Series FR565WG Deluxe
Preferred Care Recliner
Extra Wide
Assembly and Operating Instructions
IMPORTANT: READ THIS MANUAL BEFORE OPERATING YOUR LUMEX FR565WG
DELUXE EXTRA WIDE PREFERRED CARE RECLINER.
SAVE THIS MANUAL FOR FUTURE USE.
THE MOST CURRENT VERSION OF THIS MANUAL CAN BE FOUND ONLINE AT
www.grahamfield.com.
FR565WG-INS-LAB-RevB12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lumex FR565WG Deluxe
Summary of Contents for Lumex FR565WG Deluxe
- Page 1 Preferred Care Recliner Extra Wide Assembly and Operating Instructions IMPORTANT: READ THIS MANUAL BEFORE OPERATING YOUR LUMEX FR565WG DELUXE EXTRA WIDE PREFERRED CARE RECLINER. SAVE THIS MANUAL FOR FUTURE USE. THE MOST CURRENT VERSION OF THIS MANUAL CAN BE FOUND ONLINE AT www.grahamfield.com.
-
Page 2: Table Of Contents
Graham-Field® and Lumex® are registered trademarks of GF Health Products, Inc. © 2012, GF Health Products, Inc., All Rights Reserved. FR565WG-INS-LAB-RevB12: Deluxe Preferred Care Recliner Assembly & Operating Instructions... -
Page 3: Introduction
Graham-Field / Lumex Technical Support at 770-447-1609. INTENDED USE Lumex Preferred Care Recliners are intended to make the care, treatment and recovery of patients easier and more comfortable. Lumex Preferred Care Recliners are used in a wide range of healthcare applications including Dialysis, Oncology, Long Term Care, Patient Room Seating, Same Day Surgery and Post-Operative Recovery. - Page 4 . WARNING:.Unauthorized.modification.of.your.recliner.or.the.use.of.non-Lumex. replacement.parts.may.change.the.structure.of.the.recliner.and.could.create.a. hazardous.condition,.which.may.result.in.serious.injury.and.will.void.the.warranty. . WARNING:.GF.Health.Products,.Inc..specifically.disclaims.responsibility.for.any. bodily.injury.or.property.damage.which.may.occur.during.any.use.which.does.not. comply.with.federal,.state.or.local.laws.or.ordinances. FR565WG-INS-LAB-RevB12: Deluxe Preferred Care Recliner Assembly & Operating Instructions...
-
Page 5: Assembly
ASSEMBLY UNPACKING INSTRUCTIONS 1. Refer to illustration below. 2. Unpack and inspect contents for shipping damage or missing parts. If parts are damaged or missing, contact your Graham-Field distributor immediately. The contents of this package should be: a. One Recliner frame with upholstered seat b. -
Page 6: Upholstered.back.assembly
Upholstered Back Assembly upholstered back cushion elastic band Info: To facilitate assembly, DO NOT remove the wooden shipping support that is attached to the recliner’s metal back frame until after the recliner's metal back frame has been assembled to the recliner frame. -
Page 7: Operation
OPERATION TENTE® CASTERS . WARNING:.Casters.must.be.locked.at.all.times,.except.during.transport. All Lumex Preferred Care Recliners now feature black actuator tab green actuator tab the latest design, all-plastic casters from TENTE. Specifically designed for use in healthcare environments, the new casters are easier to clean, easier to move, and tolerate a wide array of cleaners and chemicals. -
Page 8: Recliner.operation
RECLINER OPERATION The Lumex Series FR565WG Preferred Care Recliners feature an infinite position mechanism, meaning there are no stops as are found on traditional recliner mechanisms. In addition, there is a caregiver position lock handle located on the back of the recliner that... -
Page 9: Recliner.positioning.mechanism.trouble-Shooting.guide
RECLINER POSITIONING MECHANISM TROUBLE-SHOOTING GUIDE Adjustment Instructions for Positioning Locking Mechanism . WARNING:.DO.NOT.lubricate.the.position. mechanism.assembly..The.recliner.could. fail.to.lock.in.position.and.cause.severe. clevis pin with ring cotter pin personal.injury. 1. Refer to illustration at right. 2. Turn the position lock adjustment handle downward to the release position. Remove the top clevis pin by removing the ring cotter pin and sliding the clevis pin out of the mechanism. -
Page 10: Upholstery.removal.and.replacement
UPHOLSTERY REMOVAL AND REPLACEMENT Back Cushion Refer to illustration at right. key ring frame To Remove: Release the two rings mounted on the elastic straps from the buttons mounted on either side of the recliner frame which hold the back strap cushion to the back frame. -
Page 11: Care.and.maintenance
CARE AND MAINTENANCE . WARNING:.Inspect.all.components.periodically.and.replace.as.needed. EVERY THREE MONTHS • Check and clean casters • Tighten bolts in each leg that secure caster into frame • Check brakes on casters • Check and clean lock recline mechanism • Check recliner mechanism for operation in all positions, including Trendelenburg Position, with assistant seated in recliner UPHOLSTERY MAINTENANCE AND STAIN REMOVAL •... -
Page 12: Cdc.recommendations
The information published in this care guide refers to the performance of PERMABLOK3 products in specific tests conducted under laboratory conditions. Results may vary under actual conditions. This information is not a guarantee and does not relieve the user from the responsibility of the proper and safe use of the product and all cleaning agents. - Page 13 • Detergent and water are adequate for cleaning surfaces in nonpatient-care areas (e.g., administrative offices). Clean and disinfect high-touch surfaces on a more frequent schedule than minimal-touch housekeeping surfaces. Clean walls, blinds, and window curtains in patient-care areas when they are visibly dusty or soiled. •...
-
Page 14: Technical.specifications
400 lb (181 kg), EVENLY DISTRIBUTED For complete technical specifications, please call the Graham-Field Technical Support Group at 770-447-1609. ACCESSORIES For your convenience, Graham-Field / Lumex offers the following accessories that may be purchased from your Graham-Field / Lumex Distributor. Item Description... -
Page 15: Limited.warranty
LIMITED WARRANTY GF Health Products, Inc. warrants the Lumex FR565WG Deluxe Extra Wide Preferred Care Recliner against manufacturing defects in materials and workmanship as listed below: Welded Frame ....Lifetime limited Upholstery ......One year limited All Other Components ..Three year limited If a product is deemed to be under warranty, GF Health Products, Inc. - Page 16 GF Health Products, Inc. 2935 Northeast Parkway Atlanta, Georgia 30360 USA Telephone: 770-368-4700 Fax: 770-368-2386 Technical Support: 770-447-1609 www.grahamfield.com...
