Technical Data

Product
Range
Nominal Operating
Differential
Adjustment
Contact Action
Material and Finish
Thermometer
Mounting
Wiring Connections
Shipping Weight
Agency Listings
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
Controls Group
507 E. Michigan Street
P.O. Box 423
Milwaukee, WI 53201
T28 Fan Coil Thermostat
Thermostat 55 to 95°F (12 to 35°C)
Thermometer 55 to 85°F (12 to 30°C)
Heating 0.6F° (0.3C°)
Cooling 1F° (0.5C°) for typical 120 V Fan Coil Valve Loads
Heating-Cooling Models with Automatic Changeover (T28D) have a 6F° (3.3C°)
Differential from Heating On to Cooling On
Cool to Warm
Snap-acting Bimetal-operated
Baseplate Cold Rolled Steel, Baked on Beige Paint
Cover Cold Rolled Steel, Baked on Ivory Paint
Bimetal Type for Accuracy and Clarity, may be Field Adjusted
Without Fan Switch Standard Outlet Box with Captive Screws
With Fan Switch Mounts to a Two-Gang Switch Box
Color Coded 18 AWG Wire Leads, 6 in. (152 mm) Long
Individual Pack - 1.0 lb (0.45 kg)
Without Fan Switch
Overpack of 20 Units - 23.6 lb (10.7 kg)
Individual Pack - 1.3 lb (0.59 kg)
With Fan Switch
Overpack of 20 units - 29.5 lb (13.4 kg)
UL Listed: File E6688, CCN XAPX
T28 Fan Coil Thermostat Installation Instructions
