Summary of Contents for Magellan GPS Tracker

  • Page 1 GPS Tracker User Manual...

  • Page 2: License Agreement

    LICENSE AGREEMENT Magellan grants you, the purchaser, the right to use the software sup- plied in and with MAGELLAN GPS products (the "SOFTWARE") in the normal operation of the equipment. You may make copies only for your own personal use and for use within your organization.
  • Page 3 GPS Tracker User Manual...
  • Page 4 USE PROPER ACCESSORIES Use only Magellan cables and antennas; the use of non-Magellan cables and antennas may severely degrade performance or damage the receiver, and will void the warranty.

  • Page 5: Table Of Contents

    Table of Contents Introduction ... 1 Packing List ... 1 Features of Your GPS Tracker ... 2 Conventions Used in the Manual ... 2 Getting Started/Initialize ... 3 GPS Tracker Description ... 3 Receiver Accuracy ... 3 GPS Tracker Receiver ... 4 Using the Keypad...
  • Page 6 Basic Operation ... 13 Power Up Sequence ... 13 Navigation Screens ... 13 Using the Status Screen ... 14 Selecting Temp Units and Calibration in your Status Screen ... 15 Using the Position Screen ... 16 Viewing Secondary Coordinate System from the Position Screen ...
  • Page 7 Setting the Speed Average ... 29 Using the Time Screen ... 29 Selecting Time Format ... 30 Saving a Waypoint ... 30 Saving Your Position Fix with a Receiver-Generated Name ... 30 Saving Your Position Fix with a User-Created Name ... 31 Creating a Waypoint ...
  • Page 8 Changing a Waypoint in a Route ... 40 Adding a Waypoint at the End of a Route ... 41 Deleting a Waypoint in a Route ... 41 Saving a Route ... 42 Activating/Deactivating a Route... 42 Reversing a Route... 43 Using Plot View in a Route...
  • Page 9 Selecting Clear Memory ... 59 Selecting NMEA ... 60 Selecting Baud Rate... 60 Troubleshooting ... 61 Commonly Asked Questions ... 62 Contacting Magellan ... 63 NMEA Data Messages ... 64 Available Datums ... 70 Specifications ... 71 Coordinate Systems ... 72 What is GPS? ...
  • Page 10 Accessories ... 77 Antenna Removal ... 78 Glossary ... 79 Index... 83...

  • Page 11: Introduction

    GPS Tracker. Packing List Before you begin, make sure that your package includes the items listed on the box. If any of these items are missing, please contact your local Magellan dealer or distributor. Magellan GPS Tracker...

  • Page 12: Features Of Your Gps Tracker

    Conventions Used in this Manual The Basic Operaton section of this manual is designed to assist you in the use of your GPS Tracker. Each topic in the reference section includes a brief description of the activity chosen and a detailed description with sample screens of how to perform the activity.

  • Page 13: Getting Started/Initialize

    Getting Started/Initialize This section shows you how to begin using your GPS Tracker for the first time. After a brief description of the receiver, it discusses: • Installing batteries. • First time use, initializing the receiver. • Usage. GPS Tracker Description The GPS Tracker has a large, high-resolution display, a detachable antenna for exceptional tracking and stores up to 500 waypoints.

  • Page 14: Gps Tracker Receiver

    GPS Tracker Receiver Detachable Quadrifilar Antenna Display ENTER key GOTO key MENU key QUIT key POWER key NAV key ARROW PAD MARK key LIGHT key Water Seal Battery Caps Magellan GPS Tracker...

  • Page 15: Using The Keypad

    GOTO - Allows selection of a destination for a single leg route GOTO from a list of waypoints. This key also accesses the Man Over Board function. MARK - Creates waypoints or stores the current position. MARK Magellan GPS Tracker...

  • Page 16: Installing The Batteries

    Installing the Batteries The GPS Tracker uses four AA alkaline batteries that are installed from the bottom of the receiver. Use the rings to unscrew the water seal battery caps. Insert the batteries into the battery tubes, with the positive end first, two batteries in each side, and screw the battery caps until securely closed.

  • Page 17: Using Your Gps Tracker

    The almanac tells the receiver which satellites are in view, based on the time, date and location of the receiver. Until the GPS Tracker is initialized, it may not know its location, time or date, therefore, it does not have a reference point to select which satellites to use.

  • Page 18: Holding The Receiver

    300 miles while turned off. Turn the Receiver On To turn your GPS Tracker on, press PWR. Because this is the first time you have used your receiver, a screen will be displayed prompting you to initialize your receiver.

  • Page 19: Input Location Information

    ARROWs to change the time and to toggle between AM and PM. Press ENTER. The GPS Tracker will not automatically change due to daylight savings. You will have to reset the time using SETUP as explained in the Customizing section The cursor moves to the date field.

  • Page 20: Selecting Primary Usage

    Velocity Made Good Course To Steer Estimated Time of Arrival Time To Go Cross Track Error Recorded Position Units of Measure PREFERENCE SET DEFAULTS FOR A PRIMARY USAGE OF: MARINE LAND Land Marine Landmark Waypoint MILES/MPH or NM/KNOTS KM/KPH Magellan GPS Tracker...

  • Page 21: Getting A Fixed Position

    At this point, you should go outside in an area where you can get a clear view of the sky. The GPS Tracker will begin receiving data from the satellites in view and will display the progress on the STATUS screen.

  • Page 22: Creating A Goto

    You will be returned to the POSITION screen with the information on the navigational requirements. Use the NAV key to view the other Navigation screens. GOTO WPT001 027 ˚ 50.2 Magellan GPS Tracker...

  • Page 23: Basic Operation

    PASS, NAV 2, PLOT, ROAD, SPEED and TIME ) provide you with neces- sary information you will need to use the GPS Tracker as a navigational tool. NAV screens can be viewed by pressing NAV from any screen. You can scroll through the NAV screens by repeatedly pressing NAV or the UP/DOWN ARROWs from any NAV screen.

  • Page 24: Using The Status Screen

    Using the Status Screen The Status screen will be the first screen displayed, after the Magellan screen, once the unit is turned on. This screen gives you the general well-being of your GPS Tracker by showing you satellite status and signal strengths, battery life and temperature.

  • Page 25: Selecting Temp Units And Calibration In Your Status Screen

    DOWN ARROWs to highlight your choice and press ENTER. Setting Temperature Calibration. The GPS Tracker comes with a factory default setting that can be changed to accommodate the environment that you are in. This enables the user to calibrate the temperature creating an offset from the factory setting.

  • Page 26: Using The Position Screen

    Automatic Averaging in the POSITION Screen Automatic averaging gives you greater position accuracy. When navigating, your GPS Tracker takes position fixes, however, when you are stationary, at zero speed, the receiver begins averaging mode. Once you begin moving, position averaging ends and the receiver begins displaying instantaneous position fixes while you navigate.

  • Page 27: Using The Nav 1 Screen

    Ideally, when you are navigating, the Position Icon and the Destination Icon should line up, one above the other Magellan GPS Tracker POSITION 34 ˚ 06.52 117˚49.56...

  • Page 28: Customizing The Nav 1 Screen

    You can continue to customize the display or press QUIT to exit. TO: FISH 50.2 3.80 R CUSTOMIZE WPT NAMES WPT NAMES WPT NAMES BRG 027 DST 50.2 SOG 8.2 COG 056 VMG 7.2 01:09P 02H24M 01:09P 36 C BLANK Magellan GPS Tracker...

  • Page 29: Using The Compass Screen

    Steering Indicator displays the bearing of the destination relative to the course over ground. When the arrows are pointed in the same direction, you are on course. The CDI Scale indicates your distance left or right of the courseline. Magellan GPS Tracker TO: HOME Sun Icon 3.52...

  • Page 30: Customizing The Compass Screen

    DST, SOG, COG, VMG, CTS, TMP and Blank. To customize your COMPASS screen, press MENU while viewing the COMPASS screen. Highlight CUSTOMIZE and press ENTER. Use the UP/DOWN ARROWs to select the field you want to change and press ENTER. Magellan GPS Tracker...

  • Page 31: Using The Nav 2 Screen

    UP/DOWN ARROWs to highlight your choice and press ENTER. You will return to the NAV 2 screen, still in the customize mode. You can continue to customize the display or press QUIT to exit. Magellan GPS Tracker CUSTOMIZE WPT NAMES WPT NAMES WPT NAMES BRG 027 DST 50.2...

  • Page 32: Using The Plot Screen

    ARROWs to scroll through the PLOT screen enabling you to create waypoints and routes graphically. TO: FISH 3.52 FISH FISH 2 DOCK BUOY HOME Distance to Destination North Indicator Waypoint Icon Current Position Icon Track History Magellan GPS Tracker...

  • Page 33: Selecting Pan-N-Scan

    INFO and press ENTER. The waypoint information screen will appear in place of the PAN-N-SCAN screen. Press QUIT to return to PAN-N-SCAN with the waypoint name at the top of the screen. Default setting is ON. Magellan GPS Tracker PAN-N-SCAN WPT001...

  • Page 34: Setting Track History

    Setting Plotter Orientation. Under Plotter Orientation, you have three choices TRACK UP (direction you are moving is at the top of the Magellan GPS Tracker...
  • Page 35 MENU. Highlight PLOT SETUP and press ENTER. Use the UP/DOWN ARROWs to select COURSE PROJECTION and press ENTER. A pop-up menu appears allowing you to select OFF or a time. Magellan GPS Tracker WPT NAMES WPT NAMES WPT NAMES ORIENT...

  • Page 36: Setting Hide Data/Show Data

    If you are off course, such that the destination icon is off the screen, an arrow icon will appear to point you in the direction to get back on course. TO: FISH 3.52 Navigation Data Desired Route Magellan GPS Tracker...

  • Page 37: Setting Hide Wpts/Show Wpts

    UP/DOWN ARROWs to highlight your choice and press ENTER. You will return to the ROAD screen, still in the customize mode. You can continue to customize the display or press QUIT to exit. Magellan GPS Tracker SHOW WPTS ICONS ONLY ICON/NAMEUT CUSTOMIZE...

  • Page 38: Using The Speed Screen

    A pop-up window will appear. Select YES or NO and press ENTER. TO: CAMP 14.2 ODOMETER 0 0 5 4 2 TRIP 0 5 4 Average Speed Icon Circumference Bar Graphical Speedometer Odometer Trip Odometer WARNING RESET TRIP TO 000? Magellan GPS Tracker...

  • Page 39: Resetting The Trip Odometer

    The first data field can be customized to correct the current time and to select the time format. Magellan GPS Tracker SPEED AVG TRIP 5 SECONDS 30 SECONDS...

  • Page 40: Selecting Time Format

    This is the fastest way to save your position. To save a waypoint with a receiver-created name, press MARK, MARK. The waypoint will be saved with a receiver-generated name beginning with WPT001, WPT002 and so on. TIME FORMAT LOCAL 24HR LOCAL AM/PM Magellan GPS Tracker...

  • Page 41: Saving Your Position Fix With A User-Created Name

    A waypoint is a recorded position that can be used in a route or a GOTO. You can save up to 500 waypoints in your GPS Tracker and refer back to them at any time, as long as the waypoints have been saved.

  • Page 42: Creating A Goto

    This completes the basic operation of the GPS Tracker. From the informa- tion provided, you can now navigate from place to place quickly and easily. The following chapters provide you with additional information on using your GPS Tracker that build upon what you have learned.

  • Page 43: Working With Waypoints

    Use the ARROWs to highlight the data field you wish to change and press ENTER. Again, use the ARROWs to make your changes. Press ENTER to exit the edit mode for that data field. Magellan GPS Tracker MENU EDIT WPT SORT WPT DELETE WPT...

  • Page 44: Creating/Editing/Deleting A Message In A Waypoint

    DOWN ARROW to highlight CLEAR MSG and press ENTER. Saving Changes to the Selected Waypoint To save your edits, follow the instructions on selecting a waypoint. Highlight SAVE EDITS and press ENTER. EDIT WPT CAMP 34˚06.56N 117˚49.60W 900 FT 11:23:35PM 12JUN97 CREATE MSG SAVE EDITS Magellan GPS Tracker...

  • Page 45: Projecting A Waypoint

    You can also input information into the coordinate fields. Once you have the necessary information in the data fields and the receiver has projected the position, you can save the position by pressing MARK. Magellan GPS Tracker PROJECTION FROM WPT003 G.C.

  • Page 46: Sorting A Waypoint

    ENTER. Highlight the waypoint you wish to delete and press ENTER. Press MENU, highlight DELETE WPT and press ENTER. A pop-up window will appear. Use the UP/ DOWN ARROWs to select YES or NO and press ENTER. WPT SORT ALPHABETIC NEAREST ICON/NAME DELETE DELETE WPT023? Magellan GPS Tracker...

  • Page 47: Working With Routes

    While in the GOTO screen, press MENU, highlight CLEAR GOTO and press ENTER. Your GOTO will be deleted. If there are no active GOTOs, then Clear GOTO will not be displayed in the MENU. Magellan GPS Tracker GOTO DOCK CAMP...

  • Page 48: Creating A Man Over Board Route

    BACKTRACK routes can be deleted as other routes. GOTO DOCK CAMP WPT001 HOTSPT LTEHSE JETTY 027 ˚ 50.2 MENU ACTIVATE VIEW/EDIT REVERSE DELETE BACKTRACK PLOT VIEW WAYPOINTS ROUTES SETUP SUN/MOON FISH/HUNT CONTRAST ALARM/MSG Magellan GPS Tracker...

  • Page 49: Creating A Multi-Leg Route

    To end the creation process, use the UP/DOWN ARROWs to highlight SAVE ROUTE and press ENTER. Press MENU, highlight SAVE ROUTE and press ENTER. Magellan GPS Tracker CREATE SAVE ROUTE ˚ CREATE HOME SAVE ROUTE ˚...

  • Page 50: Viewing/Editing A Route

    While viewing the route you wish to change a waypoint in, use the UP/ DOWN ARROWs to highlight the waypoint that you want to change and press ENTER. MENU ACTIVATE VIEW/EDIT REVERSE DELETE BACKTRACK PLOT VIEW WAYPOINTS ROUTES SETUP SUN/MOON FISH/HUNT CONTRAST ALARM/MSG VIEW/EDIT HOME CAMP SAVE ROUTE ˚ Magellan GPS Tracker...

  • Page 51: Adding A Waypoint At The End Of A Route

    While viewing the route you wish to delete a waypoint from, use the UP/DOWN ARROWs to highlight the waypoint you want to delete and press MENU. Highlight DELETE and press ENTER. Magellan GPS Tracker VIEW/EDIT HOME CAMP SAVE ROUTE ˚...

  • Page 52: Saving A Route

    Press MENU, highlight DEACTIVATE and press ENTER. MENU INSERT DELETE REPLACE SAVE ROUTE WAYPOINTS ROUTES SETUP SUN/MOON FISH/HUNT CONTRAST ALARM/MSG MENU ACTIVATE VIEW/EDIT REVERSE DELETE BACKTRACK PLOT VIEW WAYPOINTS ROUTES SETUP SUN/MOON FISH/HUNT CONTRAST ALARM/MSG Magellan GPS Tracker...

  • Page 53: Reversing A Route

    You can delete the route from your receiver. Press MENU, highlight ROUTES and press ENTER. Highlight the route that you wish to delete, press MENU, highlight DELETE and press ENTER. Magellan GPS Tracker ROUTE MENU MAP N TRACK 1 FISH ...CAMP...

  • Page 54: Working With Map 'N Track

    Delete. This erases the track points in Track History. Backtrack. This activates the BACKTRACK Route by saving the Track History as a 30 leg route and activating it. ROUTE MENU MAP N TRACK 1 FISH ...CAMP EMPTY EMPTY EMPTY LEGS DISTANCE 0.00 Magellan GPS Tracker...

  • Page 55: Auxiliary Functions

    ENTER or use the LEFT/RIGHT ARROWs to toggle between the Sun/Moon data screen and the Fish/Hunt data screens. You can change the AT and ON fields just as you did previously, if desired. Magellan GPS Tracker SUN/MOON ON: 23MAR98 RISE/SET RISE 06:55AM...

  • Page 56: Selecting The Simulate Mode

    Default setting is OFF. SETUP INITIALIZE NAV SCREENS COORD SYSTEM MAP DATUM ELEV MODE TIME FORMAT NAV UNITS TEMP UNITS NORTH REF LIGHT TIMER BEEPER PERSONALIZE CLEAR MEMORY NMEA BAUD RATE SIMULATE WPT NAMES WPT NAMES USER 000˚ Magellan GPS Tracker...

  • Page 57: Selecting Contrast

    Selecting Alarm/Message Accessing the Alarm/Message Menu While navigating, you may decide to set an alarm in your GPS Tracker. The GPS Tracker has four types of alarms: Anchor alarm, which will notify you when your anchored boat has drifted; Arrival alarm, which will notify you when you are within the arrival circle of your destination;...

  • Page 58: Selecting Anchor Alarm

    The alarm will sound until you turn it off. The default is OFF. WPT NAMES WPT NAMES ANCHOR 100FT 250FT 500FT WPT NAMES WPT NAMES ARRIVAL 100FT 250FT 500FT 0.2 MI 0.5 MI 1.0 MI Magellan GPS Tracker...

  • Page 59: Selecting Xte Alarm

    PROXIMITY ALARM and press ENTER. A pop-up screen will appear with your choices for alarm settings of OFF, 100, 250, 500 feet, 0.2, 0.5 and 1.0 miles. Highlight your selection and press ENTER. Magellan GPS Tracker WPT NAMES WPT NAMES 100FT 250FT 500FT 0.2 MI...

  • Page 60: Viewing The Alarm/Msg Menu

    While viewing the Alarm/MSG screen, press MENU. A menu will display a screen option to DEFAULTS and CLEAR MSG. PROX WPTS REEF ROCKS WPT001 WPT002 SAVE WPTS MENU DEFAULTS CLEAR MSG WAYPOINTS ROUTES SETUP SUN/MOON FISH/HUNT CONTRAST ALARM/MSG Magellan GPS Tracker...

  • Page 61: Selecting Alarm Defaults

    CLR MSG to delete the messages. While viewing the Alarm/MSG menu, highlight CLR MSG and press ENTER. A pop-up window will be displayed, select YES or NO and press ENTER. Magellan GPS Tracker WPT NAMES WPT NAMES DEFAULTS RESTORE DEFAULT...
  • Page 62 Magellan GPS Tracker...

  • Page 63: Customizing (Setup)

    SETUP and press ENTER. The Setup Menu will appear, highlight INITIALIZE and press ENTER. Follow the steps requested to initialize, as done when the receiver was initialized the first time (see Getting Started). Magellan GPS Tracker MENU COORD SYS MAP DATUM ELEV MODE...

  • Page 64: Disabling Nav Screens

    Highlight your selection and press ENTER. WPT NAMES WPT NAMES WPT NAMES NAV 1 COORD SYS WPT NAMES WPT NAMES WPT NAMES PRIMARY SECONDARY WPT NAMES WPT NAMES WPT NAMES LAT/LON DEG/MIN.MM DEG/MIN.MMM DEG/MIN/SEC Magellan GPS Tracker...

  • Page 65: Selecting Map Datum

    3D (3-Dimensional). You may find 2D useful if you know the elevation of your position and the elevation will not change. For example, if you are at sea level, you could use 2D because you know that your elevation is zero. Magellan GPS Tracker WPT NAMES WPT NAMES MAP DATUM...

  • Page 66: Selecting Time Format

    WPT NAMES 00000FT SETUP INITIALIZE NAV SCREENS COORD SYSTEM MAP DATUM ELEV MODE TIME FORMAT NAV UNITS TEMP UNITS NORTH REF LIGHT TIMER BEEPER PERSONALIZE CLEAR MEMORY NMEA BAUD RATE SIMULATE TIME FORMAT LOCAL 24HR LOCAL AM/PM Magellan GPS Tracker...

  • Page 67: Selecting Nav Units

    Default setting is NM/KNOTS for marine use. Selecting North Reference The GPS Tracker uses magnetic north as a default reference for all navigation computations. You can change this to true north (good, if you are using a map) or back to magnetic north (default, good to use if you are using a compass) under SETUP.

  • Page 68: Selecting Light Timer

    ENTER. Default setting is ALARM ONLY. LIGHT TIMER WPT NAMES WPT NAMES WPT NAMES ALWAYS ON 15 SECONDS 30 SECONDS 1 MINUTE 2 MINUTES 4 MINUTES BEEPER KEYS ONLY ALARM ONLY KEYS /ALARM Magellan GPS Tracker...

  • Page 69: Selecting Personalize

    Selecting Personalize With the personalize function, you have the option of inputting your name into the GPS Tracker receiver. Press MENU, from any screen, highlight SETUP and press ENTER. Highlight PERSONALIZE and press ENTER. A pop-up menu will be displayed, highlight OFF or ON and press ENTER.

  • Page 70: Selecting Nmea

    Selecting Baud Rate Connection to external devices requires that the baud rate of the data being sent or received by the GPS Tracker be matched to the baud rate of the external device. Your choices are 1200, 4800, 9600 and 19200 baud.

  • Page 71: Troubleshooting

    Availability (SA) can cause the elevation values to fluctuate. Battery life seems shorter than it should be: 1. Make sure that you are using four AA alkaline batteries. Magellan System recommends Eveready Energizers ™ for use in the GPS Tracker.

  • Page 72: Commonly Asked Questions

    Can I use NiCad batteries in my GPS Tracker? Yes. However, the battery life of your GPS Tracker will be diminished as well as the possibility of an incorrect reading on the battery life gauge with the use of NiCad batteries.

  • Page 73: Contacting Magellan

    Representatives are available Monday through Friday from 7 AM to 5 PM, PST. Faxes can be sent to Customer Service at (909) 394-7070. If necessary, you can also return your unit to Magellan for repair (Please call for assistance first). If possible, please notify us before shipping the unit by Parcel Post or UPS, and include a description of the problem, your name, address and a copy of your sales receipt.

  • Page 74: Nmea Data Messages

    NMEA Data Messages Your GPS receiver can be set to output GPS data in the NMEA 0183 version 1.5 or version 2.1 format to interface with other marine devices or equipment. NMEA DATA MESSAGES. NMEA data is output at 4800 baud, 8, N, 1, checksum off.
  • Page 75 8-9 Bearing, Magnetic 10-11Distance, naut. miles Waypoint identifier Geographic Position — Latitude/Longitude GLL,1111.11,a,yyyyy.yy,a,hhmmss.ss,A*hh Latitude, N/S Longitude, E/W UTC of position Status A = Data valid Magellan GPS Tracker 9 10 (A = valid, V = invalid) 9 10 11 12...
  • Page 76 A = perpendicular passed at waypoint Bearing origin to destination, M/T Destination waypoint ID 11-12 Bearing, present position to destination, Magnetic or True 13-14 Heading to steer to destination waypoint, Magnetic or 9 10 12 13 14 True Magellan GPS Tracker...

  • Page 77: Gga Global Positioning System Fix Data

    SC104 Type 1 or 9 update, null field when DGPS is not used Differential reference station ID, 0000-1023 Geographic Position — Latitude/Longitude GLL,1111.11,a,yyyyy.yy,a,hhmmss.ss,A*hh 1-2 Latitude, N/S 2-3 Longitude, E/W UTC of position Status A = Data valid V = Data not valid Magellan GPS Tracker 5 6 7 10 11...

  • Page 78: Gsa Gps Dop And Active Satellites

    GPS DOP and Active Satellites GPS receiver operating mode, satelites used in the naviga- tion solution reported by the $--GGA sentence, and DOP values. 1 2 3 GSA,a,x,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,x.x,x.x,x.x*hh<CR><LF>, Mode: M=Manual, forced to operate in 2D or 3D mode, A=Automatic, allowed to automatically switch 2D/3D...
  • Page 79 Magnetic variation, sense (E or W) CHECKSUM (Mandatory in this sentence) The formats listed are NMEA formats and Magellan receivers may not output all of the information listed for a particular format. A complete copy of the NMEA specifications can be obtained from:...

  • Page 80: Available Datums

    Provisional So. Am. 1956 SAM69 South American 1969 SCHWA Schwarzeck SICIL Sicily SIERR SWISS TANAN Tananarive Observatory 1925 THAI Indian (Thailand, Vietnam) TIMBA Timbalai TOKYO Tokyo USER DEFINED VOIRO WGS72 World Geodetic System 1972 YACAR Yacare ZANDE Zanderij Magellan GPS Tracker...

  • Page 81: Specifications

    Temp. Range: Operating 14˚F to 140˚F to (-10˚C to 60˚C) Storage Power: Source Battery Life Magellan GPS Tracker 12-channel technology, tracks up to 12 satellites to compute and update information with detachable quadrifilar antenna Approximately 15 seconds Approximately 1 minute...

  • Page 82: Coordinate Systems

    (There are 60 seconds to one minute, written as 60"). So a Lat/Lon position coordinate can be expressed in two ways, which your Magellan GPS receiver displays as 25 47.50 or 25 47’30. UTM Coordinate System. Another commonly used coordinate system is...
  • Page 83 Eastings are an east/west measurement, and correspond roughly to longitude. Northings are a north/south measure- ment, and correspond to latitude. This chart shows the position of Magellan Systems described in both Lat/ Lon and UTM coordinates. LAT/LON DEG/MIN 34˚06.58N...

  • Page 84: What Is Gps

    How Does GPS Work? Each GPS satellite transmits its precise location (position and elevation) and the start time of the transmission. A GPS receiver acquires the signal, then measures the interval between transmission and receipt of the signal to determine the distance between the receiver and the satellite, a process called ranging.

  • Page 85: Accuracy

    The DoD civil GPS under policy is that GPS accuracy, as affected by SA, is sufficient for general navigation. In an open environment, it usually is. Even with SA, a GPS receiver will bring you within visual range of a destination or target, and GPS remains the best available source for accurate, repeatable navigation and positioning information.
  • Page 86 Provisional So. Am. 1956 SAM69 South American 1969 SCHWA Schwarzeck SICIL Sicily SIERR SWISS TANAN Tananarive Observatory 1925 THAI Indian (Thailand, Vietnam) TIMBA Timbalai TOKYO Tokyo USER DEFINED VOIRO WGS72 World Geodetic System 1972 YACAR Yacare ZANDE Zanderij Magellan GPS Tracker...
  • Page 87 Temp. Range: Operating 14˚F to 140˚F to (-10˚C to 60˚C) Storage Power: Source Battery Life Magellan GPS Tracker 12-channel technology, tracks up to 12 satellites to compute and update information with detachable quadrifilar antenna Approximately 15 seconds Approximately 1 minute...
  • Page 88 (There are 60 seconds to one minute, written as 60"). So a Lat/Lon position coordinate can be expressed in two ways, which your Magellan GPS receiver displays as 25 47.50 or 25 47’30. UTM Coordinate System. Another commonly used coordinate system is...
  • Page 89 Eastings are an east/west measurement, and correspond roughly to longitude. Northings are a north/south measure- ment, and correspond to latitude. This chart shows the position of Magellan Systems described in both Lat/ Lon and UTM coordinates. LAT/LON DEG/MIN 34˚06.58N...
  • Page 90 How Does GPS Work? Each GPS satellite transmits its precise location (position and elevation) and the start time of the transmission. A GPS receiver acquires the signal, then measures the interval between transmission and receipt of the signal to determine the distance between the receiver and the satellite, a process called ranging.
  • Page 91 The DoD civil GPS under policy is that GPS accuracy, as affected by SA, is sufficient for general navigation. In an open environment, it usually is. Even with SA, a GPS receiver will bring you within visual range of a destination or target, and GPS remains the best available source for accurate, repeatable navigation and positioning information.
  • Page 92 You must also be within range of a differential radio beacon. More Information on GPS For information relating to the operation of your Magellan GPS receiver, call Magellan at (800) 707-9971 and ask for Technical Support. General information on the Global Positioning System and satellite status is available from the Civil GPS Information Center (GPSIC) in Virginia.

  • Page 93: Accessories

    Accessories for your GPS Tracker are available from your Magellan dealer or you can order directly from Magellan using the order card supplied with your receiver or call Magellan at (800) 669-4477 (press 3 twice to place an order). Carrying Case: The carrying case protects your GPS Tracker from the elements and allows you to carry your GPS Tracker on your belt.

  • Page 94: Antenna Removal

    Antenna Removal Antenna Removal. The GPS Tracker has a quadrifilar antenna that can be removed. The antenna may be removed in order to connect an external antenna. To remove the antenna, hold the receiver in one hand and rotate the antenna to the stop at the 1 o’clock position (as shown below).

  • Page 95: Glossary

    Glossary Active Leg Altitude Coordinates Datum Magellan GPS Tracker The segment of a route currently being travelled. The current elevation above sea level. Bearing. The compass direction from your position to a destination, measured to the nearest degree. Course Deviation Indicator. A graphical representa-...
  • Page 96 Same as a waypoint. The angular distance east or west of the prime meridian (Greenwich Meridian) as measured by lines perpendicular to the parallels and converging at the poles from 0˚to 180˚. The direction relative to a magnetic compass. Magellan GPS Tracker...
  • Page 97 A coordinate system describing only Great Britain, similar to UTMs. Used with GRB36 datum. Position coordinates as computed by the GPS Tracker. Speed Over Ground. The speed at which the receiver is moving. Turn. Degrees or direction to turn.
  • Page 98 Magellan GPS Tracker...

  • Page 99: Index

    Course over Ground (COG) 17, 19, 20, 21, 26, 27 Course Projection 25 Customer Service 63 Customize NAV Screens (see Magellan GPS Tracker Disabling NAV Screens) Customizing 53 Date see Time and Date Datums see Map Datums Demo Mode see Simulate...
  • Page 100 Track History 24; clear 24, 59 True North 57 Troubleshooting 61 2D 14, 55-56 Universal Time Coordinated (UTC) 30, 56 Waypoint creating 31; editing 33; hide/show 27; naming 30, 31; saving 11, 30, 34 XTE see Cross Track Error Magellan GPS Tracker...
  • Page 102 960 Overland Court, San Dimas, CA 91773 (909) 394-5000 22-10335-001...
