top part is refrigerator and bottom part is upright freezer. Refrigerator is used in households for storage of fresh food at temperatures above 0°C. Freezer is used in households for freezing fresh food and storage of frozen food for up to one year (depending on the type of food).
- Page 27 In the DE DIETRICHproduct range, you will also fi nd a wide choice of hobs, ovens, microwaves,hoods, dishwashers, cookers, freezers, that you can coordinate with your new DE DIETRICHfridge. Visit our website www.dedietrich-electromenager.com, where you will fi nd our latest innovationsas well as useful and complementary information. DE DIETRICH...
- Page 28 INSTRUCTIONS FOR USE Fridge-Freezer...
