For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
Model 23348
42664-01 • 06/09/08
Advertisement
Table of Contents
Related Manuals for Hunter 23348
Summary of Contents for Hunter 23348
- Page 1 For Your Records and Warranty Assistance Ceiling Fans Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ Model 23348 For reference also attach your receipt or a copy of your receipt to the manual. 42664-01 • 06/09/08...
-
Page 2: Table Of Contents
Fan .......11 use a solid-state speed control with this fan. Use only Hunter speed 9 • Troubleshooting ....12 controls. © 2008 Hunter Fan Company 42664-01 • 06/09/08 • Hunter Fan Company... - Page 3 Installer’s Choice and Optional Accessories Understanding Mounting and Installer’ s Choice® Support Brace Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include Ceiling instructions for all three Installer’s Choice mounting methods. Standard Outlet Box Mounting Considering Optional Accessories Style Consider using Hunter’s optional accessories, including a wall-mounted or remote speed control. To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls.
-
Page 4: Getting Ready
1 • Getting Ready To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit • Standard screwdriver (magnetic tip recommended) • Phillips-head screwdriver (magnetic tip recommended) • Wrench or pliers... -
Page 5: Installing The Ceiling Plate
Note: The isolators should be flush against the ceiling. 2-6. Pass the screws through the slotted holes in the ceiling plate into the pilot holes you drilled. Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Ceiling Plate Flat Washer 3” Wood Steps 2-3 – 2-6 Screw 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 6: Assembling The Blades
The top housing will rest on top of the adapter and should not touch Barrel Nuts the motor. Step 3-2 Blade Iron Allen Wrench Armature Screw Blade Mounting Step 3-3 Housing Screw Cover Screws 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 7: Assembling And Hanging The Fan
The adapter cover and adapter cover grommet are not used for low profile mounting. 4-4. Remove the set screw from the adapter. 4-5. Place the low profile washer (lip up) into the canopy. Be sure the green ground wire is pointing up toward the ceiling. 4-6. Align the holes in the washer with the holes in the adapter. Assemble securely with three low profile screws. Low Profile Screw 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 8: Wiring The Fan
CAUTION: Be sure no bare wire or wire strands are visible after making connections. 5-6. Turn the splices upward and push them carefully back through the ceiling plate into the outlet box. 5-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 9: Installing The Canopy And Canopy
Note: Should you need to remove the trim ring, press firmly on Canopy opposite sides of the trim ring directly above the groove in the Trim hanger ball. The tabs will flex out releasing the canopy trim ring. Ring Canopy Screw 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 10: Installing The Wall Control
Decora®-style switch plate at your local home center or hardware store. Decora® is a regsitered trademark of Leviton Manufacturing Corporation. 7-6. Slide the round wall control knob onto the shaft sticking out of the wall box assembly. Step 7-3 7-7. Turn the circuit breaker back on. Wall Shaft 7-8. To operate fan, turn the wall control knob to the desired speed. Plate Knob Wire Connector Wall Box Assembly Steps 7-4 – 7-5 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 11: Fan
Clean painted and high-gloss blades in the same manner as the fan finish. In cold weather, use upward air flow pattern To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 42664-01 • 06/09/08 • Hunter Fan Company... -
Page 12: Troubleshooting
1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade iron screws. 3. Turn power off, support fan very carefully, and check that the hanger ball is properly seated. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 42664-01 • 06/09/08 • Hunter Fan Company...
