Plantronics Savi W740-M Quick Setup Manual

Savi W740-M
® ™
Welcome:
Using a Plantronics Savi headset for PC
calls will deliver a simpler, more
comfortable and better sounding audio
experience than you could get using just
your computer's internal microphone
and speaker.
Savi W740-M Key Features:

Manages PC, deskphone and mobile
calls from a single headset

One-touch call answer/end, vol +/-,
mute and flash across devices

Hot swappable battery for unlimited
talk time (additional battery kit sold
separately)

Wireless freedom up to 350 feet from
your desk

Conference in up to three additional
Savi headsets
©2011 Plantronics, Inc. All rights reserved, Plantronics, the logo design, Savi and W740-M are trademarks or registered trademarks of Plantronics, Inc. Microsoft is a registered trademark of Microsoft Corporation in the United States and/or other
countries. Published 05.11
Quick Setup Guide
Getting started:
The Plantronics Savi headset is ready to use with your computer
and Microsoft® Office Communicator 2007.
1. Connect your Savi base to the computer. If this is the first
time you are connecting, wait for the installation process
to complete. Restart the computer if directed to do so.
Configuring Office Communicator to always route call audio to
the headset:
2. Click the drop down arrow icon in the upper left corner of
the Office Communicator window.
3. Select the Tools option.
4. Then select Set Up Audio and Video.
5. The first screen will be Setup for Handset or Headset.
Verify that your Plantronics headset is selected in the
drop down menu. Click Next.
6. This screen is Setup for Speakers/Microphone or
Speakerphone. Select Custom in the main drop down
menu.
7. Make sure your Plantronics headset is listed as your
speaker and microphone in the two drop down lists.
8. Click Next.
9. In the next screen, you will set the audio output for your
sounds (for example: incoming call or new IM message
alerts). We recommend that you use your PC speakers for
this setting
available). After making your selection click Finish.
Note: USB configuration settings are unique for each USB port. If you
connect the headset to a different port you will need to make these
changes again to set behavior for that USB port.
(if you have a sound card and speakers
2
3
6
Plantronics Headset
Plantronics Headset
8
4
7
7
9
