Parts Listing - Body Flex Sports Rider BR 1830 Owner's Manual

# Descriptoin
101 Main Frame
102 Front Stabilizer
103 Rear Stabilizer
104L Left Coupler Bar
104R Right Coupler Bar
105 Hex Bolt (M10x55 mm)
106L Left Pedal Tube
106R Right Pedal Tube
107L Left Handle Bar
107R Right Handle Bar
108L Left Chain Cover
108R Right Chain Cover
109 Fan Wheel (φ503x55 mm)
110 Spring (φ1.8x32xφ10)
111 Pedal
112 Handlebar Axle (φ16x410 mm)
113 Round End Cap (φ50 mm)
114 Foam Grip (φ23x5x275 mm)
115 Round Inner Plug (φ25x2)
116 Handlebar Sleeve (φ28.5xφ25.4x84 mm) 153 Fly Wheel (φ30.5x77 mm)
117 Knob Bolt (M8x36 mm)
118A Front Rollers
119 Bushing (φ24x12xφ16.1 mm)
120 Bushing (φ14x10xφ10.1 mm)
121 Bushing (φ18x14xφ10.1 mm)
122 Fan Wheel Axle (M10x150 mm)
123 Nut (M10x1xB5)
124 Adjuster Bolt (M6x36 mm)
125 Nut (M10x1xB10xφ20 S15)
126 Sensor Wire
127 Crankshaft
128 Washer for Crankshaft
129 Washer for Crankshaft
130L Left Crankshaft Bearing Collar
130R Right Crankshaft Bearing Collar
131 Crankshaft Bearing Set
132 Bearing Brace
133 Left Nut for Crankshaft
BR1830

Parts Listing

The following parts list describes all of the parts illustrated on the
exploded diagram on the following page. Please note, most of
these parts are already pre-assembled on your unit.
# Descriptoin
134 Chain (1/4"x204 Links)
135 Friction Belt (1150L mm)
136 Tension Adjustment Knob
137 Square Inner Plug (口30 mm)
138 Screw (ST4.8x20 mm)
139 Screw (ST4.8x45 mm)
140 Screw (ST4.8x16 mm)
141 Cap (S13)
142 Cap (S16)
143 Arc Washer (φ10x2.0xφ25xR28)
144 Hex Bolt (M10x45 mm)
145 Nylon Nut (M10)
146 Carriage Bolt (M10x57 mm)
147 Nut (M10)
148 Left Nylon Nut (B0.5x20 S19)
149 Right Nylon Nut (B0.5x20 S19)
150 Electronic Monitor
151 Spring Washer (D12)
152 Nut (M6)
154 Lock Pin for Pedal Hinge Bolt (φ3x16 mm)
155 Chain Wheel (1/4"xφ165x2.6)
156 Washer (φ10.2xφ25x2 mm)
157 Screw (M5x16 mm)
158 Round Inner Plug (φ32x1.5)
159A Hex Bolt (M6x48 mm)
Nylon Nut (M6)
160A
161 Nut (M10x1.0)
162 Right Pedal Hinge Bolt
163 Left Pedal Hinge Bolt
164 Special Washer (φ25xφ13x17x3.0)
165 U Bracket
166 Pedal Connection Joint
167 Electronic Monitor Base
168 Tool 1 (2-S17,S19)
169 Tool 2 (S8)
170 Tool 3 (S13-14-15)
171 Washer (φ10.2xφ20x2 mm)
Page 3
