Contents Environmental Information ........2 Appendix C: AV and HDMI Signal Compatibility (Input Signal Types) ..........22 Accessories included ..........3 Appendix D: Supported File Formats for USB Media TV - Features ............3 Browser ..............23 Safety Precautions and Important Information ..3 Appendix E: Supported DVI Resolutions ....
Power cord and plug Screen • The power cord plug should be easily accessible. If • Occasionally, a few non-active pixels may appear there is lightning or storms, or if the TV is not going on the screen as a fixed blue, green or red point. to be used for a while (e.g.
Accessories included Safety Precautions and Important Information Remote Control Batteries: 2 x AAA Please read these instructions fully before installing or operating. Instruction Book Side AV Connection Cable Preparation WiFi Dongle Place the device on a solid even surface. For ventilation purposes, leave a free space of at least USB Cable 10 cm all around the set.
Operation with the Buttons on the Viewing the TV Volume Setting You can move the control switch upward or downward for changing the volume. To increase volume, please move the switch upward. Move the switch downward to decrease the volume. A volume level scale (slider) will be displayed on the screen.
Remote Control 1. Standby / On 2. Channel list 3. Volume up-down 4. Menu on/off 5. OK / Channel list / Confirm 6. Return / Back 7. Internet Portal 8. My button 1 / Youtube (*) 9. My button 2 (**) 10.
Page 7
Connections NOTE: When connecting a device via the YPbPr or Side AV input, you must use the supplied connection cables to enable connection. See the illustrations above. | To enable PC audio, you will need to use the PC/YPBPR CONNECTION cable’s WHITE &...
Inserting the Batteries into the Remote Control 1. Lift the cover on the back of the remote upward gently. 2. Install two AAA batteries. Make sure to match the + and - ends of the batteries in the battery compartment (observe the correct polarity). 3.
Media Browser Menu You can play photo, music, and movie files stored on a USB disk by connecting it to your TV. Connect a USB disk to one of the USB inputs located on the side of the TV. NOTE: You can press MENU button to cancel. After all the available stations are stored, the Channel List will be displayed on the screen.
Sorting Channel List Quick Menu You can select which broadcasts will be listed in the The Quick Settings menu allows you to access some channel list. To display specific types of broadcast, options quickly. This menu includes Power Save Mode, you should use the Active channel list setting.
Menu Features and Functions Picture Menu Contents You can change the picture mode to suit your preference or requirements. The Picture Mode mode can be set to one of these options: Cinema, Game, Sport, Dynamic and Natural. Contrast Sets the lightness and darkness values of the screen. Brightness Sets the brightness value for the screen.
Page 12
Menu Features and Functions Advanced Settings Dot Clock Dot Clock adjustments correct the interference that appear as vertical banding in (in PC mode) dot intensive presentations like spreadsheets or paragraphs or text in smaller fonts. Depending on the resolution and scan frequency that you input to the TV set, you Phase (in PC mode) may see a hazy or noisy picture on the screen.
Page 13
Menu Features and Functions Settings Menu Contents Conditional Access Controls conditional access modules when available. Language Configures language settings. Parental Configures parental settings. Timers Sets timers for selected programmes. (USB Record) Recording Displays the recording configuration menu. Configuration Date/Time Sets date and time. Sources Enables or disables selected source options.
Set Timer / Delete Timer Electronic Programme Guide (EPG) After you have selected a programme in the EPG Some, but not all channels send information about the menu, press the OK button and the Options screen current and next programmes. Press the “ - EPG”...
Record, Play, Pause, Display (for PlayListDialog) keys Press the (STOP) button to stop a playback and can not be used when teletext is ON. If a recording return to the Recordings Library. starts from the timer when teletext is ON, teletext Slow Forward is automatically turned off.
• Do not spray cleaner directly onto the surface of the • PC/HDD/Media Player or any other devices that are product.This may result in discoloration and cracks DLNA 1.5 compatible should be used with a wired and may cause the screen display to peel off. connection for higher playback quality.
• The location where the transmission is most effective Wireless Connectivity differs depending on the usage environment. Connecting to a Wireless Network • The Wireless LAN adaptor should be connected directly to the TV’s USB port. USB hubs are not supported. IMPORTANT: USB dongle (supplied) is required to use wireless network features.
To disconnect from a wireless network, you should Connectivity Troubleshooting highlight Configuration Status and press OK. Wireless Network Not Available • Ensure that any firewalls of your network allow the TV wireless connection. • Ensure the USB WiFi dongle (supplied) is plugged in fully.
To play other media types from this screen, you must DLNA go back to main Media Browser screen and select DLNA support is only available in the Media Browser the media type as desired and then perform the folder mode. To enable folder mode, go to the network selection again.
iPlayer Application Software Upgrade You can access BBC iPlayer using your TV. To do Your TV is capable of finding and updating this, an active internet connection is required. (See automatically via the Aerial signal or over the Internet. connecting to a Wired/Wireless Network section to Background search and upgrade mode connect your TV to internet).
Licence Notifications Manufactured under license from Dolby Laboratories. TRADEMARK ACKNOWLEDGMENT “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. “DLNA , the DLNA Logo and DLNA CERTIFIED ® ® trademarks, service marks, or certification marks of the Digital Living Network Alliance.” “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.”...
Appendix A: Nero MediaHome Installation This software is compatible with Windows XP and Windows 7. Note: To use DLNA function, this software should be installed to your PC. To install Nero MediaHome onto your computer. 1) Insert the Nero MediaHome installation disc into your optical disc drive. 2) The Nero MultiInstaller screen will open automatically.
Appendix B: PC Input Typical Display Appendix C: AV and HDMI Signal Modes Compatibility (Input Signal Types) The following table is an illustration of some of the typical video display modes. Your TV supports up to Supported 1920x1200. Source Available Signals Index Resolution...
Appendix E: Supported DVI Resolutions When connecting devices to your TV’s connectors using DVI converter cable (not supplied), you can refer to the following resolution information. 24Hz 25Hz 30Hz 50Hz 60Hz 480i þ 480p þ 576i þ 576p þ 720p þ...
