Summary of Contents for Magellan TR7 CAM
- Page 1 Magellan ® TR7 C Off-Road GPS Navigator Quick Start Guide...
- Page 2 Please check with your state or local law enforcement for applicable regulations regarding mounting to the windshield. The driver should enter data or program the Magellan receiver only when the vehicle is stopped. Only a vehicle passenger should enter data or program the device while the vehicle is moving. It is your responsibility to comply with all traffic laws.
- Page 3 Wi-Fi 5G Band 1 is for indoor use only. Magellan Take-Back Program Magellan’s Take-Back Program provides a way for consumers to recycle certain Magellan equipment. As part of this program, all Magellan GPS models will be accepted. Visit magellanGPS.com for more information.
- Page 4 Getting To Know Your TR7 CAM. 1. Home button 2. Volume up/down 3. Power button 4. Power LED 5. Microphone 6. Touchscreen 7. Speaker 8. Micro-USB connector 9. Camera lens 10. Microphone 11. Memory card slot...
- Page 5 Getting To Know Your TR7 CAM. 1. Map: Tap to open the Map screen. 2. Off-Road Trails: Quick search for off-road trails nearby. 3. OHV Areas: Quick search for OHV areas nearby. 4. Journal: Contains your Logs & Plans. 5. Search: Search for Trails, Tracks, POIs, etc.
-
Page 6: Charge The Device
1. Power On. Press and hold the Power button on the top of your device. Within seconds, you’ll see the Magellan logo, and your device will boot up. 2. Charge the Device. Using the included AC Adapter or Vehicle Power Adapter (VPA): 1. -
Page 7: Mount The Device
Setting Up. 3. Mount the Device. Attach your device to the included mount and use suction cup base to adhere your device to your vehicle’s windshield (or dashboard). For best image quality, mount your device as follows: 1. Clean the area of the windshield where you intend to mount the device. Attach the mount to the device by inserting the camera lens through the centre opening of the mounting plate. -
Page 8: Get Started
Get Started. 1. Connect to WIFI. 1. Press and hold the Power button to turn the device on. 2. Tap Settings from the TRX Dashboard. 3. Scroll down to WIFI > tap the check box next to the WIFI option to see available networks. 4. -
Page 9: Get A Gps Signal
If you used an existing MagellanGPS.com account, your TRX will be registered to that account. A MagellanGPS.com account will also be created if you’re new to Magellan and you’re registering an email address for the first time. Go to www.TRXTrailhead.com once you’ve created your account >... - Page 10 5. Search For Trails. Your TRX helps you filter for Trails, Tracks, Trips, or POIs around you. You can also search for map data in other locales no matter their distance from your current location. 1. Tap Search from the TRX Dashboard. 2.
-
Page 11: Take Photos And Videos
Log Your Tracks. 1. Tap Map from the TRX Dashboard. The Map Screen opens to free driving mode. 2. Tap to start Tracking or to pause Tracking. Take Photos and Videos. To take photos and videos with your TRX during the Track or along a Trail: 1. -
Page 12: Auto Record
Auto record You can enable "Auto record" to capture video footage automatically along the Trail. 1. Plan your Trail. 2. Tap Follow > Start to End or End to Start. 3. Tap Begin > select the recording mode: Normal recording, Normal recording with gauge or Timelapse recording. - Page 13 Backtrack. to follow the Track you just created back to its start, in reverse. Finish and Save Track. 1. Tap while Tracking. 2. Enter a name for the track. 3. Enter details to calculate a difficulty rating. 4. Tap Save to see your stats and achievements. Note: Entering Track details is optional when you first save the Track, but mandatory before publishing a Track on www.TRXTrailhead.com.
-
Page 14: Trx Trailhead
TRX Trailhead. Go to www.TRXTrailhead.com to view your Journal, plan custom routes to follow, share your Tracks with other TRX users, and more. Learn all about TRX Trailhead at: https://www.magellangps.com/about-trxtrailhead... -
Page 15: Warranty
CONSUMER PURCHASER OF THIS PRODUCT. (b) In the event of a defect, Magellan will, at its discretion, repair or replace the hardware product with a product of like kind or quality, which may be new or reconditioned, with no charge to the purchaser for parts or labor. - Page 16 GPS. (Note: Magellan GPS receivers use GPS or GPS+GLONASS to obtain position, velocity and time information. GPS is operated by the U.S. Government and GLONASS...
- Page 17 This limited warranty is governed by the laws of the State of California, without reference to its conflict of law provisions or the U.N. Convention on Contracts for the International Sale of Goods, and shall benefit Magellan, its successors and assigns. This warranty does not affect the consumer’s statutory rights under applicable laws in force in their locality, nor the customer’s rights against the dealer arising from their sales/purchase...
- Page 18 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 19 © 20 MiTAC . The Magellan logo and Magellan are registered trademarks of MiTAC, and OneTouch is a trademark of MiTAC and are used under license by MiTAC. All rights reserved. All other trademarks and registered trademarks are property of...
