SERVICE MANUAL

MINIDISC RECORDER

• This Supplement Service Manual is issued because of some changes in MD

MECHANISM for the models

AM-C80 (AU) / F80 (AHC,AHK,AHR,AEZ,AK), (S/M Code No. 09-99B-419-2R2) and

AM-F75 (AK,AEZ), (S/M Code No. 09-99B-422-0R1).

AM-C80

AM-F80

AM-F75

BASIC MD MECHANISM : ZZG-A R1

S/M Code No. 09-008-419-2S3

AHC,AHK,AHR,

AEZ,AK

AK,AEZ

Page 1 BASIC MD MECHANISM : ZZG-A R1 • This Supplement Service Manual is issued because of some changes in MD MECHANISM for the models AM-C80 (AU) / F80 (AHC,AHK,AHR,AEZ,AK), (S/M Code No. 09-99B-419-2R2) and AM-F75 (AK,AEZ), (S/M Code No. 09-99B-422-0R1). S/M Code No. 09-008-419-2S3...
Page 2 MECHANICAL EXPLODED VIEW 1 / 1 SH,SPINDLE – 2 –...
Page 3 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-ZGA-226-010 HLDR,P.U.GUIDE S 2 87-A91-016-010 MOT,LA8-388L 3 88-ZG2-228-010 GEAR,A OWH 4 87-067-569-010 POLY WASHER 0.83-2.5-0.25 5 88-ZG2-221-110 HLDR,MOT OWH 6 88-ZG2-227-010 GEAR,MOT OWH 7 88-ZG2-230-010 GEAR,C OWH 8 88-ZG2-229-010 GEAR,B OWH 9 88-ZG2-240-010...
Page 4 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9301978 9620450 Printed in Singapore...
