DIADEMA - LILIANA IDRO IDRO USER MANUAL ENGLISH/INGLESE... -
Page 3: Table Of Contents
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. enGLiSH .............................................. - Page 4 controL paneL ..................................21 dIsplay Icons key ..........................................21 GeneraL Menu ..................................22 basIc InstructIons ..........................................22 tHe reMote controL ................................23 enable delayed swItch-off ......................................23 type and replacement of batterIes ..................................23 coMMiSSioninG SettinGS ..............................24 adjustIng tIme, day, month and year ..................................24 adjustIng the language .........................................24 operation and LoGic ................................25 additionaL rooM tHerMoStat ............................26 addItIonal thermostat functIonIng wIth stby actIve..........................26...
-
Page 5: English
Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. If it is damaged or lost, request another copy from the area technician. -
Page 6: Hydraulic System
HYDRAULIC SYSTEM Certain concepts referring to the Italian UNI 10412-2 (2009) Standard are described in this chapter. As previously described, when installing, all national, regional, provincial and town council Standards in force provided by the country in which the appliance has been installed must be complied with. TABLE of DEvICES foR CLoSED vESSEL SYSTEM, PRESEnT AnD noT PRESEnT In THE PRoDUCT Safety valve Pump control thermostat (managed by the water probe and board program) -
Page 7: Type Of System
Whenever the generators lack a device, those missing can be installed on the generator flow pipe, within a distance no greater than 1m from the machine. CoMPonEnT DISTAnCE Temperature safety sensors On the machine or not exceeding 30 cm Missing devices because not as per standard Not exceeding one metre, on the flow pipe The domestic heating appliances with automatic feeding must: be equipped with a fuel block thermostat or with a cooling circuit set up by the appliance manufacturer. -
Page 8: Closed Expansion Vessel
valve inlet or than the sum of the inlet cross-sections, in the event of several valves serving a single pipe. The discharge piping of the safety valve must be realised in order not to prevent the regular functioning of the valves and not to cause damages to persons;... -
Page 9: Liliana Idro - Diadema Idro Basic Hydraulic System Diagram
LiLiana idro - diadema idro basic hydrauLic system diagram VMTA Combustion air inlet Ø 60mm Smoke exhaust outlet Ø 120mm 3 bar safety valve 1/2 " Boiler flow/output 1" Boiler return/inlet 1" Pressure Gauge Thermometer Filling system Safety valve discharge System exhaust Balance valve Vmta... -
Page 10: Stove Positioning
stoVe positioning For correct product functioning, it is recommended to position it so that it is perfectly level, using a spirit level. rearms The figures below illustrate the positions of the tank (85°C) and H2O (100°C) rearms. Contact the qualified technician if one of the rearms should be triggered, so as to verify the cause. -
Page 11: Devices
devices TeRMs ANd deFiNiTioNs (in the relevant models) Aeration: Air renewal is required both for the disposal of the combustion products, and to prevent mixtures with a door micro switch: With the door open, the operation of the hazardous content of non-combusted gases. burn pot cleaning system is blocked closed hearth appliance: Appliance designed for operation with closed combustion chamber. -
Page 12: General
FUNcTioNAl oPeRATioNs diAgRAM State of the art installation and proper system operation include a series of activities: 1. Preliminary activities: Š Verification of the suitability of the power of the heat generator based on the characteristics of the system Š verification of the suitability of the installation site, Š... -
Page 13: Installation
iNsTAllATioN Installation in premises with fire hazards is forbidden. Installation in residential premises (except for sealed operation appliances) is also forbidden: Š in which there are liquid fuel-operated appliances with continuous or intermittent operation, which draw the combustion air in the room in which they are installed, or Š... -
Page 14: Fumes Exhaust System
veNTilATioN ANd AeRATioN oF The iNsTAllATioN PReMises Ventilation is deemed sufficient when the room is equipped with air inlets according to the table: Air inlet See figure 2 Percentage of the net opening section with Minimum net opening value of Appliance categories Reference standard respect to the appliance fumes... -
Page 15: Smoke Duct
Š nominal diameter; Š distance from combustible materials, indicated in millimetres, followed by the arrow and flame symbol; Š installer data and date of installation. Every time one must cross combustible materials, the following indications must be complied with: sYMbol descRiPTioN qUoTA[MM] Minimum distance of combustible materials from the intrados of the framework/floor/wall... - Page 16 Š counter-slope sections are not allowed; Š the smoke ducts must have, along their entire length, a diameter that is no less than that of the attachment of the appliance exhaust pipe; any section changes are allowed only on the inlet to the chimney; Š...
-
Page 17: Chimney
exAMPles oF coRRecT coNNecTioN To The chiMNeY Protection from rain Protection from rain and wind and wind Steel plate, airtight Max 3 mt 3 - 5% Insulated "T" fitting with inspection plug "T" fitting with "T" fitting with inspection plug inspection plug it is mandatory to use airtight pipes. -
Page 18: Fumes Exhaust System Product Requirements
coMbUsTioN PRodUcTs oUTleT qUoTA The outlet quota is determined by measuring the minimum height between the roof covering and the lower point of the fumes expulsion section into the atmosphere; this quota must be outside the reflux area and at an adequate distance from obstacles which hinder or make the expulsion of the combustion products difficult or from openings or accessible areas. -
Page 19: Technical Installation Documentation
coverings and finishings The coverings and finishings must only be applied after having verified the proper operation of the appliance according to the indicated modalities TechNicAl iNsTAllATioN docUMeNTATioN When installation is complete, the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... -
Page 20: Pellets And Feeding
Pellets and feeding Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other activities related to processing and working with wood. Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. -
Page 21: Control Panel
Control panel BUTTON Display OF variOUs TO aCCess ON/OFF TexT messages THe meNU OperaTiON pOWer TemperaTUre aDJUsTmeNT seTTiNg Display iCons key indicates the receipt of the radio signal indicates the stove modulation On = during radio communication On = the stove is working at the set power Off = no radio communication Flashing = the power at which the stove is working is different to the power Flashing = serial port excluded... -
Page 22: General Menu
This appliance must not be used to burn waste. Š on 1. Extraflame has an optional additional board that allows the boiler the following further functions when managing the system. The table below indicates the various possibilities that the optional can offer. -
Page 23: The Remote Control
the remote Control all that can normally be implemented through the lCD can be adjusted using the remote control. The table below provides a detailed description of the various functions: on / off pressing the key for three seconds, the stove will switch-on or off power inCrease pressing the key will increase the operating power power DeCrease... -
Page 24: Commissioning Settings
CommissioninG settinGs Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (i). The switch at the back of the stove powers the stove board. The stove remains off and a first screen appears on the panel reading OFF . aDjustinG time, Day, month anD year set clock allows to adjust the time and date set CloCk... -
Page 25: Operation And Logic
operation anD loGiC iGnition Once the "basic instructions" listed previously have been checked, press key 1 for three seconds to ignite the stove. 15 minutes are available for the ignition phase. after ignition and having reached the control temperature, the stove interrupts the ignition phase and passes to sTarTiNg. -
Page 26: Additional Room Thermostat
Š refer to the electrical diagram to connect the two thermostat cables onto the relative clamps positioned on the rear of the machine, one is red and the other one is black (sTBy clamp). Connection reserved for extraflame conveyed waves accessories. Contact the dealer for further details STBY "a"... -
Page 27: Menu Structure
menu struCture Go baCk - exit parameter sCrollinG: next (2) ; previous (3) moDify settinGs Data: inCrease (4); DeCrease (5) Confirm - aCCess menu menu text value funCtion set power power 01 - 05 selecting the power set temperature set h2o 65°... -
Page 28: Set Power
set power The following menu allows to set the power. minimum power 1, maximum power 5. CONTrOls prOCeDUre Š press key 6 and set power will appear. Š Confirm using key 6 Š The power will be displayed. Š press 4 to increase the setting and 5 to decrease it. Š... -
Page 29: Enable Chrono
enable Chrono The boiler chrono can be enables/disables from this menu CONTrOls prOCeDUre Š press key 6 and set power will appear. Š press key 2 several times until set aDjustments is displayed Š press key 6 Š press key 2 until enable Chrono is displayed Use keys 4 -5 to enable "on"/ disable "off". -
Page 30: Chrono
Chrono The chrono allows to program 4 time spans within a day to use every day of the week. the switch-on and switch-off time can be set in every time slot, along with the days of use of the programmed time slot and the desired water temperature (65 - 80°C). proGramminG example let's suppose that the weekly programmer function is to be used and 4 time slots are to be used in the following way: 1st time slot: from 08:00 to 12:00 every day of the week, excluding saturday and sunday... -
Page 31: Adjusting Language
*2ND Time slOT sWiTCH-ON at this point, the second time slot must be programmed. The sequence to be followed is the same and is repeated as per the "1sT Time slOT sWiTCH-ON". On this occasion it is only necessary to enter the time, for example start at 15:00 and stop at 22:00 and to activate the days saturday and sunday by setting them at "ON". -
Page 32: Reset
- briGhtness This menu allows to adjust the brightness of the display. The possible settings range from OFF - 10 to 31. activating OFF, the back light of the display will go off after a preset delay. The back light will go on as soon as a key is pressed or if an alarm should be triggered in the machine. CONTrOls prOCeDUre Š... -
Page 33: Maintenance
Maintenance Maintenance warnings Inspection and maintenance operations must be carried out by specialised technicians who are aware of the directions reported in this manual. Before carrying out any work, make sure that: Š The power cable's plug has been pulled out, as the generator might have been programmed to turn on. Š... - Page 34 weeKLY clean the the ash drawer: combustion chamber and Empty the ash drawer every week or when required. It is recommended to remove the ash in the combustion chamber at least once a week using a suitable vacuum cleaner MontHLY cleaning the deflector: The fumes deflector located in the upper part of the combustion chamber must be removed on a monthly basis.
- Page 35 cLean cHecK uP aLarM 1 - 2 sHouLD tHe aLarM "cLean cHecK uP" Be triggereD, MaKe sure tHat tHe BottoM of tHe Burn Pot is free froM resiDues or scaLing. tHe HoLes on tHe siDe of tHe Burn Pot (see figure to tHe siDe) Must Be coMPLeteLY cLear, to ensure ProPer coMBustion.
- Page 36 routine Maintenance Some images could be offset from the original model. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Inspections of gaskets, ash drawer and door (replace them and apply silicone where envisioned) ...
-
Page 37: Displays
Displays Display Reason Stove off sTaRT The start-up phase is in progress pelleT feeDinG Continuous pellet feeding is in progress during the ignition phase iGniTion The ignition phase is in progress sTaRT-up The start-up phase is in progress WoRk The normal work phase is in progress MoDulaTion The stove is working at minimum BuRn poT... -
Page 38: Alarms
alaRMs Display eXplanaTion soluTion On: indicates the presence of an alarm Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have elapsed from when the alarm was displayed. - Page 39 ENGLISH...
