4 BURNER GAS HOBS
GLDUAL 704 BZNG-Cast
GLDUAL 704 BZLPG-Cast
GLDUAL 704 WZNG-Cast
GLDUAL 704 WZLPG-Cast
INSTALLATION INSTRUCTIONS (FOR FITTERS ONLY)
Installation must be in accordance with manufacturer's instruction, relevant Gas
Fitting Regulations or AS5601 – "Gas Installation" regulations.
These instructions should be read carefully prior to initial use and retained in a safe
place in order that full advantage can be taken of the features of your HOB
COOKER.
ANY SERVICING AND INSTALLATION OF THE HOTPLATE
MUST BE CARRIED OUT BY AN AUTHORIZED PERSON.
MANUFACTURER: A'VARD INDUSTRIES P/L.
ADDRESS:
TEL:
FAX:
WEBSITE:
4 BURNER GAS HOBS
GLDUAL 4 BZNG-Cast
GLDUAL 4 BZLPG-Cast
GLDUAL 4 WZNG-Cast
GLDUAL 4 WZLPG-Cast
USER AND OPERATOR INSTRUCTIONS
ANY QUERIES SHOULD BE FORWARDED TO:
58-60 Quantum Close, South Dandenong, Victoria 3175, Australia.
61 3 9799 9660
61 3 9799 9662
www.goldlinecorp.com.au
&
REMINDER:
5 BURNER GAS HOBS
GLDUAL 5 BZNG-Cast
GLDUAL 5 BZLPG-CAST
GLDUAL 5 WZNG-Cast
GLDUAL 5 WZLPG-Cast
Advertisement
Table of Contents
Related Manuals for Goldline GLDUAL 704 BZNG-Cast
Summary of Contents for Goldline GLDUAL 704 BZNG-Cast
- Page 1 4 BURNER GAS HOBS 4 BURNER GAS HOBS 5 BURNER GAS HOBS GLDUAL 704 BZNG-Cast GLDUAL 4 BZNG-Cast GLDUAL 5 BZNG-Cast GLDUAL 704 BZLPG-Cast GLDUAL 4 BZLPG-Cast GLDUAL 5 BZLPG-CAST GLDUAL 704 WZNG-Cast GLDUAL 4 WZNG-Cast GLDUAL 5 WZNG-Cast GLDUAL 704 WZLPG-Cast...
-
Page 3: Installation Instructions
Goldline GLDUAL manual April 2015 CUT OUTS Diagram A Diagram B Model GLDUAL 4 Tray Dimensions (in mm) Cut-Out (in mm) Diagram A Diagram B Model GLDUAL 704 Tray Dimensions (in mm) Cut-Out (in mm) Diagram A Diagram B Model GLDUAL 5... - Page 4 The cook top must be installed with provision to allow the gas to be turned off and disconnected for servicing and removal of the appliance as required from gas supply. Use a spanner at the flat area provided to hold the regulator firmly, when making the join. Refer diagram below. Goldline GLDUAL manual April 2015...
- Page 5 14. Please note that the cooktop is fitted with the flame failure device that cuts off the gas supply when burner flame extinguishes suddenly or abnormally in order to avoid gas leakage. WARNING! NOT FOR USE IN MARINE CRAFT, CARAVANS OR MOBILE HOMES UNLESS FITTED WITH SAFETY DEVICE. Goldline GLDUAL manual April 2015...
-
Page 6: Servicing Instructions
Turn the adjustment setting height of each. Replace electrode bypass screw anti-clockwise to and then fit clamp and screw. increase the turn-down rate FAULT ISOLATION CHART FAULT CAUSES REMEDY Goldline GLDUAL manual April 2015... -
Page 7: Manual Ignition
CONTROLS The Hobcooker has the control knobs, which are situated, at the front of the glass plate. An indicator motif advises which knob controls each burner. The ‘full -on’ and pre -set ‘simmer’ Goldline GLDUAL manual April 2015... -
Page 8: Burner Operation
Check the burner port regularly for blockage especially if there is occurrence of spillage and clean them if necessary. MAINTENANCE SCHEDULE It is recommended that to have the units serviced by an authorized person at least once a year. Goldline GLDUAL manual April 2015... - Page 9 State should be consulted. Note: Should you still experience difficulties with your Goldline cook top please contact the manufacturer at the address and phone number provided in this manual RECOGNISING ABNORMAL OPERATION...
- Page 10 For spare part and technical support enquires please call MANUFACTURER: A’VARD INDUSTRIES P/L. ADDRESS: 58-60 Quantum Close, South Dandenong, Victoria 3175, Australia. TEL: 61 3 9799 9660 FAX: 61 3 9799 9662 WEBSITE: www.goldlinecorp.com.au e-mail: info@goldlinecorp.com.au Goldline GLDUAL manual April 2015...
