Page 1
FX -318 Instruction Manual - English Antenna LCD Screen - Displays the current channel selection and other Ear/Mic/Charge radio symbols. jack PTT (PUSH to TALK) button –Press and hold to transmit. FX-318 PWR(POWER) button – Press CALL button and hold to turn...
Page 2
Belt Clip latch 2. Installation 2.1 Removing the Belt Clip a. Pull the Belt Clip latch forward (away from the FX-318) b. While pulling the Belt clip latch, push up the Belt clip as shown in Figure1. 2.2 Installing the Belt Clip a.
Page 3
f. Charging the batteries (using adaptor) Lift the charge socket cover located on the upper side of the handset. Insert the round connector of the 9.0V DC/300mA adaptor into the charge jack. Plug the mains adaptor into a 230-240VAC,50Hz,main socket with the switch on the socket set to OFF.
Page 4
speaker volume. 3.4 Changing Channels The FX-318 has 8 available channels, to communicate with other FX-318 users within a range, you must all have your FX-318 tuned to the same channel. a. Press the MENU button once, the current channel number flashes on the LCD screen.
Page 5
current channel. Press and hold the MENU and DOWN buttons at the same time. “RX” icon will be displayed on the LCD screen. Your FX-318 will pick up signals on the current channel, including background noise. Press the MENU button to stop the channel monitoring.
Page 6
3.9 Setting the Roger Beep The Roger Beep is a tone which is automatically transmitted whenever the PTT button is released. This alerts the receiving party to inform that you have intentionally ended the transmission, and you are now in receive mode. Press the MENU button 10 times, the “R0”...
Page 7
Press and hold the CALL button to exit the Stop watch function and return to standby mode. 5.3 LCD Screen Back Light Every time a button is pressed (except PTT and CALL button), the LCD screen back light will illuminate for 4 seconds. 5.4 Microphone/Earphone/Charge Jack The FX-318 is equipped with an auxiliary microphone, earphone, and charge jack located at the upper side of the unit.
Page 8
BRONDI S.p.A. www.brondi.it info@brondi.it Version : July 22, 2014...
