Procedure 2
Gently pull the tray out until it reaches the end of its travel (Approx. 100mm)
Insert the CD ROM (label side up). Push the CD tray back in until it can be
heard to clock and the CD activates.
Note: The CD will only work reliably when the LCD angle is in its maximum or
minimum position.

2.5 Connectors

All connections are located on the underside of the unit.
