User Manual
®
Hotwire
8799 TDM SHDSL Line Card
with G.703 Interface
Installation Instructions
Document Number 8799-A2-GZ40-10
April 2003
Product Documentation Online
Complete documentation for this product is available at www.paradyne.com.
Select Support
Select the following documents:
To order a paper copy of a Paradyne document or to speak with a sales
representative, please call 1-727-530-2000.
Hotwire 8799 TDM SHDSL Line Card
The Hotwire
Division Multiplexer Symmetric High-bit-rate Digital Subscriber Line (TDM SHDSL)
ports and a G.703 interface. When the card is used in a Hotwire 8610/8620 or
8810/8820 Digital Subscriber Line Access Multiplexer (DSLAM) chassis, it
transports up to 2048 Kbps signals over traditional twisted-pair telephone wiring.
8799-A2-GZ40-10
Technical Manuals
8799-A2-GB20
Hotwire 8799 TDM SHDSL Line Card, with G.703 Interface, User's Guide
8000-A2-GB22
Hotwire Management Communications Controller (MCC) Card, IP
Conservative, User's Guide
®
8799 Line Card is a circuit card assembly that contains eight Time
HANDLING PRECAUTIONS FOR
!
STATIC-SENSITIVE DEVICES
This product is designed to protect sensitive components from damage
due to electrostatic discharge (ESD) during normal operation. When
performing installation procedures, however, take proper static control
precautions to prevent damage to equipment. If you are not sure of the
proper static control precautions, contact your nearest sales or service
representative.
April 2003
Hotwire DSL
Systems.
1
Advertisement
Table of Contents
Related Manuals for Paradyne Hotwire 8799
Summary of Contents for Paradyne Hotwire 8799
-
Page 1: Product Documentation Online
If you are not sure of the proper static control precautions, contact your nearest sales or service representative. 8799-A2-GZ40-10 Technical Manuals Hotwire DSL ® 8799 Line Card is a circuit card assembly that contains eight Time April 2003 Systems. -
Page 2: Installation Overview
Installation Overview Installation and configuration of the Hotwire 8799 TDM SHDSL Line Card consists Installing the card in the DSLAM. Connecting to the DTE. Installing the supplied ferrite chokes. Connecting to an MDF. Providing initial card identity information or changing existing identity information. - Page 3 Installing TDM SHDSL Cards A Hotwire 8799 TDM SHDSL Line Card can be installed, removed, and replaced from the DSLAM chassis without disrupting service to the other cards in the chassis. Procedure To install the card: 1. Determine in which slot the card will be installed. Verify that cards in adjacent slots have been fastened.
- Page 4 — For a Hotwire 8810/8820 DSLAM chassis – Hold the Hotwire 8799 TDM SHDSL Line Card vertically, with the component side facing right, and insert it into the top and bottom card guides. 4. Slide the card into the slot until the power and network connectors seat firmly in the mating connectors on the backplane.
-
Page 5: Connecting To The Dte
Connecting to the DTE Connection to the four ports of the Hotwire 8799 TDM SHDSL Line Card is through the 50-pin interface connector on its faceplate. Refer to Connector Pin Assignments in the User’s Guide Procedure To connect the Hotwire 8799 TDM SHDSL Line Card to your DTE: 1. - Page 6 Connecting to an MDF You can connect the Hotwire DSLAM chassis containing the Hotwire 8799 TDM SHDSL Line Card to an MDF or other demarcation point. Do not connect it to a POTS splitter. Procedure To connect the Hotwire DSLAM chassis containing the Hotwire 8799 TDM SHDSL Line Card to an MDF: 1.
-
Page 7: Front Panel Leds
Front Panel LEDs The following table describes the meaning and states of the LEDs on the Hotwire 8799 TDM SHDSL Line Card’s faceplate. Type SYSTEM G.703 DSL PORT * Slow cycling: LED turns off and on in equal duration once per second. -
Page 8: Logging In To The Hotwire Dslam
(MCC) Card, IP Conservative, User’s Guide TDM SHDSL card from the MCC card selection screen. Asynchronous Terminal Interface Menu The following illustration shows the paths to the Hotwire 8799 TDM SHDSL Line Card’s various ATI screens. Hotwire Management Communications Controller... -
Page 9: Entering Identity Information
Configuring the Card Configuration option settings determine how the card operates. Use the Configuration branch of the Hotwire 8799 TDM SHDSL Line Card’s menu to display or change configuration option settings. If the factory default settings do not support your network’s configuration, customize the configuration options for your application. -
Page 10: Accessing And Displaying Configuration Options
Configuration Edit/Display menu screen appears. The Configuration Loader screen is displayed allowing you to upload or download configurations from a TFTP server. The selected configuration option set is loaded and the Configuration Edit/Display menu screen appears. April 2003 Model: 8799 MainMenu Exit 8799-A2-GZ40-10... -
Page 11: Configuration Edit/Display
System Options (Table 5) General system options of the card. System Clock Options (Table 6) System clock. Cross-Connect Mode Options The card’s cross connections (Table 7) and timeslot assignments. Assign Time Slots Options (Table 8) April 2003 Model: 8799 MainMenu Exit... - Page 12 General SNMP Management Management support of the Options (Table 9) card through SNMP and the Inband Management Channel. SNMP NMS Security Options (Table 10) SNMP Traps Options (Table 11) Inband Management Channel Options (Table Guide. April 2003 Hotwire 8799 TDM 8799-A2-GZ40-10...
- Page 13 Default Setting: 000.000.000.000 Specifies the peer IP address for the remote management link. Circuit Identifier Possible Settings: ASCII text field , Clear Default Setting: [blank] Uniquely identifies the circuit number of the transmission vendor’s DSL line for troubleshooting purposes. 8799-A2-GZ40-10 April 2003...
- Page 14 Specifies the threshold for loop attenuation in a 15-minute interval after which a trap will be sent. Margin Trap Threshold Possible Settings: 1–15 dB, or 0 to Disable Default Setting: 4 Specifies the threshold for the Signal-to-Noise ratio margin in a 15-minute interval after which a trap will be sent. April 2003 8799-A2-GZ40-10...
- Page 15 Default Setting: Signaling_CCS Specifies whether the G.703 interface is used for voice or data. Primary Clock Source STU-C Only. Possible Settings: Internal, G.703 Default Setting: Internal Determines the primary clock source for the card when in Bypass mode. 8799-A2-GZ40-10 April 2003...
- Page 16 Default Setting: 120 ohms Specifies the line impedance of the G.703 interface. Region Setting STU-C Only. DIsplays: Annex B Specifies the set of unique, regional SHDSL operations parameters to be used by the card. Displays Annex B for European networks. April 2003 8799-A2-GZ40-10...
- Page 17 Default Setting: Internal Possible Settings (STU-R): DSL Port 1–8 Default Setting: DSL Port 2 Specifies the secondary clock source to be used for system timing. Failure of this clock results in an automatic fallback to the internal clock. 8799-A2-GZ40-10 April 2003...
- Page 18 Possible Settings: DS1 Bypass, DS1 Cross-connect, DS0 Cross-connect, Unassigned, Disabled Default Setting: DS1 Bypass Determines the cross-connect mode for the port. Destination Possible Settings: DSL (1–8), G.703 (1–8), Unassigned, I Default Setting: DSL Specifies which destination port is cross-connected to the selected source port. April 2003 8799-A2-GZ40-10...
- Page 19 Default Setting: [Blank] Determines the time slot to which this time slot is connected. Data or Voice Possible Settings: d, v Default Setting: d Determines whether the time slot is dedicated to the transmission of voice or data. 8799-A2-GZ40-10 April 2003...
- Page 20 SNMP manager when that manager attempts to access an object in the MIB. Name 2 Access STU-R Only. Possible Settings: Read, Read/Write Default Setting: Read Determines the access level for Community Name 2. April 2003 8799-A2-GZ40-10...
- Page 21 Default Setting: 000.000.000.000 Specifies the Internet Protocol address used to identify each SNMP manager. Access Type Possible Settings: Read, Read/Write Default Setting: Read Determines the access level allowed for an authorized NMS when IP address validation is being performed. 8799-A2-GZ40-10 April 2003...
- Page 22 Possible Settings: PPP, Frame Relay Default Setting: PPP Specifies the type of data the Inband Management Channel will accept. Inband Management Port Possible Settings: 1 – 8 Default Setting: 1 Selects the G.703 port for the primary Inband Management Channel. April 2003 8799-A2-GZ40-10...
- Page 23 Selects the G.703 time slot for the backup Inband Management Channel. Backup Inband Management DLCI Possible Settings: 16 – 1007 Default Setting: 16 Selects the Data Link Connection Identifier (DLCI) the backup Inband Management Channel will use when Inband Management Type is set to Frame Relay. 8799-A2-GZ40-10 April 2003...
- Page 24 Configuration DSL Port DSL INTERFACE OPTIONS Port Status: Estimated Line Length: Startup Margin: Max DSL Rate: Min DSL Rate: EIA-530 Payload Rate: Remotely Initiated Loopback: April 2003 Model: 8799 Enable Long 2056 kbps 2056 kbps 2048 kbps Enable Clear MainMenu...
-
Page 25: Important Safety Instructions
— Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. — Do not use the telephone to report a gas leak in the vicinity of the leak. 8799-A2-GZ40-10 April 2003... -
Page 26: Emi Notices
CANADA – EMI NOTICE: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la classe A respecte toutes les exigences du règlement sur le matérial brouilleur du Canada. April 2003 8799-A2-GZ40-10... -
Page 27: Warranty, Sales, Service, And Training Information
Hotwire is a registered trademark of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks or registered service marks of their respective owners. Copyright © 2003 Paradyne Corporation. Printed in U.S.A. 8799-A2-GZ40-10 April 2003... - Page 28 *8799-A2-GZ40-10* *8799-A2-GZ40-10* April 2003 8799-A2-GZ40-10...
