Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What's in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Front and Back Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting up the Delta 1010-AI with your Delta 1010 . . . . . . . . . . . . . . . . . . . . . . 4
Hooking Up Your ADAT Optical Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using Your Delta 1010-AI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ADAT to Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ADAT to Analog Outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Analog Ins to ADAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ADAT Thru . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mixed Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Standalone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Master Clock Settings and the Delta 1010-AI . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Synchronizing your ADATs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Delta 1010-AI
MANUAL
™
Advertisement
Table of Contents
Related Manuals for M-Audio DELTA 1010-AI
Summary of Contents for M-Audio DELTA 1010-AI
-
Page 1: Table Of Contents
Standalone Mode ..........9 Master Clock Settings and the Delta 1010-AI ......10 Synchronizing your ADATs . -
Page 2: Introduction
Introduction Congratulations on your purchase of the Delta 1010 ADAT Interface, designed and manufactured by M Audio. The Delta 1010-AI is a companion to the Delta 1010 PCI Recording System, and when used together, the Delta 1010-AI will add ADAT Optical 8-channel input and output capability to your Delta 1010. -
Page 3: Front And Back Panel Descriptions
4. ADAT to Analog Outs Button: Pressing this button and locking it to the “in” position will enable “ADAT to Analog Outs” mode. The incoming Delta 1010-AI ADAT signal will then be routed directly to the analog outs on the Delta 1010 rack unit. -
Page 4: Setting Up The Delta 1010-Ai With Your Delta 1010
“host card,” which has been properly seated and secured in one of your computer’s PCI expansion slots. 2. Connect the female end of the supplied 25-pin cable to the Delta 1010-AI’s “To Delta 1010 Host Card” connector on the back of the Delta 1010-AI. -
Page 5: Hooking Up Your Adat Optical Device
ADAT (or other 8-channel ADAT optical capable device). 2. Plug the other end of your optical cable into the ADAT Optical “In” jack of the Delta 1010-AI. 3. Plug one end of the second optical cable into the ADAT Optical “Out” jack of the Delta 1010-AI. -
Page 6: Using Your Delta 1010-Ai
In t Using Your Delta 1010-AI Adding the Delta 1010-AI to the Delta 1010 Recording System gives you the ability to convert your Delta’s 8 analog inputs into one ADAT Optical input and its 8 analog outputs into one ADAT Optical output. Your Delta 1010-AI and the Delta 1010 rack mount unit can also be used in a “standalone”... - Page 7 1 through 8 are routed to the ADAT Optical out of the Delta 1010-AI in addition to the Delta 1010 analog outs 1 through 8 on the 1010’s rack mount unit “by default.” All other Delta 1010-AI modes are bypassed.
-
Page 8: Adat To Host
ADAT to Analog Outs: With this mode enabled, the ADAT Optical input on the Delta 1010-AI is routed through the Delta 1010 rack mount unit 24 bit D/A converters to analog outs 1 through 8. The audio outs of the Delta 1010 PCI card, which are normally routed to the analog outs of the 1010’s rack unit, are... -
Page 9: Analog Ins To Adat
Delta 1010-AI will trigger the Delta 1010 rack unit to power up. When the Delta 1010-AI is not connected to the host computer or the when the... -
Page 10: Master Clock Settings And The Delta 1010-Ai
“wordclock” from that incoming digital signal so that all digital audio sampling clocks are synchronized. When the host computer Delta 1010 PCI card, the Delta 1010-AI, and the Delta rack unit are connected and powered, the Delta control panel’s “Master Clock” setting in the Hardware Settings page must be set to “Wordclock”... -
Page 11: Synchronizing Your Adats
ADAT optical signal at the input of the Delta 1010-AI, in conjunction with having selected “Wordclock” in the Hardware Settings page of the Delta control panel (see “Using Your Delta 1010-AI “ADAT to Host”... -
Page 12: Limited Lifetime Warranty
Limited Lifetime Warranty MIDIMAN warrants that this product is free of defects in materials and workmanship under normal use so long as the product is: owned by the original purchaser; the original purchaser has proof of purchase from an authorized MIDIMAN dealer; and the purchaser has registered his/her ownership of the product by sending in the completed warranty card.
