Service Manual
Refrigerator
Model: FR-631ND
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http://svc.dwe.co.kr
S/M No. : FR631ND011
FR-710ND
Feb. 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-631ND and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo FR-631ND

Summary of Contents for Daewoo FR-631ND

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD. http://svc.dwe.co.kr Feb. 2001...

  • Page 2: Table Of Contents

    SAFETY AND PRECAUTIONS 1) For starters, be sure to check any chances of the leakage of electricity 2) You could handle a part in the vicinity of electricity after unplugging 3) You should put on rubber glovers to prevent an electric shock on operation test 4) Make sure the rated current, voltage, capacity before using an instrument 5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten 6) Be careful not to let water to permeate the electric part in the machine room...

  • Page 3: External Views

    1. EXTERNAL VIEWS 1-1. EXTERNAL SIZE model FR-631ND FR-710ND 1-2. NAME OF PARTS 1 Freezer Compartment Lamp 2 Shelf Ffreezer 3 Case Icing 4 Guide Icing 5 Ice Box 6 Refrigerator Compartment Lamp 7 Cover Cubic Duct 8 Fresh Case...

  • Page 4: Specifications

    2. SPECIFICATIONS 2-1. OUTLINE DIVISION CONTENTS MODEL NAME FR-631ND FR-710ND FREEZER USABLE CAPACITY (L) REFRIGERATOR TOTAL WIDTH EXTERNAL DIMENSION( mm) DEPTH HEIGHT 1818 1818 REFRIGENT R134a COOLING SYSTEM Fan Cooling System COOLING &CONTROL SYSTEM DEFROST SYSTEM Fin Evaporator Forced DEFORST CONTROL Automatic Start &...
  • Page 5 2) RELAY REFRIGERANT 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 50 240 / 50 TYPE NAME 276THBYY-52 181SHBYY-52 276THBYY-52 276THBYY-52 ASSY PART CODE 3018119350 3018116610 3018119350 3018119350 RESIS-TANCE C-RELAY PART CODE RESIS-TANCE S220 S330 S220...
  • Page 6 4) RUNNING CAPACITOR REFRIGERANT 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 50 240 / 50 PART CODE 400EL15110 RATED VOLTAGE 350V RATED CAPACITANCE 5µF REFRIGERANT R134a 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60...
  • Page 7 8) DEFROST HEATER REFRIGERANT R12, R134a 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 50 240 / 50 SPEC (W) 180W 180W 180W 180W 180W 180W 180W PART CODE 3012803210 3012803210 3012803210 3012803200 3012803200 3012803200 3012803200 9) LAMP ASSEMBLY REFRIGERANT...
  • Page 8 13) DOOR S/W REFRIGERANT R12,R134a 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 50 240 / 50 TYPE NAME PART CODE 3018100010 3018100010 3018100010 3018100010 3018100010 3018100010 3018100010 14) F-SENSER REFRIGERANT R12,R134a 220/50 VOLTAGE (V/HZ) 100 /50,60 110 / 60...

  • Page 9: Power Cord

    2-3. POWER CORD SHAPE OF POWER CORD PART CODE DESCRIPTION REMARK 3011315000 CP-2PIN For european country 401RA17200 CP-2PIN For other country 4006D17101 KP-30 For America & El Salvador 401PD17101 KP-211 For Japan & Taiwan 3011300801 BP-3PIN 3011303010 # 267 For Chile 3011315310 For Israel "For U.K, Middle Asia...

  • Page 10: Door Color

    2-4. DOOR COLOR 1) ASSEMBLY URETHAN FREEZER DOOR 1 NON-KEY TYPE R134a Refrigerant COLORTYP Embo High-glossy Normal High-glossy Embo High-glossy Normal PCM High-glossy Laminasheet Bright PCM Laminasheet Bright PCM PARTCODE 3010024400 3010024410 3010024420 2 KEY TYPE R134a Refrigerant COLORTYP Embo High-glossy Normal High-glossy...

  • Page 11: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM...

  • Page 12: Circit Diagram

    3-2. CIRCUIT DIAGRAM...

  • Page 13: Air Flow Diagram

    3-3. AIR FLOW DIAGRAM Freezer Pleas don’t put bottles such as beer, beverage etc. It might be broken because of freezing Freezer pocket Please don’t put long term storing items such as ice cream etc. It might be melted because of opening the door freguently.

  • Page 14: Refrigent Cycle Diagram

    3-4. REFRIGRANT CYCLE DIAGRAM...

  • Page 15: Exploded View And Parts List

    4. EXPLODED VIEW AND PARTS LIST 4-1. TOTAL EXPLODED VIEW...

  • Page 16: Total Parts List

    4-2 TOTAL PARTS LIST  Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) PART CODE PART NAME...
  • Page 17 INSU F LUVR A 3018909300 LOUVER F A HIPS 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 3010924600 CAP F LUVR 3017820900 SHELF F AS HIPS(FR-631ND) 59-1 3017820920 SHELF F AS HIPS(FR-710ND) 3010621500 BRACKET F SHELF 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 3011110200...
  • Page 18 REMARK 76-2 3011428601 COVER V/CASE SAN(FR-710ND) 3011110500 CASE VEGETB *R A 78-1 3011111000 CASE VEGETB *R B HIPS(FR-631ND) 78-2 3011113400 CASE VEGETB *R B HIPS(FR-710ND) 3014700200 ROLLER V/CASE *R / *L = 2 / 2 3015303300 SUPPORTER ROLL *R / *L = 2 / 2...
  • Page 19 PART CODE PART NAME PART DESCRIPTION Q'TY REMARK 3019012500 POCKET EGG HIPS 106-1 3019012400 POCKET FRESH HIPS 106-2 3011448400 COVER FRESH POCKET GPPS 3011161500 CASE EGG GPPS 3012307620 GASKET R DR AS PVC-S 3019012300 POCKET F *U HIPS 3019012200 POCKET F *T HIPS 3012307520 GASKET F DR AS...

  • Page 20: Machine Room Exploded View And Parts List

    4-3. MACHINE ROOM EXPLODED VIEW AND PARTS LIST PART NAME PART NAME PART NAME BASE CAB *B 10 CABLE TIE 18 PIPE SUC CONN SCREW MACHINE 11 CASE VAPORI AS 19 ABSORBER PIPE CORD POWER AS 12 PIPE WI-CON AS 20 PIPE MUFFLER AS SCREW TAPPING 13 SCREW TAPPING...
  • Page 21 DAEWOO ELECTRONICS CO., LTD. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” FAX: 02) 360-8184 TEL: 02) 360-8183 E-mail : G7F00E@web.dwe.co.kr S/M NO. : FR631ND010 PRINTED DATE: Feb. 2001...
