A Graham-Field Brand
Warning: This product should not be used without proper instruction from a healthcare professional.
Warning: Lumex assumes no responsibility for any damage or injury caused by improper installation,
assembly or use of this product.
Warning: If components are damaged or missing, contact your dealer immediately. DO NOT use
substitute parts.
Assembly instructions (see picture at right)
1. Install back & seat assembly on base frame
assembly.
2. Tighten and fix left and right knobs.
3. Install left and right armrests. Lock into place.
4. Install left and right footrests on base frame
assembly brackets. Lock into place.
5. Slide the commode set under the seat set from
back side.
Warning: Ensure that all components are
securely installed as described above
before use.
Lifetime limited warranty. For additional warranty information, please contact your Lumex dealer.
6810A: DROP ARM VERSAMODE
(WITH COMMODE PAIL)
ASSEMBLY INSTRUCTIONS
commode
WARRANTY
Graham-Field Health Products
Atlanta, Georgia 30360
printed in China
back & seat
assembly
armrest
set
knob
base frame
assembly
bracket
footrest
6810A
©Graham-Field Health Products, 05/04
