Paradyne Hotwire 8810 Errata

Hotwiret 8810 Digital Subscriber Line Access Multiplexer (DSLAM)
Installation Guide
Errata
Document Number 8810-A2-GK40-00
October 1998
Telco 50-pin Connector Pinouts for DSL Loops and
POTS Splitters
50
26
25
1
97-15323
8810-A2-GK40-00
TM
This document contains information about the user documentation. Keep this
document with your Hotwire
This information applies to page B-3 of the following document:
H
Hotwire 8810 Digital Subscriber Line Access Multiplexer (DSLAM) Installation
Guide (Document No. 8810-A2-GN20-00)
The three Telco 50-pin connectors on the Interface Module and the 18 Telco
50-pin connector on the rear of the chassis provide the 2-wire loop interface
from each DSL port to either the POTS splitter shelf or, if the loop is not being
shared with POTS, then to the Main Distribution Frame (MDF). The following
table lists the pin assignments for each of these interfaces. Note that Pins 25
and 50 are not used.
