- Page 1 BR 1830 Elliptical Elliptical * This item is for consumer use only and it is not meant for commercial use. OWN ER’ S MA NUAL...
-
Page 2: General Information
Warranty this manual carefully before commencing the assembly of your product or starting to Body Flex Sports warrants your product for exercise. a period of 1 year for the frame and 90 days on all parts if the item is used for the intended •... - Page 3 Hardware & Tool List The following parts list describes all of the parts illustrated on the exploded diagram on the following page. Please note, most of these parts are already pre-assembled on your unit. Bolt #105 Hex Bolt (M10x55 mm) #144 Hex Bolt (M10x45 mm) [2 Pieces] [4 Pieces]...
-
Page 4: Parts Listing
Parts Listing The following parts list describes all of the parts illustrated on the exploded diagram on the following page. Please note, most of these parts are already pre-assembled on your unit. Descriptoin Descriptoin Main Frame 134 Chain (1/4"x204 Links) Front Stabilizer 135 Friction Belt (1150L mm) Rear Stabilizer... -
Page 5: Exploded Diagram
Exploded Diagram The following diagram is provided to help you familiarize yourself with the parts and hardware that will be used during the assembly process. Please note that not all of the parts and hardware you see here will be used while you are assembling the machine because some of these items are already pre-installed. -
Page 6: Assembly Instructions
Assembly Instructions A s s e m b l y S t e p 1 Hardware & Tool Required Bolt With the help of an assistant, attach the Rear Stabilizer (#103) to the rear of the Main Frame (#101). Insert two Carriage Bolts (#146) through the Rear Stabilizer (#103) followed by the rear of the Main Frame (#101). - Page 7 Assembly Instructions A s s e m b l y S t e p 2 Hardware & Tool Required Remove the Nylon Nuts (#145) and Washers (#156) that Washer are pre-assembled on the Handlebar Axle (#112) and set them aside as they will be used in a later process. Insert the Handlebar Axle (#112) through the main frame.
- Page 8 Assembly Instructions A s s e m b l y S t e p 3 Remove Hex Bolts (#105) and Nylon Nuts (#145) that are pre-assembled on the Pedal Connection Joint (#166) and set them aside as they will be used in a later process. Attach the Pedal Connection Joint (#166) to the Right Pedal Tube (#106R).
- Page 9 Assembly Instructions A s s e m b l y S t e p 3 IMPORTANT: Secure both pedal hinge bolts every 30 days. Through regular use, the pedal hinge bolts may still come loose even when the initial assembly was secure. DO NOT operate the Body Rider when these parts are loose! WARNING: Failure to keep these parts securely fastened will severely damage your Body Rider and may cause injury to the user.
- Page 10 Assembly Instructions A s s e m b l y S t e p 4 Hardware & Tool Required Attach the Right Pedal (#111) to the Right Pedal Tube Bolt (#106R) and secure them together using two Hex Bolts (#144) and two Nylon Nuts (#145). #144 Hex Bolt (M10x45 mm) [4 Pieces] Repeat this process on the other side.
- Page 11 Assembly Instructions Hardware & Tool Required A s s e m b l y S t e p 5 Bolt A. Handlebar Assembly: 1). Dual-action mode: To allow Left/Right Handlebar (#107L/107R) to move along with the movement of #157 Screw (M5x16 mm) [2 Pieces] the Pedals (#111), attach the Left/Right Handlebar (#107L/107R) to the Left/Right Coupler Bar (#104L Others...
- Page 12 Assembly Instructions T e n s i o n A d j u s t m e n t The assembly of your Body Rider is now complete. As you try it for the first time, you should adjust the tension to a desirable level before you begin a full workout.
-
Page 13: Safety Instructions
Safety Instructions • Make sure all bolts are tightened. • Check for loose parts and components • Check to see if there are any tears or bends in the welding or metal. • Be sure that all adjustment locking devices and safety devices are properly engaged prior to use! BR1830 Page 12... -
Page 14: Computer Operation
Computer Operation SPECIFICATIONS: TIME………………………………………0:00-99:59 SPEED……………………………………0.0-99ML/H DISTANCE ……………………………0.0-999.9ML CALORIES………………………………0.0-9999CAL KEY FUNCTION: MODE: This key lets you to select and lock on to a particular function you want. OPERATION PROCEDURES: 1. AUTO ON/OFF: ◆ The system turns on when any key is depressed of when it receives an input from the speed sensor. - Page 15 Warm-Up Instructions Before use, you must read and understand all instructions & warning stated in this Owner's Manual as well as posted on the equipment. The following flexibility exercises are provided to you as a means to prevent injury while you are exercising. A proper warm-up routine decreases the chance of injuring your muscles while you are exercising.
- Page 16 Warm-Up Instructions Trunk Flexion, Prone 1. Assume the depicted position on your hands and knees. Stretch your hands out in front of you and then slowly start to pull them back in toward your body as you tuck your chin and arch your back upward. 2.
-
Page 17: Proof Of Purchase
Proof of purchase Model Number BR 1830 version: 11-12-2010 BR 1830... - Page 18 This page intentionally left blank...
- Page 19 This page intentionally left blank...
- Page 20 Body Flex Sports, Inc. • 21717 Ferrero Parkway, Walnut, CA 91789 • Telephone: (888) 266 - 6789 • Email: info@bodyflexsports.com...
