Front/Rear view
1
Low Level Input
1
High Level Input
2
Gain Controll
3
High pass switch
4
High pass cutting adjustment
5
Multiplayer x1/x10 switch
6
Steroe Mono input selector
7
Low pass switch
8
Low pass cutting adjustment
9
Multiplayer x1/x10 switch
10
Led indicator
11
Fuse
12
12V (DC) power terminal
13
Remote terminal
14
GND terminal
15
+ Left channel terminal (+ MONO)
16
- Left channel terminal
17
+ Rigth channel terminal
18
- Rigth channel terminal (- MONO)
19
2
3
5
6
4
12
13
14
01
7
8
9
10
15
16
17 18
11
19
