Gas Built-in Hob
1 BURNER GAS HOB (GL301N)
2 BURNER GAS HOB (GL2N, GL302N)
3 BURNER GAS HOB (GL3N, GL603N, GL3SS)
4 BURNER GAS HOB (GL4N, GL4SS)
4 BURNER GAS HOB (GL704N)
INSTALLATION INSTRUCTIONS (FOR FITTERS ONLY)
Installation must be in accordance with manufacturer's instruction, relevant Gas
Fitting Regulations or AS5601 – "Gas Installation" regulations.
These instructions should be read carefully prior to initial use and retained in a safe
place in order that full advantage can be taken of the features of your HOB COOKER.
ANY SERVICING AND INSTALLATION OF THE HOTPLATE
MUST BE CARRIED OUT BY AN AUTHORIZED PERSON.
MANUFACTURER: A'VARD INDUSTRIES P/L.
ADDRESS:
TEL:
FAX:
WEBSITE:
Goldline N12- manual-ULPG Jan 2012
USER AND OPERATOR INSTRUCTIONS
ANY QUERIES SHOULD BE FORWARDED TO:
58-60 Quantum Close, South Dandenong, Victoria 3175, Australia.
61 3 9799 9660
61 3 9799 9662
www.goldlinecorp.com.au
&
REMINDER:
1
Advertisement
Table of Contents
Related Manuals for Goldline GL301N
Summary of Contents for Goldline GL301N
- Page 1 Gas Built-in Hob 1 BURNER GAS HOB (GL301N) 2 BURNER GAS HOB (GL2N, GL302N) 3 BURNER GAS HOB (GL3N, GL603N, GL3SS) 4 BURNER GAS HOB (GL4N, GL4SS) 4 BURNER GAS HOB (GL704N) INSTALLATION INSTRUCTIONS (FOR FITTERS ONLY) & USER AND OPERATOR INSTRUCTIONS Installation must be in accordance with manufacturer’s instruction, relevant Gas...
- Page 2 Diagram A Cut-Out (in mm) Tray Dimensions (in mm) Model GL2N/GL2ND Diagram A Diagram B Tray Dimensions (in mm) Cut-Out (in mm) Model GL3N/GL3SS Diagram A Diagram B Tray Dimensions (in mm) Cut-Out (in mm) Goldline N12- manual-ULPG Jan 2012...
- Page 3 Diagram B Tray Dimensions (in mm) Cut-Out (in mm) Model GL4N/GL4SS Diagram A Diagram B Tray Dimensions (in mm) Cut-Out (in mm) Model GL704N Diagram A Diagram B Tray Dimensions (in mm) Cut-Out (in mm) Goldline N12- manual-ULPG Jan 2012...
-
Page 4: Installation Instructions
- The flexible hose must be certified to AS/NZS1869 - class B or class D. - The gas connection point must be between 800 to 850mm above the floor and in the region outside the width of the appliance to a distance of 250mm. Goldline N12- manual-ULPG Jan 2012... - Page 5 - Disconnect gauge and replace test point screw. 10. Test the appliance: - Depress each control knob and turn to full flame setting. - The burner will ignite. Adjust control knob to desired setting. Normally, no adjustment should be necessary. Goldline N12- manual-ULPG Jan 2012...
- Page 6 - DO NOT TOUCH SPARK IGNITOR WHILE LIGHTING THE BURNER. - WHEN THE APPLIANCE IS INSTALLED IN A MARINE CRAFT OR IN A CARAVAN, IT SHALL NOT BE USED AS A SPACE HEATER. - DO NOT MODIFY THIS APPLIANCE. Goldline N12- manual-ULPG Jan 2012...
-
Page 7: Servicing Instructions
4-5mm 2. Check connection to ignitor, replace if faulty. If any problem cannot be rectified please contact the agent in your state or the gas supply authority service department or contact the product manufacturer. Goldline N12- manual-ULPG Jan 2012... -
Page 8: Manual Ignition
BATTERY REPLACEMENT (applicable to battery ignition model) 1. Open the battery holder cover flap 2. Remove old battery 3. Replace with new 1.5 Volt “D” size battery noting correct polarity 4. Close cover flap Goldline N12- manual-ULPG Jan 2012... -
Page 9: Maintenance Schedule
Check the burner port regularly for blockage especially if there is occurrence of spillage and clean them if necessary. MAINTENANCE SCHEDULE It is recommended that to have the units serviced by an authorized person at least once a year. Goldline N12- manual-ULPG Jan 2012... -
Page 10: Safety Hints
State should be consulted. Note: Should you still experience difficulties with your Goldline cook top please contact the manufacturer at the address and phone number provided in this manual Goldline N12- manual-ULPG Jan 2012... - Page 11 For spare part and technical support enquires please call MANUFACTURER: A’VARD INDUSTRIES P/L. ADDRESS: 58-60 Quantum Close, South Dandenong, Victoria 3175, Australia. TEL: 61 3 9799 9660 FAX: 61 3 9799 9662 WEBSITE: www.goldlinecorp.com.au e-mail: info@goldlinecorp.com.au Goldline N12- manual-ULPG Jan 2012...
