Service Manual
Refrigerator
Model: FF100SS
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http://svc.dwe.co.kr
S/M No. : FR272NCU00
(For AVANTI)
Sep. 2002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo FF100SS
Summary of Contents for Daewoo FF100SS
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD. http://svc.dwe.co.kr Sep. 2002...
-
Page 2: Safety And Precautions
SAFETY AND PRECAUTIONS 1) For starters, be sure to check any chances of the leakage of electricity 2) You could handle a part in the vicinity of electricity after unplugging 3) You should put on rubber glovers to prevent an electric shock on operation test 4) Make sure the rated current, voltage, capacity before using an instrument 5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten 6) Be careful not to let water to permeate the electric part in the machine room... -
Page 3: Specification
1.Specification 100g Refrigerant R134a Fan Cooling Convection Type COOLING System Air Forced Convection Refrigeration System Forced Fin-Evaporator Type Defrost System Automatic Start & Stop Defrost Operation Adjustable Dial Cold Control 2.2cu-ft Freezer Capacity 7.4cu-ft Refrigerator 9.6cu-ft Total Height 1636mm External 600mm Width Dimension... -
Page 4: Name Of Parts
2. NAME OF PARTS... -
Page 5: Refrigerant Cycle Diagram
3. REFRIGERANT CYCLE DIAGRAM... -
Page 6: Machine Room View And Part List
4. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME 1 BASE CAB AS 7 WI-CON PIPE 13 BASE COMP AS 2 COMPRESSOR 8 DRYER AS 14 BRACKET EARTH 3 P-RELAY AS 9 PIPE SUC AS 15 POWER CORD AS 4 PIPE VAPORI AS 10 PIPE SUC CONN 16 ABSORBER PIPE A... -
Page 7: Methods Of Exchanging Main Parts
5. METHODS OF EXCHANGING MAIN PARTS (1) Freezing room louver 1) Unscrew, remove the F-louver by pulling forward with inserting screwdriver into the hole of F louver. 2) Assemble it by pressing triangle shape ( ) by hand. (2) R control box 1) After pressing both bottom surfaces of shade and pull forward. - Page 8 Methode of exchanging main parts 4) Pull slightly forward with instant force. 5) Remove the housing 6) After romoving the control switch knob and two screws for fixing control switch, change the control switch to new one.
- Page 9 Methode of exchanging main parts (3) Bimetal 1) Cut off the wire bind. 2) Take out the bimetal. Bimetal (4) Glass tube heater Evaporator fastening screw 1) Remove 2 screws that fasten the evaporator. 2) Slightly pull the evaporator to the arrow's direction.
- Page 10 Methode of exchanging main parts 4) Cut the both ends of glass tube heater tube heater lead wires and insulate and seal lead tip remaining in refrigerator with tape etc. Raise upward Heater Cover Heater fixture Glass tube (Top) heater Lead wire 5) Pull out the glass tube heater from the heater supporter with heater covers remaining.
- Page 11 6. EXPLODE VIEW AND PARTS LIST 1. Expoloded views U.S.A (AVANTI , FF100SS)
-
Page 12: Parts List
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) 2) PARTS LIST U.S.A(AVANTI,FF100SS) NO PART CODE PART NAME DESCRIPTION... - Page 13 NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3012624000 HANDLE F A A TYPE 3011610810 DECO F HNDL AS A TYPE 3019015700 POCKET F *T GPPS 3019015800 POCKET F *U GPPS ASSY R DOOR URT HCFC-141B 3012310010 GASKET R DR AS PVC-S 3019016200 POCKET SM...
