Summary of Contents for DeDietrich DRD882YLX

  • Page 1 Freezer - Fridge / User Manual DRD882YLX...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................. 5 1.1 General Safety Warnings ....................5 1.2 Installation warnings .......................9 1.3 Electrical information (For UK type plug) ..............10 1.4 During Usage........................10 2 DESCRIPTION OF THE APPLIANCE ............. 12 3 USING THE APPLIANCE ................12 3.1 Information about New Generation Cooling Technology ..........12 3.2 Display and Control Panel ....................13 3.3 Operating your Fridge Freezer ..................13 3.3.1 Super Freeze Mode ....................13...
  • Page 4 EN - 4...
  • Page 5: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 6 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
  • Page 7 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 8 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
  • Page 9: Installation Warnings

    1.2 Installation warnings • Do not cover the body or top of fridge freezer with lace. This will affect the Before using your fridge freezer for the first performance of your fridge freezer. time, please pay attention to the following •...
  • Page 10: Electrical Information (For Uk Type Plug)

    refrigerator and the back wall at where change a fuse in this type of plug, follow you place the fridge. You can move the the steps below: fridge towards the back wall until that 1. Remove the fuse cover and fuse. point.
  • Page 11 CFC. Therefore, take care not to harm commercial or common use. Such use environment when you are discarding will cause the guarantee of the appliance your old fridges. to be cancelled and our company will not be responsible for any losses incurred. CE Declaration of conformity •...
  • Page 12: Description Of The Appliance

    2 DESCRIPTION OF THE 3 USING THE APPLIANCE APPLIANCE 3.1 Information about New Generation Cooling Technology Fridges with new-generation cooling technology have a different operating system to static fridges. Other (static) fridges may experience a build up of ice in the freezer compartment due to door openings and humidity in the food.
  • Page 13: Display And Control Panel

    3.2 Display and Control Panel 3.3.1 Super Freeze Mode Activating Super Freeze Mode • Press the freezer set button until "SF" is shown on the screen. The buzzer will sound twice and the mode will be set. • Freezer temperature segment will show "SF".
  • Page 14: Economy Mode

    case, super cool mode will continue. 3.3.4 Holiday Mode • Economy and holiday modes cannot be Activating Holiday Mode selected. • Push the "Mode" • Super cool mode can be cancelled in the button until a circle same way it is selected. appears around the Super cool mode will automatically plane symbol.
  • Page 15: Drink Cool Mode

    3.3.5 Drink Cool Mode 3.3.6 Screen Saver Mode Purpose Purpose This mode is used to cool drinks within an This mode saves energy by switching off all adjustable time. control panel lighting when the panel is left inactive. Activating / Deactivating Drink Cool Mode How to Use •...
  • Page 16: Temperature Settings

    any buttons for 1 second, super cool will NOTE: Child lock will also deactivate if flash. the electricity supply is interrupted or if the fridge is disconnected from the mains. • If you continue to press the button, it will restart from +8 °C.
  • Page 17: Temperature Adjustment Warnings

    3.5 Temperature Adjustment Warnings 3.6.1 The Icematic • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency. • Do not start another adjustment while you are already making an adjustment. •...
  • Page 18: The Chiller Shelf

    3.6.2 The Chiller Shelf 3.6.3 The Fresh Dial Fresh dial If the crisper is full, the fresh dial located in front of the crisper should be opened. This allows the air in the crisper and the Chiller shelf humidity rate to be controlled, to increase Keeping food in the Chiller compartment, the life of food within.
  • Page 19: Food Storage

    4 FOOD STORAGE vegetables. Water leaking from meat may contaminate other products in the refrigerator. You should package meat 4.1 Refrigerator Compartment products and clean any leakages on the shelves. For normal operating conditions, set the • Do not put food in front of the air flow temperature of the cooler compartment to passage.
  • Page 20: Freezer Compartment

    The table below is a quick guide to show • Always follow the manufacturer's you the most efficient way to store the instructions on food packaging when major food groups in your refrigerator storing frozen food. If no information is compartment.
  • Page 21 removed and food obstructs the air suction hole, the efficiency of your fridge will reduce. Therefore, take care while loading the freezer compartment and make sure not to cover the air suction hole. Air suction hole NOTE: If you attempt to open the freezer door immediately after closing it, you will find that it will not open easily.
  • Page 22 The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. Maximum storage time Meat and fish Preparation (months) Wrap in foil 6 - 8 Steak Lamb meat Wrap in foil 6 - 8 Wrap in foil...
  • Page 23: Cleaning And Maintenance

    Maximum storage time Vegetables and Fruits Preparation (months) Strawberry and Wash and hull 8 - 12 Blackberry Add 10 % of sugar to the container Cooked fruits Wash and hull the stems 8 - 12 Plum, cherry, sourberry Maximum storage time Thawing time at room Thawing time in oven (months)
  • Page 24: Shipment And Repositioning

    6 SHIPMENT AND REPOSITIONING 6.1 Transportation and Changing Positioning • The original packaging and foam may be kept for re-transportation (optional). • Fasten your appliance with thick packaging, bands or strong cords and follow the instructions for transportation on the packaging. •...
  • Page 25: Before Calling After-Sales Service

    7 BEFORE CALLING AFTER-SALES SERVICE Errors Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels or if a problem occurs with the appliance. Warning codes are displayed in the freezer and cooler indicators. ERROR TYPE MEANING WHAT TO DO...
  • Page 26 ERROR TYPE MEANING WHAT TO DO 1. Set the fridge temperature to a colder value or set Super Cool. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct Likely to occur after: temperature.
  • Page 27: Tips For Saving Energy

    8 TIPS FOR SAVING ENERGY Humidity increases faster if the doors are opened frequently, especially if the 1. Install the appliance in a cool, well- humidity of the room is high. ventilated room, but not in direct sunlight • There is a build-up of water droplets and not near a heat source (such as a on the rear wall.
  • Page 28 52319539...
